QUICK SETUP GUIDE
Portable Speaker
with Power Bank
NS-SPBTBRICK2 / NS-SPBTBRICK2-XX
PACKAGE CONTENTS
• Bluetooth speaker
• USB charging cable
• Quick Setup Guide
FEATURES
• Stereo speakers
• Wirelessly stream from any Bluetooth device
• Rechargeable battery lasts up to 40 hours
• Integrated power bank charges your mobile devices
• Water-resistant body
Back view
Bluetooth
Power button
LED
Call button
Volume +/-
buttons
Charging and
battery
power LED
Before using your new product, please read these instructions to prevent any damage.
IMPORTANT SAFETY INSTRUCTIONS
• Read these instructions.
• Keep these instructions.
• Heed all warnings.
• Follow all instructions.
• Do not use this speaker near water.
• Clean only with a dry cloth.
• Do not block any ventilation openings. Install in accordance with the
manufacturer's instructions.
• Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat.
• Only use attachments/accessories specified by the manufacturer.
• Unplug this speaker during lightning storms or when unused for long
periods of time.
• Refer all servicing to qualified service personnel. Servicing is required
when the speaker has been damaged in any way, such as if the
speaker is dropped, exposed to liquids, or does not operate normally.
• Never expose the product to fire as this could result in personal
injury.
• Do not store the product in an extremely cold or warm environment.
• Never dismantle the product.
• Never let children play with the product.
• Do not expose the product to dampness or moisture.
• The product should not be exposed to dripping or splashing.
• Pay attention to the environmental aspects of battery disposal.
• Do not expose the speaker's battery to excessive heat such as
sunshine or fire.
Power
bank
• CAUTION: Danger of explosion if the battery is incorrectly placed. Do
button
not try to replace the battery.
Micro USB
port
DC OUT
AUX in jack
CHARGING YOUR SPEAKER
1 Open the port cover on the back of your speaker.
2 Connect the small end of the charging cable to the micro USB port on
the back of your speaker.
3 Connect the other end to a USB port on a USB wall charger or your
computer.
4 To check the battery level, press the
(Power bank button).
Note: The speaker beeps when the battery is low. About five minutes later, the
speaker turns off automatically.
CHARGING LED
DESCRIPTION
Blinks white
Charging
Solid white
Fully charged
CHARGING AN EXTERNAL DEVICE
1 Open the port cover on the back of your speaker.
2 Plug one end of a USB cable into your external device and the other
end into the DC OUT port on your speaker.
3 Press and hold the
(Power bank button). Your external device
charges.
CONNECTING AN AUDIO DEVICE
Bluetooth
1 Press and hold
(power) to turn on your speaker. The Bluetooth LED
indicator blinks blue quickly and your speaker automatically enters
pairing mode.
2 Make sure that your Bluetooth device is within 33 ft. (10 m) of your
speaker.
3 Turn on your Bluetooth device, turn on Bluetooth, then enter pairing
mode. For more information, see the documentation that came with
your Bluetooth device.
4 On your Bluetooth device, select NS-SPBTBRICK2. Your speaker
pairs with your Bluetooth device and the Bluetooth LED indicator
lights solid blue.
5 To disconnect, un-pair your Bluetooth device from your speaker.
OR
Press and hold
(call) for three seconds on your speaker. Your
Bluetooth device loses connection automatically.
BLUETOOTH LED
DESCRIPTION
Blinks blue
Speaker is in pairing mode
Solid blue
Speaker is connected to Bluetooth device
Blinks blue slowly
Speaker is connected to an AUX device
Audio cable
• Connect a 3.5 mm audio cable (not included) from your speaker's
AUX jack to your audio device's headphone/audio out jack.
RECONNECTING TO A PAIRED DEVICE
When your speaker is not paired to a device, the LED blinks blue.
Your speaker loses the
Bluetooth connection if you...
To reconnect...
Turn off your speaker.
Turn on your speaker. Your speaker searches
for the last connected Bluetooth device and
reconnects.
Move the Bluetooth device out
Make sure that your Bluetooth device is
of range.
within 33 feet of your speaker.
Turn off your Bluetooth device.
Turn on your Bluetooth device, then make
sure that Bluetooth is on.
Turn off Bluetooth on your
Turn on Bluetooth on your Bluetooth device.
Bluetooth device.
Connect your Bluetooth device
Disconnect your Bluetooth device from the
to another Bluetooth device.
other Bluetooth device, then set your device
to pairing mode. Select NS-SPBTBRICK2 on
your Bluetooth device.
Note: The Bluetooth range (33 ft./10 m) may be reduced if the wireless signal
has to pass through walls or other obstructions.
