Congratulations on choosing a HERA product!
We thank you for your custom.
Please note that this product, as all the others in the rich HERA range, has been designed and made with total quality to ensure excellent performance and best meet your
expectations and requirements. Carefully read this instruction manual in its entirety and keep it safe for future reference. It is essential to know the information and comply
with the instructions given in this manual to ensure the fitting is installed, used and serviced correctly and safely. HERA disclaims all liability for damage to the fitting or to
other property or persons deriving from installation, use and maintenance that have not been carried out in conformity with this instruction manual, which must always
accompany the fitting. HERA reserves the right to modify the characteristics stated in this instruction manual at any time and without prior notice.
MPX6 RGB SERIES
User's Manual & Installation Guide
5
6
9
10
www.heraled.com
Standart DMX Wiring Diagram
Installation Instruction
Ordering Information
Accessories & Recommended Products
Back Cover
V.1.0
Advertisement
Table of Contents
Related Manuals for HERA MPX6 RGB SERIES
Summary of Contents for HERA MPX6 RGB SERIES
- Page 1 We thank you for your custom. Please note that this product, as all the others in the rich HERA range, has been designed and made with total quality to ensure excellent performance and best meet your expectations and requirements. Carefully read this instruction manual in its entirety and keep it safe for future reference. It is essential to know the information and comply with the instructions given in this manual to ensure the fitting is installed, used and serviced correctly and safely.
-
Page 2: Safety Information
Waste Electrical Shock Manual. Illumination and Electronic Equipment Warranty Hera warrants the products for a period of five (5) years from date of purchase, provided that the purchased items are used under the conditions stated in this user manual. Marking www.heraled.com... - Page 3 Explanation MPX6 RGB Series are used in project such as media facades lighting, outdoor video display where high brightness and standard pixel pitch distance is needed. Splendid effects can be animated with large fixtures without limitation of geometry, shape and range.
-
Page 4: Product Specifications
MPX6 RGB SERIES Product Specifications Model Direct View Diffused View Light Source: 6pcs High intensity 3 in 1 Chip RGB LEDs Lumen Maintenance: 60.000+ hours L70 @ 25° C (full output) Color Range: 16.7 Million additive RGB colors Color Resolution:... - Page 5 MPX6 RGB SERIES Connection Diagram Connection Diagram Connection Diagram Standart DMX Wiring Diagram Indoor Zone Ethernet AC Input RISK OF ELECTRIC SHOCK 3 Pin VDE RJ45 90~264VAC 50/60Hz RJ45 DMX 1 DMX 2 DMX 3 DMX 4 DMX 5 DMX 6...
-
Page 6: Installation Instruction
MPX6 RGB SERIES Installation Instruction Installation Instruction Warning! *Do not bend the cable. * Minimum clearance from dot 20mm/0.79” *Do not twist the cable. * Install the product without stretching the cable. * Make space as 20mm cap. www.heraled.com... - Page 7 MPX6 RGB SERIES Installation Instruction Install with the proper screw to the montage area. Install cable cap by isolating the cable with RTV silicon to protect last product cables after montage. P20043 MPX Cable Cap With Plastic Cable Tie Assembly Montage with plastic cable tie as shown in the figure.
- Page 8 MPX6 RGB SERIES Installation Instruction With Mesh Installation Apply P20050 Steel Rope Mounting Bracked apparatus on mesh implementation by following the steps as shown in the figure. Recommended Steel Rope Thicknees 1,5mm P20044 MPX Series For Dome Accessories Assembly www.heraled.com...
-
Page 9: Ordering Information
MPX6 RGB SERIES Ordering Information P01012085 MPX6-RGB 100mm pitch 40 Pixel & 5m Leader Cable Sets P01013085 MPX6-RGB 200mm pitch 40 Pixel & 5m Leader Cable Sets P01014085 MPX6-RGB 300mm pitch 40 Pixel & 5m Leader Cable Sets P01015085 MPX6-RGB 400mm pitch 40 Pixel & 5m Leader Cable Sets P01016085 MPX6-RGB 500mm pitch 40 Pixel &... - Page 10 www.heraled.com...
