Quick User Guide
Charging
To ensure a long service life of the batteries, please ensure
that the hoist is left on charge when not in use.
To charge the AirRise260™, follow the following procedure:
• Place the hand control in the wall charger (Figure 1)
• Check if the indicator light lights up (Figure 2)
• Leave hoist on charge for about 8 hours.
To ensure the batteries are kept in good condition,
always put the hoist on charge after use. Never allow
the battery to fully discharge.
Hand Control
The plug of the hand control should be placed firmly in the input at the bottom of the
lift. The cord of the hand control can, if requested, be fitted with a strain release or
fixed with screw-thread.
Middle 2 buttons:
If the hoist is fitted with a electrically
powered spreader bar, these buttons enable
this to be used.
Bottom 2 buttons:
Turn the hoist on and off. When charging, the LED
indicators light up at the bottom of the hoist. Should
this be annoying, for example in a bedroom, this can be
turned off with the red button. There is also the option of a
bedroom mode, with which the charging indicators switch
off automatically after 2 minutes.
Indicator light:
In the middle of the letter 'O' in INNOVA™, there
is an LED indicator light. This tells you when the
hoist is charging.
The most innovative
healthcare equipment in the world.
Top 2 buttons:
These control the hoist's lifting and
lowering
Figure 1:
The wall charger
Figure 2:
Charging indicator light
t
|
0345 034 1450
f
|
0345 034 1451
e | enquiries@innova.uk.com
www.innovacareconcepts.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Innova AirRise260
Summary of Contents for Innova AirRise260
- Page 1 To ensure a long service life of the batteries, please ensure that the hoist is left on charge when not in use. To charge the AirRise260™, follow the following procedure: • Place the hand control in the wall charger (Figure 1) • Check if the indicator light lights up (Figure 2)
- Page 2 The battery is not at critical level, but gives an indication that charging is desired. The batteries must be charged as described in section 2.3. RED STATUS The batteries have reached a critical level, the hoist must not be used, further discharge will damage the batteries. The batteries must be charged as described in section 2.3. Weight limit The weight limit of the AirRise260™ is 260kg (41 Stone). Emergency Pull Cord The hoist immediately stops all functions when the red emergency cord is pulled. If you continue to pull the cord, the spreader bar will slowly move downwards. This movement stops as soon as the cord is released. The AirRise260™ is now completely switched off. To re-activate the hoist, press the On button on the hand control. 0345 034 1450 The most innovative 0345 034 1451 e | enquiries@innova.uk.com healthcare equipment in the world. www.innovacareconcepts.com...
