70MHz HIGH VOLTAGE DIFFERENTIAL PROBE
USER'S MANUAL [LDP-6010]
This probe is in compliance with IEC-61010-031 CAT. I, Pollution Degree 2.
1. Safety Terms and Symbols
Terms appear in this manual:
Symbols appear on the product:
Danger
High Voltage
2. General Safety Summary
Review the following safety precautions to avoid injury and prevent damage to this probe
or any products that connected to it.
Observe Maximum Working Voltage
To avoid any injury, do not use the probe under the condition that the voltage between either
input lead or earth is above 2500Vrms CAT II or above 5000Vrms CAT I between two
inputs. This voltage rating applies to both of 1/100 & 1/1000 settings.
_______________________________________________
WARNING. Warning statements identify conditions or practices
that could result in injury or loss life.
_______________________________________________
CAUTION. Caution statements identify conditions or practices that
could result in damage to this product or other property.
Protective
(Earth) Terminal
1
Attention
Refer to Manual
