Sunex Tools 8013ADLX Manual

PARTS BREAKDOWN

AlSO AVAIlABlE
Part # Description
RS3DHDL Short Chrome Drawer Handle
RS3DHDLB Short Black Drawer Handle
RS8006HDL Long Chrome Drawer Handle
RS8006HDLB Long Black Drawer Handle
RS8006HDLS Handle Screws (Set of )
RSRBSLIDEC2 Clip-On Roller Bearing Slide/pr.
8006RB Red Replacement Large Drawer
8006CRBBK Black Replacement Large Drawer
8006CRBBL Blue Replacement Large Drawer
8006CRBY Yellow Replacement Large Drawer
8016 Red Replacement 3 Drawer Unit
8016BK Black Replacement 3 Drawer Unit
8016BL Blue Replacement 3 Drawer Unit
8016Y Yellow Replacement 3 Drawer Unit
8007 Red Replacement Third Shelf
8007BK Black Replacement Third Shelf
8007BL1 Blue Replacement Third Shelf
8007Y Yellow Replacement Third Shelf
8013LS -Piece Lock & Key Set, Keyed Alike
1110 EVA Foam for Trays / 10-pk.
1111 EVA Foam for Drawers / 10-pk.
800SSM Rubber Liner for Side Shelf / 10-pk.

REPlAcEmENT PARTS lIST

Item Part # # Req'd
1 * 2
2 RSSCPLW 2
3 RSSCPW 2
 RSSCPP1 1
5 RSSCPHK 1
6 8011 1
8011BK
8011BL
8011Y
* For replacement, purchase RSSC7, Chrome Leg, and 8014, Leg Extensions.
8013ADLX: Parts Breakdown & Operating Manual
INCLUDES PRY BAR HOLDER AND SIDE WORK BENCH
7
5
Description
Chrome Leg/ea.
Locking Caster/ea.
Non-Locking Caster/ea.
Set of  Plastic Inserts
Bolt Kit (Incl. 8 ea. of 10mm and 1mm
bolts, nuts, washers and  screws)
Red Pry Bar Holder
Black Pry Bar Holder
Blue Pry Bar Holder
Yellow Pry Bar Holder
MODEL 8013ADLX / 8013ABKDLX
8013ABLDLX / 8013AYDLX
LOCKING TOP & DRAWERS
3
7
8

SERVICE CART WITH
1
8

800 1 Red Side Work Station
800BK Black Side Work Station
800BL Blue Side Work Station
800Y Yellow Side Work Station
8002 1 Red Top Lid
8002BK Black Top Lid
8002BL1 Blue Top Lid
8002Y Yellow Top Lid
1
6
2
rev. 082107
