- Page 1 012243EN Operating Instruction Booklet Pneumatic Screwdriver 347-218U 397060 A 347-318U 397060 B 347-518U 397060 C 347-618U 397060 D MINIMAT...
-
Page 2: Table Of Contents
We kindly ask that you read these operating instructions carefully so that you will be able to use this tool safely and for many years to come. If you need additional information, please contact your DEPRAG Representative, one of our international support offices or us direct at DEPRAG. -
Page 3: Safety Tips
Safety Tips 1.1. General Safety Tips Before operating tool make sure to carefully read and observe this operating instruction. Generally, the operator of the equipment and/or machinery is responsible for the equipment’s perfect condition and operation, while observing all necessary safety regulations. -
Page 4: General Safety Tips For Pneumatic Screwdriver Spindles
1.2. General Safety Tips for Pneumatic Screwdriver Spindles · Disconnect the tool from the air supply, when changing bits or when readjusting clutch. · Do not wear wide clothing or jewelry, for they can be seized by movable parts. Wear a hairnet if operator has long hair. ·... -
Page 5: Owner Obligation
1.3. Owner Obligation The owner is obliged to only let persons operate the equipment, who · are familiar with basic work environment safety rules and accident- preventing regulations. Also, those persons must have been instructed in the correct use of the equipment. ·... -
Page 6: Warranty And Liability
1.5. Warranty and Liability Unless otherwise specified, our “General Sales and Delivery Conditions” apply. Warranty and liability claims in regards to persons or equipment damages are invalid, if one or several of the following causes apply: · Use of the equipment in a non-designated application. ·... -
Page 7: Symbol Description
1.6. Symbol Description Read and observe the Operating Instruction Booklet, prior to and during operation of tool. DANGER Reference to an immediate danger to a person. May lead to serious injuries or even death if unobserved! Properly recycle environmentally damaging grease, cooling agents or detergents. - Page 8 Maintenance and repair on hydraulic and pneumatic equipment may only be performed by specially trained personnel! Disconnect equipment from air supply, prior to repair of pneumatic or hydraulic equipment. Provide regular preventive maintenance on hoses and airlines. Exchange hose lines, even if there is no visible damage! (Observe corresponding requirements of the manufacturer!) After repair and maintenance, check the following items: ·...
-
Page 9: Observe Environmental Regulations
Such materials must be stored, transported, contained and recycled in suitable containers. Designated Equipment Use DEPRAG MICROMAT / MINIMAT-Screwdrivers of straight shape are used for manual torque-controlled assemblies, preferably for vertical applications. -
Page 10: Installation
The hose length should not exceed 2 meters. · All DEPRAG Screwdrivers may be operated either with or without lubricated air (see paragraph: Maintenance and Upkeep). Best results are achieved, when machine is lubricated with 1 – 2 drops of oil per 1m... - Page 11 In regards to air-quality according to ISO8573-1, we recommend: LASS ESIDUE ESIDUE OF ESIDUE OF ATER Content Particle Concentration Dew Point Pressure Size mm mg/m³ max. mg/m³ Concentration max. g/m³ Lubricated Air Dry Air 0,88 Picture: Connection of a DEPRAG MINIMAT-Screwdriver...
- Page 12 Recommended Accessories Balancer, spring loaded EIGHT APACITY ENGTH EIGHT – (kg) (kg) FROM 0 – 0,5 827676 A 0,3 – 1,2 827677 A 1 – 2 827678 A 2 – 3 808690 A Hose Balancer, spring loaded EIGHT APACITY ONNECTION EIGHT I.D.
-
Page 13: Operation
If necessary, exchange clutch spring. The required torque adjustment can be checked, using a DEPRAG Torque Wrench or Measuring Platform (see DEPRAG catalogs D 3020 and D 3022). This equipment can also be used to re-adjust the torque of the Screwdriver. - Page 14 Pull off lock ring. Remove clutch spring, replace with new clutch spring and reassemble clutch in reverse order. Insert clutch into clutch bearing and tighten clutch bearing to DEPRAG- Screwdriver (left-hand thread). NOTICE The claw of the clutch must engage with the claw of the...
-
Page 15: Torque Adjustment
4.2. Torque Adjustment For an external torque adjustment use the following steps: Disconnect the screwdriver from air supply. Insert the supplied hand screwdriver 326240 through the slot on the motor housing into the half-round bore of the lock ring. By turning the hand screwdriver 326240 clockwise (-), the torque is reduced and by turning it counter-clockwise (+), the torque is increased. -
Page 16: Handling
Handling The operation of the DEPRAG MINIMAT-Screwdriver is very simple. Grip the Screwdriver as illustrated on the picture “Connection of a DEPRAG MINIMAT- Screwdriver”. As soon as you put the bit onto the screw and slightly push the screwdriver down, it will start running. After reaching the preset torque, the automatic clutch will disengage and turn off the Screwdriver. -
Page 17: Assembly - Disassembly
After repair or maintenance, verify that equipment runs to specification! Principally, use only DEPRAG original spare parts. Otherwise, a reduction in equipment power-output and an increased maintenance-requirement occurs. If NON-DEPRAG parts are installed, DEPRAG is justified to void any existing warranty and liability obligations. ATTENTION... -
Page 18: Special Repair Tools (Optional Equipment)
Pull off air connecting-side bearing cover from rotor. f. Press the two ball bearings from the bearing covers. Assembly: Use the DEPRAG Grease 807293 (100-g tube) to grease the ball bearing, needle bearing and gearing parts prior to reassembly. -
Page 19: Correct Assembly Of Shut-Off Function On Clutch
6.2. Correct Assembly of Shut-Off Function on Clutch ATTENTION If the stop-pin is installed incorrectly, the clutch will NOT shut -off. In between the two curves, the taper of the stop pin has to point towards the outside (as illustrated in the pictures below). Curves Taper on Stop Pin... -
Page 20: Spare Part Drawings
6.3. Spare Part Drawings... -
Page 27: Dimensional Drawing
6.4. Dimensional Drawing... -
Page 28: Maintenance And Upkeep
6 months (single shift). · Exchange broken or worn inserting tools immediately, for they can cause injury to the Operator. · If tool malfunctions, we recommend to send the machine to DEPRAG. 7.1. Wear Parts UANTITY... -
Page 29: Trouble Shooting
Maintain air pressure of 90 PSI shut-off or for required torque ratchets value Valve Pin is too long Check length of valve pin, either shorten or replace valve pin (picture: Actual Size of Valve Pin) If necessary, please send tool to DEPRAG for service. -
Page 30: Delivery Capacity
Picture: Actual Size of Valve Pin Attention: When connecting to compressed air supply valve pin may be catapulted out which may cause serious injuries. When verifying the actual size of the valve pin, make sure N O T to hold the screwdriver directed towards yourself or any other person. -
Page 31: Accessories - Optional Equipment
You will find suitable inserting tools · in our brochure D 3320 E or · on the internet as follows: ® Screwdriving www.deprag.com Technology® Selection program: Inserting tools All catalogs are available for download from our web site: www.deprag.com... - Page 32 Assembly of Exhaust Hose 402957 A A complete exhaust hose # 402957 A is available as an optional item. Please mount exhaust hose as follows: Disconnect driver from air supply. Remove slide connector 831098. Assemble threaded pin 828335 into the bore of slide connector 831098. Remove quick release nipple 328733.
-
Page 33: Storage
Assembly of Support Ring 3870321 For better driver support and to allow an increased down-pressure force, the support ring may be installed as follows: Disconnect driver from air supply. Unscrew clutch bearing complete (AF 22, left-hand thread). Mount the support ring. Tighten the complete clutch bearing with support ring 3870321 to the Screwdriver. -
Page 34: Technical Data
12 Technical Data Manufacturer DEPRAG SCHULZ GMBH u. CO. Address Kurfürstenring 12 - 18 P.O. Box 1352 D-92224 Amberg D-92203 Amberg Phone 09621/371-0 09621/371-120 Technical Data: 347-218U 347-318U 347-518U 347-618U 397060 A 397060 B 397060 C 397060 D Length (mm) 202,5 Drive hex. -
Page 35: Conformity Declaration
14 Conformity Declaration EC-Conformity Declaration according to the EC-Machine-Guidelines 98/37/EC, Amendment IIA DEPRAG SCHULZ GMBH & CO. PO Box 1352 D-92203 Amberg hereby confirm, that the design of the Screwdriver 347-218U 347-318U 347-518U 347-618U conforms to the following, relevant regulation: EC-Machine-Guidelines, Version 98/37/EC, Amendment No. -
Page 36: Service Locations And Authorized Partners
