Summary of Contents for TimeIPS BAR-USB-SW
- Page 1 BAR-USB-SW BAR-USB-SWI Barcode Swipe Reader Installation Guide...
- Page 2 Operation is subject to the following conditions: (1) these devices may not cause harmful interference, and (2) these devices must accept any interference received, including interference that may cause undesired operation. (2) The responsible party is TimeIPS, Inc. 5445 E 85 St N, Valley Center KS, 67226. Phone 316.264.1600...
- Page 3 1-foot cord terminates to a PS/2 connector ● Comes with a PS/2 to USB adapter cable ● Plugs into the USB connectors on the back of the TimeIPS LCD display or ● TimeIPS system Additional Required Equipment Barcode printed badges ●...
- Page 4 Attach the reader with loop-and-hook fastener, such as Velcro ● brand adhesive. For permanent installations, secure the swipe reader with screws ● into the rear thread mounts Page 4 http://support.timeips.com 316.264.1600 TimeIPS...
- Page 5 Connect The Cable You must use the included USB adapter cable when connecting the barcode reader to your TimeIPS system. Connect the USB cable to a free USB port on the back of an LCD display, or directly to a USB port on the back of a TimeIPS system.
- Page 6 Configure Badge Numbers Employees are assigned badge numbers by entering them into TimeIPS. If you have pre-printed badges, use the badge number on the back side of the badge. Badge Number The employee badge number field is set in “ID / Badge” by going to “Administration”...
- Page 7 Swipe the badge again with a full swipe Does not Badge is reversed Reorient the badge so that the barcode is facing the indicator light blink or beep and the barcode is fully inserted into the reader. TimeIPS http://support.timeips.com 316.264.1600 Page 7...
- Page 8 Approximate weight: ~1lb (~500g) This manual is copyright 2004-2012 TimeIPS, Inc. TimeIPS and the TimeIPS logos are registered trademarks of TimeIPS, Inc. All other trademarks are the property of their respective owners. Thank you for reading this manual carefully. If you noticed errors, have any suggestions or found typographical problems, we want to know! Please send an email with the version code below and your feedback to documentation@timeips.com We appreciate your time.
