- Page 1 MEC-FIR-M003 Mini PCI-e 1-port IEEE 1394A and 2-port 1394B board User’s Manual Third Edition, June 2014 © 2014 Cervoz Co., Ltd. All rights reserved. Reproduction without permission is prohibited...
- Page 2 Copyright Notice © 2014 Cervoz Co., Ltd. All rights reserved. Reproduction without permission is prohibited. Trademarks Cervoz is a registered trademark of Cervoz Co., Ltd. All other trademarks or registered marks in this manual belong to their respective manufacturers. Disclaimer Information in this document is subject to change without notice and does not represent a commitment on the part of Cervoz.
-
Page 3: Table Of Contents
Chapter 1 Introduction Overviews Features Installation Flowchart Package Checklist Chapter 2 Hardware Installation Chapter 3 Driver Confirmation Appendix Pin Assignments Board Side Pin Assignments Device Side Pin Assignments Technical Reference MEC-FIR-M003 Specifications MEC-FIR-M003 Dimensions MEC-FIR-M003 Daughter Board Dimensions Product Warranty Statement... -
Page 4: Introduction
Introduction Overview MEC-FIR-M003 is a FireWire card for embedded PC. The card follows the Mini PCI-e standard which is complaint with PCI Express x 1 classification and small form factor (30.00 x 50.95 mm). This board fits in any host computer that has Mini PCI-e card slots. -
Page 5: Installation Flowchart
Installation Flowchart Installation Flowchart of MEC-FIR-M003 The following flowchart provides a brief summary of the procedure you should follow to install the Mini PCI-e card: Hardware Installation Connect the internal cable Hardware Installation Install the card in the Mini PCI-e slot... -
Page 6: Hardware Installation
Hardware Installation This chapter describes the PCI Express Series hardware installation procedure. Since the BIOS automatically assign the PCI Express board’s IRQ number and I/O addresses, you must plug in the board before installing the driver. Step 1 Connect the internal cable to the card 1. - Page 7 Step 2 Install the card to the Mini PCI-e slot Make sure you install the card in the right position (fool-proof design) Step 3 Fix the card on the motherboard (clip type or screw type) There are 2 options to fix the card. It depends on the design of the motherboard (clip or screw).
- Page 8 Step 4 Card installation completed Step 5 Connect the cable to the daughter board Connect other side of the cable to the daughter board Both sides of the cable connectors are the same, it doesn’t matter which side Note you connect...
- Page 9 Step 6 Connect the power cable to the 4PIN power connector Connect the power cable to the big 4PIN power connector from the power supply Connector Fixation MECFIX – Versatile Mounting 1. Standard PCI/PCIe Bracket PCI / PCIe IO Bracket...
- Page 10 2. Low Profile PCI/PCIe Bracket Low Profile IO Bracket 3. Internal Mounting Upper Fixation – Industrial System...
- Page 11 Right & Left Fixation – Industrial System 4. Customized Front / Rear Plate Front / Rear I/O Plate Universal Bracket...
-
Page 12: Driver Confirmation
Driver Confirmation This chapter gives installation, configuration, and update/removal procedures for the driver for Win 2003, Win XP, Win Vista, Win 7, and Win 8.. Step 1 Turn on PC and start Windows Note XP OS as example... - Page 13 Step 2 Check if driver is detected Start “Computer Management” program Go to the route: → → → My Computer Manage Device Manager IEEE 1394 Bus host controller You would find driver name: OHCI Compliant IEEE 1394 Host Controller Device is ready to be used...
-
Page 14: Appendix
Appendix Pin Assignments ... -
Page 15: Board Side Pin Assignments
Board Side Pin Assignments Wire to Board Connector (CN23、CN24) Description Description +TPB0 +TPB2 -TPB0 -TPB2 +TPA0 +TPA2 -TPA0 -TPA2 +TPB1 -TPB1 +12V +TPA1 +12V -TPA1 +12V Power Input Connector (PWR_IN8) Description +12V Device Side Pin Assignments IEEE 1394A 6 pin Connector (1394A_1) Description +12V -TPB0... - Page 16 IEEE 1394B 9 pin Connector (1394B_1、1394B_2) 1394B_1 1394B_2 Description Description -TPB1 -TPB2 +TPB1 +TPB2 -TPA1 -TPA2 +TPA1 +TPA2 A shield A shield +12V +12V B shield B shield...
-
Page 17: Technical Reference
Technical Reference MEC-FIR-M003 Specifications General PCI-Express Revision PCI-Express Base Specification Rev 1.1 PCI-Express Electromechanical PCI-Express Mini Card Electromechanical Rev. 1.1 Revision Hardware Controllers LSI FW643E Single-Lane (x1) PCI-Express with throughput up to 2.5Gbps Interface (Connector) IEEE 1394A 1 (1394A) -
Page 18: Mec-Fir-M003 Dimensions
MEC-FIR-M003 Dimensions MEC-FIR-M003 Daughter Board Dimensions... -
Page 19: Product Warranty Statement
Limitation of Liability Cervoz’ liability arising out of the manufacture, sale, or supplying of the product and its use, whether based on warranty, contract, negligence, product liability, or otherwise, shall not exceed the original selling price of the product. The remedies provided herein are the customer’s sole and exclusive remedies.
