Techlogix HomPro HP-ACVT-DA2 User Manual

This Digital to Analog Audio Converter is designed for either home or professional audio switching. It
converts Coaxial or Toslink digital audio signals to analog L/R audio and available for connection to an
external device such as an amplifier via standard RCA-style jacks. This Converter is small in size and quite
easy to install.
1.0 Features
This Converter has many features that enable it to perform in a superior manner. Among those features you
will find:
1. Converts Coaxial or Toslink digital audio signals to analog L/R audio
2. Supports sampling rate at 32, 44.1, 48 and 96 KHz.
3. 24-bit SPDIF incoming bit stream on left and right channels
4. Provides electromagnetic-noise-free transmission.
5. Easy to install and simple to operate.
2.0 SPECIFICATIONS
Signal Inputs/Output
Input Audio
Output Audio
Connector
Input audio connector
Output audio connector
Sampling rate
Size(L-W-H)
Weight (Net)
Power Requirement
External Power Supply
Power Consumption
3.0 PACKAGE CONTENTS
Before attempting to use this unit, please check the packaging and make sure the following items are
contained in the shipping carton:
1). Main unit (Digital to Analog Audio Converter).
2). DC 5V Power Supply
3) User's Manual.
HP-ACVT-DA2 USER MANUAL
Digital to Analog Audio Converter
Coaxial or Toslink digital audio
L/R audio and 3.5mm
Toslink、1XRCA(Coaxial)
2XRCA（R/L）+ Headphone
32, 44.1, 48 and 96 KHz
55X60X22MM
78g
5V DC@<1A>
0.5 watts (max)
