T T a a b b l l e e o o f f C C o o n n t t e e n n t t s s
Non-Transferable Limited Consumer Warranty . . . . . . . . . . . . . . . . . . . . . . . . .2

Important Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

7" Headrest Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Typical Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

I I m m p p o o r r t t a a n n t t N N o o t t e e s s
1. Before installing your LCD Monitor system, please read the instructions care-
fully.
2. Retain this manual for future reference.
3. Do not use any chemical solvent, cleaning agent or corrosive detergent to clean
away dirt on the surface of the screen. Doing so may cause irreversible dam-
age to the surface of the LCD screen. To clean off dirt or fingerprints, it is rec-
ommended that a soft-damp lens cleaning cloth be used.
4. Using spare parts from another manufacturer may cause permanent damage to
the unit.
5. Install the unit in a dry location, avoid condensation.
6. Ensure the plugs are properly plugged in before operating the unit.
7. Should the LCD panel break, avoid contact with the broken glass or fluid leaking
out from the enclosure. If you come into contact, flush and clean the affected
areas with plenty of water. Seek medical attention immediately.
8. When operating the display unit, avoid touching or pressing on the LCD screen.
Excessive force will damage the LCD screen.
9. When installing this unit in a vehicle, ensure that the installation and use of
this unit is in compliance with local vehicle rules and regulations.
10. Use the head rest cover to protect and conceal the LCD screen when not in use.
© 2004 Directed Electronics, Inc.
