INSTRUCTION AND
MAINTENANCE MANUAL
OVIJECTOR
HAND HELD SELF-FILLING REPEATER SYRINGE
ADJUSTABLE DOSAGE
MK1
0.1ml • 0.2ml • 0.3ml • 0.4ml • 0.5ml
0.6ml • 0.7ml • 0.8ml • 0.9ml • 1.0ml
MK2
0.5ml • 0.75ml • 1.0ml • 1.25ml • 1.5ml • 1.75ml • 2.0ml
MK3
1.0ml • 1.5ml • 2.0ml • 2.5ml • 3.0ml
3.5ml • 4.0ml • 4.5ml • 5.0ml
Advertisement
Related Manuals for Kaycee Ovijector
Summary of Contents for Kaycee Ovijector
- Page 1 INSTRUCTION AND MAINTENANCE MANUAL OVIJECTOR HAND HELD SELF-FILLING REPEATER SYRINGE ADJUSTABLE DOSAGE 0.1ml • 0.2ml • 0.3ml • 0.4ml • 0.5ml 0.6ml • 0.7ml • 0.8ml • 0.9ml • 1.0ml 0.5ml • 0.75ml • 1.0ml • 1.25ml • 1.5ml • 1.75ml • 2.0ml 1.0ml •...
- Page 2 Your Kaycee syringe is a hand- operated repeater syringe which has been designed for use with all oil and water-based vaccines. It is comfortable to handle and its ergonomic design allows long sessions without operator-fatigue. This accurate, robust and easy to...
- Page 3 2. Setting the dose The numbers on the dose knob show the dose amount in ml. In order to set the Ovijector to the dose required, twist the dose knob at the base of the handgrip. It will click into precise dose settings each complete turn.
- Page 4 3. Connect vaccine The self-filling Kaycee syringes can be fitted with: a. rear connector and tube feed into vaccine container b. Multifit bottle holder c. Cap assembly and bottle. Fit the PVC feed tube to rear connector and short vaccine feed needle to the other end of the tube.
-
Page 5: Maintenance
4. Maintenance Immediately after use, pump through with hot soapy water, followed by clean water. This is essential to ensure blockages do not occur due to a build-up of residue and to promote the long life of your instrument. Remove piston and lubricate ‘O’-ring with medicinal liquid paraffin or Caster oil and refit piston, do not interchange pistons between syringes as they are individually calibrated for accuracy. - Page 6 Parts list - Rear Connector Fitting PLEASE STATE VACCINATOR MODEL WHEN ORDERING OVIJECTOR (REAR CONNECTOR FITTING) Cat. No 10091 Luer lock stem 40mm 10092 Luer lock stem 60mm 10157 Fibre washer 10169 Valve spring 10170 Delivery valve (conical) 10182 Suction valve (semi-sphere)
- Page 8 Parts list - Cap Assembly Bottle PLEASE STATE VACCINATOR MODEL WHEN ORDERING OVIJECTOR (CAP ASSEMBLY BOTTLE) Cat. No Luer lock stem 40mm 10091 10092 Luer lock stem 60mm 10157 Fibre washer 10169 Valve spring Delivery valve (conical) 10170 Suction valve (semi-sphere)
- Page 10 Parts list - Multifit Bottle Holder PLEASE STATE VACCINATOR MODEL WHEN ORDERING OVIJECTOR (MULTIFIT BOTTLE HOLDER) Cat. No Luer lock stem 40mm 10091 Luer lock stem 60mm 10092 10157 Fibre washer 10169 Valve spring 10170 Delivery valve (conical) Suction valve (semi-sphere)
- Page 12 Distributor: www.kaycee.co.uk Visit our website to see our full range of syringes and accessories...
