OPERATING MANUAL
THIS OPERATING MANUAL CONTAINS IMPORTANT SAFETY INFORMATION.
READ CAREFULLY AND UNDERSTAND ALL INFORMATION BEFORE OPERATING
THIS CART. SAVE THIS MANUAL FOR FUTURE USE.
PARTS LIST
Examine box contents, then proceed with following instructions.
Locking Drawer Assembly
Bottom Tray
Read and follow all instructions in User's Manual. • Maximum load
capacity 350 lbs. • Units can tip or strike you causing personal injury.
• Do not open more than one loaded drawer at a time. • Lock lid and
drawers before moving. • Do not stand on or step in drawers. • Apply
brake on locking casters anytime cart is in place. • Move cart slowly
when loaded, avoid cracks, holes and other floor irregularities. • Do
not pull; push to move. • Improper moving or loading can cause injury.
• Failure to heed these warnings may result in personal injury and/or
property damage.
WARNING: This product can expose you to chemicals including
nickel, which is known to the State of California to cause cancer and
birth defects or other reproductive harm. For more information go to
www.P65Warnings.ca.gov.
8013ADELUXE/8013ABKDELUXE/8013ABLDELUXE
SERVICE CART WITH LOCKING TOP & DRAWERS
Chrome Legs (2)
(With Inserts Installed)
Long Drawer Handle (1)
Drawer Handle
Screws (14)
WARNING
MODEL 8013ADELUXE / 8013ABKDELUXE /
INCLUDES PRY BAR HOLDER AND SIDE WORK BENCH
Non-Locking Casters (2)
Keys
(Attached
to Legs)
Short Drawer Handles (4)
TOOLS NEEDED
Rubber Mallet
Table or Workbench
8013ABLDELUXE
Locking Casters (2)
Pry Bar Holder
Side Work Bench
Phillips Head
6mm Wrench
Screwdriver
2 People
© Copyright 2018, Sunex Tools
M6x42 Bolts,
Nuts, & Washers
(8 Pcs. Each)
®
rev. 06/04/18
