I-gotU Q-Band Q-68HR User Manual

Q-68HR
Device Overview
Reversible Wristband
Metallic contact for charging
How to wear your Q-68HR?
1
Wear Q-68HR on your wrist
Put on the wristband with the screen facing up and the band wrapped
around your wrist. Slide one band through the loop of the other band, and
align the clasp along the band to find the holes where best fit the clasps.
3
Charge your Q-68HR
1
To charge your Q-68HR, place it in the charging box at the
other end of the USB cable. Close the box afterwards, and
make sure the Q-68HR is securely covered. Plug the USB
connector to either a PC or power adapter to start charging.
Q-Band
Core
2
3
Touch Button
Optical Sensor
2
Fasten Q-68HR with clasp
Squeeze both clasps into the holes on the wristband until you hear a
click, indicating the band is securely fastened.
Note: The watch band is replaceable and both side wearable/reversible.
4
Change the wristband
1
2
1. Spread open both bands with the screen facing up, and press down the screen
with your thumb until the core comes off the wristband.
2. Insert the core with screen facing up into the notch from below the wristband.
Make sure the two tenons on each side of the core are securely fixed into the
corresponding slots in the bands.
Important Notice:
Failure to follow the instructions above might cause damage to the device.
EN
User Manual
Clasp
