This product can be used with the
following operating systems:
Windows XP, Me, 2000, 98SE
Windows XP, Me, 2000, 98SE
Windows XP, Me, 2000, 98SE
Windows XP, Me, 2000, 98SE
Windows XP, Me, 2000, 98SE
Macintosh OS v10.1
Macintosh OS v10.1
Macintosh OS v10.1
Macintosh OS v10.1
Macintosh OS v10.1
Before You Begin
You must have at least the following:
Windows XP/Me/2000/98SE or Macintosh OS v10.1
•
•
Pentium Class CPU or Higher
•
One Available PCI Slot
•
CD-ROM Drive
Check Your Package Contents
These are the items included with your purchase:
If any of the below items are missing, please contact your reseller.
Run the Driver CD before you install the DU-520.
The Driver CD contains an installation program that
significantly simplifies the installation process.
• DU-520 Hi-Speed USB 2.0 PCI Adapter
• CD-ROM (containing Drivers,
Installation Guide and Warranty)
Windows Users
DU-520
DU-520
DU-520
DU-520
DU-520
5-Port Hi-Speed
USB 2.0 PCI Adapter
1
Advertisement
Table of Contents
Related Manuals for D-Link DU-520
Summary of Contents for D-Link DU-520
-
Page 1: Before You Begin
• DU-520 Hi-Speed USB 2.0 PCI Adapter • CD-ROM (containing Drivers, Installation Guide and Warranty) Windows Users Run the Driver CD before you install the DU-520. The Driver CD contains an installation program that significantly simplifies the installation process. DU-520... - Page 2 Insert the D-Link CD-ROM Into Your Computer Mac users please proceed to the last section. Turn on your computer insert D-Link DU-520 Driver CD in the CD-ROM drive. Click Install Drivers If the Autorun screen does not automatically start, click on Start > Run, enter “D:\Autorun.exe”...
- Page 3 PCI card). Locate an available PCI slot and insert the DU-520 carefully into the PCI slot. Secure the DU-520 with the screw from the backplate. Replace your computer's cover and plug in the power cord. Turn On PCI Slot...
-
Page 4: Windows Xp Users
Completing The Driver Installation Windows XP Users It is recommended to have the latest Windows XP Service Packs installed on your computer for optimal product performance. Driver installation will proceed automatically for Windows XP with Service Pack. If Service Packs are not installed, follow these steps to complete the driver installation. -
Page 5: Windows 2000 & Me Users
Windows XP Users Click Next Click Continue Anyway Click Finish Windows 2000 & Me Users The DU-520 driver installation will proceed automatically for Windows 2000 & Me users while Windows is starting. -
Page 6: Windows 98Se Users
Windows 98SE Users Follow these steps to complete installation under Windows 98SE for each device that Windows propmpts you to install. You will see each of these screens twice. Click Next Click Next Make sure all boxes are unchecked and Click Next. - Page 7 Windows 98SE Users Click Next Click Next Windows 98 may prompt you for the Windows 98 Setup disk. If prompted, insert the Windows 98 Setup disk and select OK. Click Finish When prompted, Computer Restart Your to complete the installation.
- Page 8 Macintosh OS X 10.1 Users Insert the DU-520 Driver CD into the CD-ROM drive. Double-click DU-520 appears on the desktop Drag-&-drop USB2EHCI_V1033_1130.img to the desktop Double-click USB2EHCI- V1033_1130.IMG from the desktop Double-click USB2EHCI_V1033 it appears on the desktop Double-click USB2EHCI_V1033.pkg...
- Page 9 Macintosh OS X 10.1 Users Click the Lock Enter your Name & Password Click Click Continue...
- Page 10 Macintosh OS X 10.1 Users Select a Destination Volume Click Continue Click Install Click Continue Installation...
- Page 11 Once properly installed, the DU-520 Hi-Speed USB 2.0 5-Port PCI Adapter can be used to connect both USB 2.0 and USB 1.1 devices to any of its five USB ports. The diagram below shows a typical installation using the DU-520 and other USB devices.
- Page 12 To ensure optimal performance when using USB 2.0 devices, use a • USB 2.0 certified cable such as the DUB-C5AB. • The DU-520 will work in Macintosh OS 8/9 at USB 1.1 speeds using the built-in drivers for the appropriate operating system.
-
Page 13: Technical Support
Monday to Friday 8:30am to 9:00pm EST D-Link Technical Support over the Internet: http://support.dlink.ca email:support@dlink.ca ©2002 D-Link Systems, Inc. All rights reserved. Trademarks or registered trademarks are the property of their respective holders. Software and specifications subject to change without notice. DU-520.03062003...
