- Page 1 MEC-COM-M114 Mini PCI-e 4-port RS-232 serial board with power input User’s Manual Third Edition, February 2014 © 2014 Cervoz Co., Ltd. All rights reserved. Reproduction without permission is prohibited...
- Page 2 Copyright Notice © 2014 Cervoz Co., Ltd. All rights reserved. Reproduction without permission is prohibited. Trademarks Cervoz is a registered trademark of Cervoz Co., Ltd. All other trademarks or registered marks in this manual belong to their respective manufacturers. Disclaimer Information in this document is subject to change without notice and does not represent a commitment on the part of Cervoz.
-
Page 3: Table Of Contents
Table of Contents Chapter 1 Introduction Overviews Features Installation Flowchart Package Checklist Chapter 2 Hardware Installation Chapter 3 Software Installation Appendix Pin Assignments Board Side Pin Assignments Device Side Pin Assignments Technical Reference MEC-COM-M114 Specifications MEC-COM-M114 Dimensions Product Warranty Statement... -
Page 4: Introduction
Introduction Overview MEC-COM-M114 is a serial communication card for embedded PC. The card follows the Mini PCI-e standard which is complaint with PCI Express x 1 classification and small form factor (30.00 x 50.95 mm). This board fits in any host computer that has Mini PCI-e card slots. -
Page 5: Installation Flowchart
Installation Flowchart Installation Flowchart of MEC-COM-M114 The following flowchart provides a brief summary of the procedure you should follow to install the Mini PCI-e card: Hardware Installation Connect the internal cable Hardware Installation Install the card in the Mini PCI-e slot... -
Page 6: Hardware Installation
Hardware Installation This chapter describes the PCI Express Series hardware installation procedure. Since the BIOS automatically assign the PCI Express board’s IRQ number and I/O addresses, you must plug in the board before installing the driver. Step 1 Connect the internal cable to the card Connect the internal cable to the card Connect the power cable to the card The power cable will be needed if you wish to have the COM ports powered. - Page 7 Step 2 Install the card to the Mini PCI-e slot Make sure you install the card in the right position (fool-proof design) Step 3 Fix the card on the motherboard (clip type or screw type) There are 2 options to fix the card. It depends on the design of the motherboard (clip or screw).
- Page 8 Step 4 Card installation completed Step 5 Connect the power cable to the 4PIN power connector Connect the power cable to the big 4PIN power connector from the power supply...
- Page 9 Connector Fixation 1. Standard PCI/PCIe Bracket PCI / PCIe IO Bracket 2. Customized Front / Rear Plate Front / Rear I/O Plate Universal Bracket...
-
Page 10: Software Installation
Software Installation This chapter gives installation, configuration, and update/removal procedures for the driver for Win 2003, Win XP, Win Vista, and Win 7. Step 1 Turn on PC and start Windows Note XP OS as example... - Page 11 Step 2 Windows automatically detects the new device If the card is installed properly, system would detect the new device and the hardware wizard would start automatically. Select “No, not this time” Click “Next” Step 3 Insert CD Select “Install from a list or specific location (Advanced)” Click “Next”...
- Page 12 Select “Include this location in the search:” Click “Browse” Step 5 Browse for folder (Ex.: XP 32bit) Select the driver by route: My Computer -> CD or DVD drive -> MEC-COM-M114 -> Driver -> Win_XP -> Win_XP 32bit Click “OK”...
- Page 13 Step 6 Confirm driver folder Click “Next” Make sure you select the correct driver. Step 7 Installation in progress...
- Page 14 Step 8 Driver installation completed Driver installation is completed, click “Finish” Step 9 Confirm if driver is installed Start “Computer Management” program Go to the route: → → → My Computer Manage Device Manager Multi-port serial adapters You would find driver name: PCI Express Multiport Serial Adapter Device is ready to be used...
-
Page 15: Appendix
Appendix Pin Assignments Board Side Pin Assignments Wire to Board Connector (CN15) Wire to Board Connector (CN13) Description Description Description Description DCD_1 DCD_2 DCD_3 DCD_4 DSR_1 DSR_2 DSR_3 DSR_4 RXD_1 RXD_2 RXD_3 RXD_4 RTS_1 RTS_2 RTS_3 RTS_4 TXD_1 TXD_2 TXD_3 TXD_4 CTS_1... - Page 16 DB9 Male Connector-1/2 With Power Select (JP4) DB9 Male Connector-1 DB9 Male Connector-2 Pin 9 = +5V Short 1-3 Pin 9 = +5V Short 2-4 Pin 9 = +12V Short 3-5 or 5-7 Pin 9 = +12V Short 4-6 or 6-8 Pin 9 = RI Short 7-9（Default）...
-
Page 17: Device Side Pin Assignments
Device Side Pin Assignments RS232 Port DB9 Male Connector-1/2/3/4 DB9 Male DB9 Male DB9 Male DB9 Male Connector-1 Connector-2 Connector-3 Connector-4 Description Description Description Description DCD_1 DCD_2 DCD_3 DCD_4 RxD_1 RxD_2 RxD_3 RxD_4 TxD_1 TxD_2 TxD_3 TxD_4 DTR_1 DTR_2 DTR_3 DTR_4 DSR_1 DSR_2... -
Page 18: Technical Reference
Technical Reference MEC-COM-M114 Specifications General PCI-Express Revision PCI-Express Base Specification Rev 1.1 PCI-Express Electromechanical PCI-Express Mini Card Electromechanical Rev. 1.1 Revision Hardware Controllers OXPCIe954 (16C550C compatible) Single-Lane (x1) PCI-Express with throughput up to 2.5Gbps Hardware Controllers OXPCIe954 (16C550C compatible) -
Page 19: Mec-Com-M114 Dimensions
Regulatory Approvals CE, FCC EN 55022, EN61000-3-2, EN61000-3-3, FCC Part 15 Subpart B Class B En 55024, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, IEC 61000-4-11 Reliability MTBF 2,321,370 hr Warranty 3 years MEC-COM-M114 Dimensions... -
Page 20: Product Warranty Statement
Limitation of Liability Cervoz’ liability arising out of the manufacture, sale, or supplying of the product and its use, whether based on warranty, contract, negligence, product liability, or otherwise, shall not exceed the original selling price of the product. The remedies provided herein are the customer’s sole and exclusive remedies.
