- Page 1 INSTRUCTION AND MAINTENANCE MANUAL AVIJECTOR HAND HELD SELF-FILLING REPEATER SYRINGE ADjUSTAbLE DOSAgE MK25 0.25ml • 0.5ml • 1.0ml...
- Page 2 Your Kaycee syringe is a hand- operated repeater syringe which has been designed for use with all oil and water-based vaccines. It is comfortable to handle and its ergonomic design allows long sessions without operator-fatigue. This accurate, robust and easy to...
- Page 3 Allow to cool, refit handle and pump out water. 2. Setting the dose In order to set the Avijector to the dose required, fit the piston crosshead in the keyhole dose slot (0.25/0.5/1.0ml) of your choice on the side arm...
- Page 4 3. Connect vaccine The self-filling Kaycee syringes can be fitted with: a. rear connector and tube feed into vaccine container b. Multifit bottle holder c. Cap assembly and bottle. Fit the PVC feed tube to rear connector and short vaccine feed needle to the other end of the tube.
-
Page 5: Maintenance
4. Maintenance Immediately after use, pump through with hot soapy water, followed by clean water. This is essential to ensure blockages do not occur due to a build-up of residue and to promote the long life of your instrument. Remove piston and lubricate ‘O’-ring with medicinal liquid paraffin or Caster oil and refit piston, do not interchange pistons between syringes as they are individually calibrated for accuracy. - Page 6 Parts list - Rear Connector Fitting PLeAse sTATe vAccINATOR mODeL WHeN ORDeRING AVIJECTOR (REAR CONNECTOR FITTING) Cat. No 10091 Luer lock stem Fibre washer 10157 10169 Valve spring 10170 Delivery valve (conical) Suction valve (semi-sphere) 10182 10194 Trigger screw 10200...
- Page 8 Parts list - Cap Assembly Bottle PLeAse sTATe vAccINATOR mODeL WHeN ORDeRING AVIJECTOR (CAP ASSEMBLY BOTTLE) Cat. No 10091 Luer lock stem Fibre washer 10157 10169 Valve spring 10170 Delivery valve (conical) Suction valve (semi-sphere) 10182 10194 Trigger screw 10200...
- Page 10 Parts list - Multifit Bottle Holder PLeAse sTATe vAccINATOR mODeL WHeN ORDeRING AVIJECTOR (MULTIFIT BOTTLE HOLDER) Cat. No 10091 Luer lock stem Fibre washer 10157 10169 Valve spring 10170 Delivery valve (conical) Suction valve (semi-sphere) 10182 10194 Trigger screw 10200...
- Page 12 Distributor: www.kaycee.co.uk Visit our website to see our full range of syringes and accessories...
