- Page 1 User Manual TL-DA12-HD2 1x2 HDMI Splitter & Distribution Amplifier All Rights Reserved Version: TL-DA12-HD2_160926...
- Page 2 TL-DA12-HD2 User Manual Preface Read this user manual carefully before using this product. Pictures shown in this manual are for reference only; the actual product may vary. This manual is only for operation instruction only and not for any maintenance or repair.
- Page 3 TL-DA12-HD2 User Manual SAFETY PRECAUTIONS To insure proper operation, please read all instructions carefully before using the device. Save this manual for further reference. l Unpack the equipment carefully and save the original box and packing material for possible future shipment l Follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons.
-
Page 4: Table Of Contents
TL-DA12-HD2 User Manual Contents 1. Introduction ............................. 5 1.1 Introduction toTL-DA12-HD2 ..................5 1.2 Features ..........................5 1.3 Package List .......................... 5 2. Panel Description ........................... 6 3. System Connection ........................8 3.1 Usage Precautions ....................... 8 3.2 System Diagram ........................8 3.3 Connection Procedures ..................... -
Page 5: Introduction
1. Introduction 1.1 Introduction to the Product The TL-DA12-HD2 is a 1x2 splitter featuring the capability to repeat HDMI or DVI source to two displays simultaneously. Compliant with HDMI 2.0 and HDCP 2.2, the TL- DA12-HD2 provides comprehensive resolution capacities up to 4K@60 4:4:4 and 1080p with 3D. -
Page 6: Panel Description
Micro USB port; connect a DC 5V power adapter for power or plug a USB drive for firmware updates ④ DC 5V Note: Firmware updates require auxiliary equipment; please contact TechLogix for additional details. HDMI output ports. Connects to HDMI displays, automatically OUT1& ⑤ capturing the input resolution. - Page 7 TL-DA12-HD2 User Manual Note: Output HDCP compliancy status depends on the input signal. When the input signal is HDCP compliant, then output signal will be HDCP compliant and vice versa. a) Pictures shown in this manual are for reference only.
-
Page 8: System Connection
Step2. Connect HDMI displays to the HDMI OUTPUT sockets of TL-DA12-HD2 with high-quality HDMI cables. Step3. Connect the DC 5V power adapter to the power port of TL-DA12-HD2. Note: All the ports support hot-plug. Please note that hot plugging a display may result in screen splashing at the output ends. -
Page 9: Edid Management
TL-DA12-HD2 User Manual 3.4 EDID Management The TL-DA12-HD2 comprises of one HDMI input port and two HDMI output ports. EDID management helps distribute and route signals from the source at the resolution of the first detected display (detecting from output 1 or 2). -
Page 10: Specification
TL-DA12-HD2 User Manual 4. Specification I/O Connections HDMI Input One (1) HDMI Type A receptacle HDMI Outputs Two (2) HDMI Type A receptacle Power DC 5V 2A Supported Video and Audio 480i, 480p, 576i, 576p, 720p, 1080i, 1080p, Resolutions 1080p 3D, 4Kx2K (24, 25, 30, 60 Hz) Video Compliance HDMI 2.0, HDCP 2.2, DVI 1.0... -
Page 11: Supported Input Video Formats
TL-DA12-HD2 User Manual Power, ESD, Regulatory 6.5W Maximum Power Consumption 15KV ESD Protection CE, FCC Regulatory Other Standard Warranty 3 Year 1 Power, 1 Input status, 2 Output connection Indicators status Installation guide, Power adaptor, Mounting “L” Included Items brackets (2 ea), Mounting screws (4 ea), Plastic cushions (4 ea) 4.1 Supported Input Video Formats... -
Page 12: Panel Drawing
TL-DA12-HD2 User Manual 5. Panel Drawing www.tlnetworx.com... -
Page 13: Troubleshooting & Maintenance
Static becomes stronger Check the grounding and when connecting the Bad grounding make sure it is connected video connectors well. If your problem persists after following the above troubleshooting steps, please contact your authorized reseller or TechLogix technical support. www.tlnetworx.com... -
Page 14: After-Sales Service
No certificate or invoice as the proof of warranty l Damage caused by force majeure l Non-authorized service 3) Technical Support: When contacting TechLogix support, please have the following information available: l Product part number l Installation and sale date l Detailed failure information www.tlnetworx.com...
