- Page 1 OWNER’S MANUAL DVD MINI HI-FI SYSTEM Please read this manual carefully before operating your set and retain it for future reference. DM5430 (DM5430, DMS5430V) DM5330 (DM5330, DMS5330V) DM5230 (DM5230, DMS5230V)
- Page 2 Getting Started Getting Started Safety Information CAUTION CAUTION: This product employs a Laser System. RISK OF ELECTRIC SHOCK DO NOT OPEN To ensure proper use of this product, please read this owner’s manual carefully and retain it for future CAUTION: TO REDUCE THE RISK OF ELECTRIC reference.
- Page 3 Getting Started This device is equipped with a portable battery or accumulator. Safety way to remove the battery or the battery from the equipment: Remove the old battery or battery pack, follow the steps in reverse order than the assembly. To prevent contamination of the environment and bring on possible threat to human and animal health, the old battery or the battery put it in the appropriate...
-
Page 4: Table Of Contents
Table of Contents Table of Contents – OTHERS Operating Basic Operations Getting Started – Disc/USB Operations Safety Information Other Operations Unique Features – Displaying Disc Information on-screen Accessories – To display the DVD Menu Introduction – To display the DVD title –... - Page 5 Table of Contents Troubleshooting Troubleshooting Appendix Specifications Maintenance – Handling the Unit – Notes on Discs Trademarks and Licenses Language Codes Area Codes...
-
Page 6: Getting Started
Getting Started Unique Features Introduction Playable Discs USB Direct Recording Records music to your USB device. This unit plays DVD±R/RW and CD-R/RW that contains audio titles, DivX, MP3, WMA and/or JPEG files. Some DVD±RW/DVD±R or CD-RW/ Accessories CD-R cannot be played on this unit due to the recording quality or physical condition of the disc, or the characteristics of the recording device and Please check and identify the supplied accessories. -
Page 7: Regional Codes
LG players when formatting rewritable discs. When setting the option to Live File > Caution System, you cannot use it on LG players. Indicates cautions for preventing possible damages (Mastered/ Live File System : Disc format system from abuse. -
Page 8: Usb Device Requirement
Getting Started USB device requirement DivX file requirement y Devices which require additional program DivX file compatibility with this unit is limited as installation when you have connected it to a follows : computer, are not supported. y Available resolution: up to 800 x 600 (W x H) pixels. -
Page 9: Remote Control
EQ ($) : You can choose sound time. impressions. POWER (1) : Switches the unit LG EQ (9) : Select a Natural or ON or OFF. Local Specialization equalizer OPEN/CLOSE (B) : Opens and effect by LG EQ. -
Page 10: Front Panel
Getting Started Front panel... - Page 11 Optimizes compressible MP3 files so that it f USER EQ improves the bass sound. g Selects DVD/CD function. o REC. Selects TUNER function. p LG EQ Selects USB function. You can choose fixed sound impression. Selects AUX function. h SET PRESET (+) Confirms the settings.
-
Page 12: Rear Panel
Getting Started Rear panel a AUX IN connector b VIDEO OUT connector c ANTENNA (FM, AM) d COMPONENT VIDEO OUT (PROGRESSIVE SCAN) connector e POWER IN f SPEAKERS terminals g Cooling Fan (Except DM5230) -
Page 13: Connecting
Connecting Connecting to Antenna Connection speakers Connect the supplied FM/ AM antenna for listening to the radio. Attaching the speakers to the unit To connect the cable to the unit, press each plastic finger pad to open the connection terminals on the unit. -
Page 14: Connections To Your Tv
Connecting Connections to Your Video Connection Connect the VIDEO OUT jack on the unit to the video in jack on the TV using a video cable. Make one of the following connections, depending on the capabilities of your existing equipment. Note y Depending on your TV and other equipment you wish to connect, there are various ways... -
Page 15: Component Video Connection
Connecting Optional Equipment Component Video Connection Connection Connect the COMPONENT VIDEO OUT (PROGRESSIVE SCAN) jacks on the unit to the corresponding input jacks on the TV using component cables. AUX In Connection You can hear the sound through the system’s speakers. -
Page 16: Usb Connection
Connecting USB Connection Connect the USB port of USB Memory (or MP3 player, etc.) to the USB port on the front of the unit. Note Removing the USB Device from the unit 1. Choose a different function/mode or press STOP (Z) twice in a row. 2. -
Page 17: Adjust The Setup Settings
System setting System setting Adjust the Setup To display and exit the Setup Menu settings 1. Select the DVD/CD or USB function by pressing FUNCTION. By using the Setup menu, you can make various 2. Press SETUP. adjustments to items such as picture and sound. Displays the [SETUP] Menu. -
Page 18: Language
System setting LANGUAGE DISPLAY TV Aspect Select a language for the Setup menu and then on Select which screen aspect to use based on the screen display. shape of your TV screen. [4:3] Disc Audio/Disc Subtitle/Disc Menu Select when a standard 4:3 TV is connected. Select the language you prefer for the audio track (disc audio), subtitles, and the disc menu. -
Page 19: Audio
System setting AUDIO LOCK (Parental Control) DRC (Dynamic Range Control) Initial Setting of the Area Code Make the sound clear when the volume is turned When you use this unit for the first time, you have down (Dolby Digital only). Set to [On] for this effect. to set the Area Code as shown below. -
Page 20: Others
System setting OTHERS Password You can enter or change password. DivX(R) Registration 1. Select [Password] on the [Lock] menu and then ABOUT DIVX VIDEO: DivX® is a digital video format press D. created by DivX,Inc. This is an official DivX Certified device that plays DivX video. -
Page 21: Operating
Operating Basic Operations Do this Stop Press Z. Playback Press d. Disc/USB Operations Pause During playback, press M. 1. Insert the disc by opening the Disc tray or connect the USB device to the USB port. Press M repeatedly to play title Frame-by-Frame Frame-by-Frame. -
Page 22: Other Operations
Operating Other Operations To display the DVD Menu When you play a DVD which contains several menu, Displaying Disc Information you can select the menu you want using the Menu. on-screen 1. Press MENU. The disc’s menu appears. You can display various information about the disc 2. -
Page 23: Starting Play From Selected Time
Operating Starting play from selected Creating your own program time You can play the contents of a disc in the order you want by arranging the order of the songs on To start playing at any chosen time on the file or the disc. -
Page 24: Viewing A Photo File As A Slide Show
Operating Viewing a PHOTO file as a Using your player as an alarm slide show clock 1. Turn the power on. 2. Press TIMER. Each functions flashes. 1. Highlight the file (not folder) which you like beginning slide show. 3. Press SET/CD M when the function you want to 2. -
Page 25: Sleep Timer Setting
Operating Sleep Timer Setting Turning off the sound temporarily Press SLEEP one or more times to select delay time between 10 and 180 minutes, after which the unit Press MUTE to mute your unit. turn off. You can mute your unit in order, for example, to To cancel the sleep function, press SLEEP answer the telephone, appears the “... -
Page 26: Using Microphone
Operating Using Microphone 1. Connect your microphone to the MIC 1, 2. 2. Play the music you want. 3. Sing along with the accompaniment. Adjust the microphone volume by pressing MIC VOL.. Note y When not using the microphone, set the MIC VOL. -
Page 27: Radio Operations
Operating Radio Operations Presetting the Radio Stations You can preset 50 stations for FM and AM. Before tuning, make sure that you have turned Be sure that both FM and AM aerials are connected. down the volume. (Refer to the page 13) 1. -
Page 28: Sound Adjustment
You can select a desired sound mode by using LG EQ/EQ You can listen to music with the desired sound You can change the LG EQ/EQ using A/D arrow effect by adjusting the BASS, MIDDLE and TREBLE. key while the sound effect information is displayed 1. -
Page 29: Advanced Operations
Operating Note Advanced Operations y You can check the recording percentage rate for the USB record on the display window during the recording. (MP3/ WMA Listening to music from your CD Only) external device y During recording MP3/ WMA, there is no sound. -
Page 30: Troubleshooting
Troubleshooting Troubleshooting Problem Cause & Correction y The power cord is not plugged in. Plug in the power cord. No Power. y The TV is not set to receive the DVD signal. Select the appropriate video input mode on the TV so the picture from the unit appears on the TV screen. No picture. -
Page 31: Appendix
Power supply Refer to main label. Power consumption Refer to main label. Net Weight 5.2 kg DM5430 DM5330 DM5230 External dimensions (W x H x D) 275 x 342 x 365 mm 275 x 334 x 365 mm 275 x 334 x 365 mm 5 °C to 35 °C (41 °F to 95 °F) - Page 32 Appendix Front Speakers Models DMS5430V DMS5330V DMS5230V Type 2 Way 2 Speaker 2 Way 2 Speaker 2 Way 2 Speaker Impedance 4 Ω 4 Ω 4 Ω Rated Input Power 130 W 50 W 30 W Max. Input Power 260 W 100 W 60 W Net Dimensions (WxHxD)
-
Page 33: Maintenance
Appendix Maintenance Notes on Discs Handling Discs Handling the Unit Never stick paper or tape on the disc. Storing Discs When shipping the unit After playing, store the disc in its case. Do not Please save the original shipping carton and expose the disc to direct sunlight or sources of heat packing materials. -
Page 34: Language Codes
Appendix Language Codes Use this list to input your desired language for the following initial settings: Disc Audio, Disc Subtitle, Disc Menu. Language Code Language Code Language Code Language Code French 7082 Lithuanian 7684 Sindhi 8368 Afar 6565 Singhalese 8373 Afrikaans 6570 Frisian... -
Page 35: Area Codes
Appendix Area Codes Choose an area code from this list. Area Code Area Code Area Code Area Code Afghanistan Fiji Monaco Singapore Argentina Finland Mongolia Slovak Republic France Morocco Slovenia Australia Austria Germany Nepal South Africa Belgium Great Britain Netherlands South Korea Bhutan Greece...
