kincrome Evolution K7963 Operation Manual

Tool Trolley
Operation Manual
IMPORTANT:
Parts List
Included
Keys x 2
Trolley Handle x 1
Tools & Assistance
Required for Trolley:
This operating manual contains important safety information,
read carefully & understand all information before operating
the trolley. Save this manual for future use.
4 x Hex 5mm
13mm x 24 Bolts
Bolts for
(24) for Castors
Trolley Handle
(with Washers)
2 People
13 Drawer Extra Wide
1350mm (53")
Measurements:
(External - With Castors - 125 x 50mm (5 x 2") x2 Locking)
WIDTH
1347 mm
Measurements - Top Section
WIDTH
1347 mm
Large Shallow Drawers (Left)
WIDTH 566 mm
Large Deep Drawers (Left)
WIDTH 566 mm
Large Shallow Drawers (Right)
WIDTH
566 mm
Large Deep Drawers (Right)
WIDTH
566 mm
Extra Large Top Drawer
WIDTH 1242 mm
Non-Locking
Castors (3)
For Castors:
13mm Spanner
1
Oversize
This product requires a two person lift
- use proper lifting techniques
Weight: 96kg
DEPTH HEIGHT
466 mm
DEPTH HEIGHT
466 mm
DEPTH 405 mm HEIGHT
DEPTH 405 mm HEIGHT
DEPTH HEIGHT
405 mm
DEPTH HEIGHT
405 mm
DEPTH 405 mm HEIGHT
Locking 14 x Liners
Castors (3)
For Handle:
5mm Hex Key
K7963
963 mm
15 mm
62 mm
104 mm
62 mm
104 mm
104 mm
