Page 3
Dear Customer, Congratulations for choosing our G LAB product! MIDI 2 x LOOP (M2L) is a loops’ switcher controlled by MIDI interface (by Program Change or Control Change commands) or manually, by using the buttons on the top of the device. Using the MIDI commands it is also possible to mute the signal (e.g.
Page 4
Structure 1 - MIDI channel settings switcher 6 - LOOP 2 signal output (SEND) 2 - signal OUTPUT connector 7 - signal INPUT connector 3 - LOOP 2 signal input (RETURN) 8 - power supply connector 4 - LOOP 2 signal output (SEND) 9 - MIDI input 5 - LOOP 1 signal input (RETURN) 10 - MIDI copy (THRU)
Page 5
Scheme and signal path description M2L has true passive signal path (without signal boosting and buffering elements). Owing to this the M2L doesn’t influence the guitar tone (doesn’t change the tone and doesn’t cut the signal). It is recommended to use the switcher button to exclude from the effects’...
Page 6
Power supply M2L should be supplied from 9V (DC) external adaptor (efficiency 60 mA or more). Before plugging the power supply check the pin polarisation. ATTANTION!: Damage of the M2L caused by improper power supply causes the loss of the warranty. Possible using of the M2L Below are shown the possible schemes of M2L connection with the guitar system.
Page 7
Scheme of M2L connection to the amp’s effect loop...
Page 8
Scheme of extending GSC with two effect loops...
Page 10
Two stereo effects’ switcher (TRUE BYPASS)
Page 11
Parameters: Dimensions (depth x width x height) 205 x 70 x 38 mm Weight 450 g Maximal input signal 30 dBu Power supply 9V DC (8,7 do 9,4V), 60mA...
Page 13
ELZAB S.A., ul. Kruczkowskiego 39, 41-813 Zabrze, Poland, hereby declares on own responsibility that the following product: MIDI 2 x LOOP (G LAB M2L) that is covered by this certificate and marked with CE 07 label conforms with following standards:...
Page 14
DO NOT PLACE THIS PRODUCT INTO THE WASTE CONTAINER ! This device is marked with a cross-lined waste container symbol according to 2002/96/EU Directive on Waste Electric and Electronic Equipment. Such marking informs that after usage equipment can not be trashed together with other household waste.
