SERVICE MANUAL
EU3216STF
16:9 CTV
NOV03
SERVEU3216

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EU3216STF and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Teac EU3216STF

  • Page 1 SERVICE MANUAL EU3216STF 16:9 CTV NOV03 SERVEU3216...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1.INTRODUCTION ..........................1 2.TUNER ..............................1 3.IF PART (TDA9885/86) ........................1 4.VIDEO SWITCH TEA6415 ......................2 5.MULTI STANDARD SOUND PROCESSOR .................2 6.SOUND OUTPUT STAGE WITH TDA7269A ................2 7.BERTICAL OUTPUT STAGE WITH STV9379FA ..............2 8.VIDEO OUTPUT AMPLIFIER TDA6108 .................2 9.POWER SUPPLY (SMPS) ......................3 10.MICROCONTROLLER SDA55XX ..................3...
  • Page 3 13.10.SDA5555 ..........................13 13.10.1.General definition......................13 13.10.2.Features ...........................13 13.11.MC44608 ..........................14 13.11.1.Description ........................14 13.11.2.General Features ......................15 13.11.3.Pin Connections ......................15 13.12.TCET1102G ........................16 13.12.1.Description ........................16 13.12.2.Applications........................16 13.12.3.Features ...........................16 13.13.TDA9885T ..........................16 13.13.1.General Description ......................16 13.13.2.Features ...........................16 13.13.3.Pinning ..........................17 13.14.PI5V330 ..........................17 13.14.1.General Description ......................17 14.AK45 CHASSIS PRODUCTION SERVICE MODE ADJUSTMENTS ......18 14.1.SERVICE MENU ........................18 14.2.ADJUST MENU.........................18...
  • Page 4 Option 39. Personal Preferance Equalizer Band 1..............39 Option 40. Personal Preferance Equalizer Band 2..............39 Option 41. Personal Preferance Equalizer Band 3..............39 Option 42. Personal Preferance Equalizer Band 4..............39 Option 43. Personal Preferance Equalizer Band 5..............39 Option 44. Sound Efect (Standard; Music; Speech; Jazz; Pp)..........39 Option 45.
  • Page 5: Introduction

    1.INTRODUCTION 11AK45 is a 50Hz colour television capable of driving 24” + CRT sizes( beginning from 24” 16:9 up to 33”). The chassis is capable of operation in PAL, SECAM, NTSC (playback) colour standards and multiple transmission standards as B/G, D/K, I/I’, and L/L´. Sound system output is supplying 2x10W (10%THD) for left and right outputs of 8ohm speakers.
  • Page 6: Video Switch Tea6415

    4.VIDEO SWITCH TEA6415 In case of three or more external sources are used, the video switch IC TEA6415 is used. The main function of this device is to switch 8 video-input sources on the 6 outputs. Each output can be switched on only one of each input. On each input an alignment of the lowest level of the signal is made (bottom of sync.
  • Page 7: Power Supply (Smps)

    9.POWER SUPPLY (SMPS) The DC voltages required at various parts of the chassis are provided by an SMPS transformer controlled by the IC MC44608, which is designed for driving, controlling and protecting switching transistor of SMPS. The transformer generates 145V for FBT input, +/-14V for audio amplifier, 5V and 3.3V stand by voltage and 8V, 12V and 5V supplies for other different parts of the chassis.
  • Page 8: Acquisition Features

    • Up to 16 Colours per DRCS Character • One out of Eight Colours for Foreground and Background Colours for 1-bit DRCS and ROM Characters • Shadowing • Contrast Reduction • Pixel by Pixel Shiftable Cursor With up to 4 Different Colours •...
  • Page 9: Ic Descriptions

    K9356M: Standard B/G, D/K, I, L Features TV IF audio filter with pass band for sound carriers at 32,40 MHz (D/K, L), 32,90 MHz (I) and 33,40 MHz (B/G) K3953M Terminal and Pin configuration are the same with K9656M: Standard B/G, D/K, I, L/L’...
  • Page 10: Pinning

    • Low power consumption • Short-circuit resistant • High performance • high signal-to-noise ratio • High slew rate • Low distortion • Large output voltage swing. 13.2.3.Pinning SYMBOL DESCRIPTION OUTA Output A INA(neg) Inverting input A INA(pos) Non-inverting input A Negative supply INB(pos) Non-inverting input B...
  • Page 11: Features

    13.3.2.Features Standard Selection with single I C transmission Automatic Standard Detection of terrestrial TV standards Automatic Sound Selection (mono/stereo/bilingual), new registers MODUS, STATUS Two selectable sound IF (SIF) inputs Automatic Carrier Mute function Interrupt output programmable (indicating status change) Loudspeaker / Headphone channel with volume, balance, bass, treble, loudness AVC: Automatic Volume Correction Subwoofer output with programmable low-pass and complementary high-pass filter 5-band graphic equalizer for loudspeaker channel...
  • Page 12: Vdp313Xy

    Not connected Not connected AVSS Analog ground AVSS Analog ground MONO_IN Mono input Not connected Reference voltage IF A/D VREFTOP converter SC1_IN_R SCART 1 input, right SC1_IN_L SCART 1 input, left ASG1 AHVSS Analog Shield Ground 1 SC2_IN_R SCART 2 input, right SC2_IN_L SCART 2 input, left ASG2...
  • Page 13: Features

    13.4.2.Features Video Decoding and Processing – four CVBS, one S-VHS input, one YC component input – integrated high-quality A/D converters and associated clamp and AGC circuits – adaptive 2H comb filter Y/C separator – multistandard colour decoder PAL/NTSC/SECAM including all substandards –...
  • Page 14: Tea6415C

    GNDD SUPPLY Digital Ground RSW2 GNDAB Range Switch 2 for Measurement ADC RSW1 GNDAB Range Switch 1 for Measurement ADC SENSE GNDAB Sense ADC Input GNDM SUPPLY Ground, MADC ınput VERTQ Inverted Vertical Sawtooth Output VERT Vertical Sawtooth Output Vertical Parabola Output XREF Reference Input for RGB DACs SVMOUT...
  • Page 15: Pinning

    • 6.5dB gain between any input and output • 55dB crosstalk at 5mHz • Fully ESD protected 13.5.3.Pinning Input Max : 2Vpp, Input Current: 1mA, Max : 3mA Data Low level : -0.3V Max: 1.5V, High level : 3.0V Max : Vcc+0.5V Input Max : 2Vpp, Input Current: 1mA, Max : 3mA Clock...
  • Page 16: Tda7269A

    13.7.TDA7269A 13.7.1.Description The TDA7269A is class AB dual Audio power amplifier assembled in the Multiwatt package, specially designed for high quality sound application as Hi-Fi music centers and stereo TV sets. 13.7.2.Features Wide Supply Voltage Range Up To ±20V Split Supply High Output Power 14 + 14W @THD =10%, R =8Ω,V...
  • Page 17: Pin Configurations

    • 8-byte Page (1K, 2K), 16-byte Page (4K, 8K, 16K) Write Modes • Partial Page Writes are Allowed • Self-timed Write Cycle (10 ms max) • High-reliability – Endurance: 1 Million Write Cycles – Data Retention: 100 Years • Automotive Grade and Extended Temperature Devices Available •...
  • Page 18: Mc44608

    Memory • Non-multiplexed 8-bit data and 16 … 20-bit address bus (ROMless Version) • Memory banking up to 1Mbyte (Romless version) • Up to 128 Kilobyte on Chip Program ROM • Eight 16-bit data pointer registers (DPTR) • 256-bytes on-chip Processor Internal RAM (IRAM) •...
  • Page 19: General Features

    external components while offering a high flexibility and reliability. The device also features a very high efficiency stand–by management consisting of an effective Pulsed Mode operation. This technique enables the reduction of the stand–by power consumption to approximately 1W while delivering 300mW in a 150W SMPS.
  • Page 20: Tcet1102G

    13.12.TCET1102G 13.12.1.Description The TCET110/ TCET2100/ TCET4100 consists of a phototransistor optically coupled to a gallium arsenide infrared-emitting diode in a 4-lead up to 16-lead plastic dual inline package. The elements are mounted on one lead frame using a coplanar technique, providing a fixed distance between input and output for highest safety requirements.
  • Page 21: Pinning

    • SIF AGC for gain controlled SIF amplifier; single reference QSS mixer able to operate in high performance single reference QSS mode and in intercarrier mode, switchable via I C-bus • AM demodulator without extra reference circuit • Alignment-free selective FM-PLL demodulator with high linearity and low noise •...
  • Page 22: Ak45 Chassis Production Service Mode Adjustments

    14.AK45 CHASSIS PRODUCTION SERVICE MODE ADJUSTMENTS 14.1.SERVICE MENU All system, geometry and white balance alignments are performed in production service mode. Before starting the production mode alignments, make sure that all manual adjustments are done correctly. To start production mode alignments enter the MAIN MENU and then press the digits 4, 7, 2 and 5 respectively or press MUTE and INFO buttons at the same time.
  • Page 23 Y-Delay SECAM Enter a SECAM B/G colour and black-white bar test pattern via RF. Adjust Y-Delay SECAM till the colour transients on the colour bar of the pattern become as sharper and colours between transients do not mix with each other as possible. Y-Delay NTSC Enter an NTSC colour and black-white bar test pattern via RF.
  • Page 24 The amplitude of R of RGB output can be adjusted with the drive parameter WDR. The amplitude of G of RGB output can be adjusted with the drive parameter WDG. The amplitude of B of RGB output can be adjusted with the drive parameter WDB. The DC offset values of R of RGB output can be adjusted with the cutoff parameter CR.
  • Page 25 PANORAMIC VERT_POS (Panoramic mode Vertical Position) It’s used to adjust the vertical position of panoramic mode. PANORAMIC VERT_AMPL (Panoramic mode Vertical Amplitude) It’s used to adjust the vertical amplitude of panoramic mode. PANORAMIC VERT_SCOR (Panoramic mode Vertical S-Correction) It’s used to adjust the vertical s-correction of panoramic mode. PANORAMIC VERT_SSYM (Panoramic mode Vertical S-Symmetry) It’s used to adjust the vertical s-symmetry of panoramic mode.
  • Page 26 16:9 ZOOM VERT_POS (16:9 Zoom mode Vertical Position) It’s used to adjust the vertical position of 16:9 zoom mode. 16:9 ZOOM VERT_AMPL (16:9 Zoom mode Vertical Amplitude) It’s used to adjust the vertical amplitude of 16:9 zoom mode. 16:9 ZOOM VERT_SCOR (16:9 Zoom mode Vertical S-Correction) It’s used to adjust the vertical s-correction of 16:9 zoom mode.
  • Page 27 OSD Position It’s used to adjust the horizontal position of the OSD. BCLTHR Beam current threshold BCLG Beam current loop gain ROTATION (TILT) This adjustment only works when the TV has rotation option. Change TILT by pressing Left/Right buttons to rotate the complete raster clock-wise and counter clock-wise depending on the CRT. Check and readjust TRPEZ item if the adjustment becomes improper after some other geometric adjustments are done.
  • Page 28 POFS2 (RGB HORIZONTAL SHIFT) It’s used to adjust the horizontal position of RGB signal. REFERENCE WDR RED COOL The amplitude of R of RGB output can be adjusted with the drive parameter WDR for the colour temp of cool mode. REFERENCE WDR GREEN COOL The amplitude of G of RGB output can be adjusted with the drive parameter WDR for the colour temp of cool mode.
  • Page 29 FULL HORZ_POS It’s used to adjust the horizontal position of 16:9 mode (full mode). FULL HORZ_AMPL It’s used to adjust the horizontal amplitude of 16:9 mode (full mode). BRIGHT MODE BRIGHTNESS It’s used to adjust the brightness value of bright mode. BRIGHT MODE COLOUR It’s used to adjust the colour value of bright mode.
  • Page 30 14:9 RGB CUSHION It’s used to adjust the cushion in 14:9 mode for RGB signals. PANAROMIC RGB HORIZONTAL AMPLITUDE It’s used to adjust the horizontal amplitude in panoramic mode for RGB signals. 16:9 RGB HORIZANTOL AMPLITUDE It’s used to adjust the horizontal amplitude in 16:9 mode for RGB signals. 16:9 SUBTITLE RGB HORIZONTAL AMPLITUDE It’s used to adjust the horizontal amplitude in 16:9 subtitle mode for RGB signals.
  • Page 31 ADJUST EXPLANATION 2835 2835W MULTI MULTI - PAL I White Point RED White Point GREEN Whit Point BLUE AGC (Automatic Gain Control) It will be adjusted to below 1V of Max. AGC for each TV. IF-PLL Negative IF-PLL Positive Y-Delay Y-Delay SECAM Y-Delay NTSC Y-Delay OTHER...
  • Page 32 PANORAMIC HORZ_AMPL 14:9 ZOOM VERT_POS 14:9 ZOOM VERT_AMPL 14:9 ZOOM VERT_SCOR 14:9 ZOOM VERT_SSYM 14:9 ZOOM TRAPEZE 14:9 ZOOM CUSHION 14:9 ZOOM HOR_COR_SYM 14:9 ZOOM HOR_CORNER 14:9 ZOOM HORZ_POS 14:9 ZOOM HORZ_AMPL 16:9 ZOOM VERT_POS 16:9 ZOOM VERT_AMPL 16:9 ZOOM VERT_SCOR 16:9 ZOOM VERT_SSYM 16:9 ZOOM TRAPEZE 16:9 ZOOM CUSHION...
  • Page 33 STANDARD MODE COLOUR STANDARD MODE CONTRAST FULL VERT_POS (16:9 MODE) FULL VERT_AMPL FULL VERT_SCOR FULL VERT_SSYM FULL TRAPEZE FULL CUSHION FULL HOR_COR_SYM FULL HOR_CORNER FULL HORZ_POS FULL HORZ_AMPL BRIGHT MODE BRIGHTNESS BRIGHT MODE COLOUR BRIGHT MODE CONTRAST SOFT MODE BRIGHTNESS SOFT MODE COLOUR SOFT MODE CONTRAST PERSONAL MODE FACTORY SETTING BRIGHTNESS...
  • Page 34: Options Menu

    14.3.OPTIONS MENU Select the parameter by pressing up/down buttons. Adjust the parameter by pressing Left/Right buttons. . In OPTIONS menu, some of the changed parameters are not stored automatically. To store the adjusted parameters, you should turn off and on TV. OPTIONS...
  • Page 35: Option 3. (0X19) Video Processor Cathode Drive Level

    B4: x B3: x B2: x B1: LUMA 1 Luma Soft Limiter Enabled B0: BB 1 Blue Background Option Option 3. (0x19) Video Processor Cathode Drive Level B7: x B6: x B5: x B4: x B3: x B2: x B1: x B0: country = note 0 Note 0: choice for others country option...
  • Page 36: Option 8. If Frequency

    note 1: :Frequency Mode Frequency Menu Item available Frequency Menu Item not available Option 8. IF Frequency B7: x B6: x B5: IfI note 3 B4: IfD note 4 B3: IfM note 5 B2: Aps note 6 B1: Hp note 7 B0: Hue note 8 note 3:...
  • Page 37: Option 10. Scart, Combfilter, Teletext, Language

    Option 10. Scart, Combfilter, Teletext, Language B7: x B6: RGB note 2 B5: FAV = B4: AV2S B3: FSVHS = note 3 B2: BAV note 4 B1: Sc2 note 5 B0: BSVHS = note 6 note 2 : RGB Menu Item active/inactive RGB Menu Item inactive RGB Menu Item active note 3:...
  • Page 38: Option 13. Pll Tuner Control 2 Mid Byte

    Option 13. PLL Tuner Control 2 Mid Byte b7 b6 b5 b4 b3 b2 b1 b0 Philips UV1316T MK3 0 0 0 0 0 0 1 0 Philips UV1316MK2 1 0 0 1 0 0 1 0 Alps TELE9X062A 0 0 0 0 0 0 1 0 Samsung TEXX2949PG28A 0 0 0 0 0 0 1 0 Siel...
  • Page 39: Option 19. Pip Pll Tuner Control 1 Byte

    Temic 5001PH5-3X0003 0 0 0 0 0 0 0 0 Thomson CTT5020 0 0 0 1 1 0 1 1 (1B hex) Option 19. PIP PLL Tuner Control 1 Byte b7 b6 b5 b4 b3 b2 b1 b0 Philips UV1316MK2 1 0 0 0 1 1 1 0 Alps TELE9X062A...
  • Page 40: Option 25. Pip Pll Tuner Vhf High - Uhf Crossover Low Byte

    Option 25. PIP PLL Tuner VHF HIGH – UHF Crossover Low Byte b7 b6 b5 b4 b3 b2 b1 b0 Philips UV1316MK2 1 1 1 0 0 0 1 0 (E2 hex) Alps TELE9X062A 0 0 0 0 0 0 0 0 Samsung TEXX2949PG28A 1 0 1 0 0 0 1 0 Siel...
  • Page 41: Option 30. Country

    note 2: Tub : Tube size 16:9 Tube size 4:3 Tube size note 3: Z.Def : Zoom Default Mode 16:9 mode default 4:3 mode default Option 30. Country B7: C4 = note 1 B6: C3 = note 1 B5: C2 = note 1 B4: C1 = note 1...
  • Page 42: Option 33. Prescaler Msp Scart (Avl=Off)

    b7 b6 b5 b4 b3 b2 b1 b0 prescaler MSP NICAM (AVL = OFF) 0 0 0 1 1 1 1 1 (if virtual dolby option is available) Option 33. Prescaler MSP SCART (AVL=OFF) b7 b6 b5 b4 b3 b2 b1 b0 prescaler MSP SCART (AVL = OFF) 0 0 0 0 1 1 0 0 b7 b6 b5 b4 b3 b2 b1 b0...
  • Page 43: Option 39. Personal Preferance Equalizer Band 1

    note 3 : RGB Menu Item active/inactive RGB Menu Item inactive RGB Menu Item active note 4 : Equalizer available Equalizer not available Equalizer available note 5 : List Mode available List Mode not available List Mode available note 6 : Country Line available / Aps available or not Country Line not available / Aps not available Country Line available / Aps available...
  • Page 44: Option 47. Volume Offset Center

    Option 47. Volume Offset Center b7 b6 b5 b4 b3 b2 b1 b0 VOLUME OFFSET CENTER 0 0 0 0 0 1 1 0 Option 48. Volume Offset Rear b7 b6 b5 b4 b3 b2 b1 b0 VOLUME OFFSET REAR 0 0 0 0 0 1 1 0 Option 49.
  • Page 45: Option 55. Speaker Setup

    Option 55. Speaker Setup b7 b6 b5 b4 b3 b2 b1 b0 Speaker Setup (L/R, L/C/R, L/R/S, L/C/R/S) 0 0 0 0 0 0 0 0 Option 56. Audio Options Available Or Not Attention: All bits on the Option 56 must be the “0” for MONO TV SETS B7: nicam note 7 B6: ASD...
  • Page 46: Option 58. Msp Audio Flags

    note 1 : b7 b6 b5 b4 b3 b2 b1 b0 MSP Stereo/Mono Threshold 0 0 0 1 1 0 0 1 Option 58. MSP Audio Flags B7: b7 = B6: b6 = B5: b5 = B4: Trs = note 1 B3: Trb = note 1 B2: Bbe =...
  • Page 47 00010100 = 9 sec 00110100 = 17 sec 00010101 = 9,25 sec 00110101 = 17,25 sec 00010110 = 9,5 sec 00110110 = 17,5 sec 00010111 = 9,75 sec 00110111 = 17,75 sec 00011000 = 10 sec 00111000 = 18 sec 00011001 = 10,25 sec 00111001 =...
  • Page 48 76543210 Bit Positions 76543210 00000000 00100000 00000001 00100001 00000010 00100010 00000011 00100011 00000100 00100100 00000101 00100101 00000110 00100110 00000111 00100111 00001000 00101000 00001001 00101001 00001010 00101010 00001011 00101011 00001100 00101100 00001101 00101101 00001110 00101110 00001111 00101111 Colour Code 00010000 00110000 00010001 00110001 00010010...
  • Page 49: Option Table Recommended Values

    14.4.OPTION TABLE RECOMMENDED VALUES X listed in the option can be 0 or 1 OPTION 2835 MULTI 2835W MULTI 2835W PAL I X2 XXXXXX10 X2 XXXXXX10 X2 XXXXXX10 XX XXXXXXXX XX XXXXXXXX XX XXXXXXXX 23 001XXX11 23 001XXX11 001XXX11 XX XXXXXXX0 XX XXXXXXX0 XX XXXXXXX0 XX XXXXXXXX...
  • Page 50 75 01110101 75 01110101 01110101 00 00000000 00 00000000 00000000 DE 11011110 DE 11011110 DE 11011110 19 00011001 19 00011001 00011001 00 00000000 00 00000000 00000000 64 01100100 64 01100100 01100100 10 00010000 10 00010000 00010000 AK45 Service Manual 01/12/2003...
  • Page 51: Screen Adjustment (Fbt Screen)

    14.5.SCREEN ADJUSTMENT (FBT SCREEN) SCREEN ADJUST From the option list change option 2 bit 6 from 0 to 1 for disabling vertical scan. Adjust horizontal line via screen adjust pot. as thin as possible. Then press 0 to leave service menu. AK45 Service Manual 01/12/2003...
  • Page 52: Geometry Adjustment

    14.6.GEOMETRY ADJUSTMENT 4:3 FORMATS 4:3 MODE 16:9 MODE AK45 Service Manual 01/12/2003...
  • Page 53: 16:9 Formats

    16:9 FORMATS AUTO MODE AK45 Service Manual 01/12/2003...
  • Page 54 REGULAR MODE AK45 Service Manual 01/12/2003...
  • Page 55 ZOOM 14:9 MODE AK45 Service Manual 01/12/2003...
  • Page 56 ZOOM 16:9 MODE AK45 Service Manual 01/12/2003...
  • Page 57 SUBTITLE ZOOM MODE AK45 Service Manual 01/12/2003...
  • Page 58 FULL MODE AK45 Service Manual 01/12/2003...
  • Page 59 PANOROMIC MODE AK45 Service Manual 01/12/2003...
  • Page 60 AK45 Service Manual 01/12/2003...
  • Page 61: Block Diagram

    BILL OF MATERIAL LIST 3216*TEAC TEAC 10023314 EU3216STF(AK45)H.FUME BOM Date : 28/11/2003 COMPONENT MATERIAL POSITION NUMBER CODE ON/OFF AS.110°(32- 20036465 33")(2.2/AU)(W/MAKARON 30002174 SWITCH SAFE ON/OFF 4A/64A 30002368 CNAS 2P/650 AC MAINS W/C POWER CORD 2.2MT W/FILTER 30014059 AUST.TYPE SWITCH INSULATION DOOR...
  • Page 62 CNAS 2P/600 SIS W/C+FER 38 30019083 PL603 UL1007AWG24 39 30020461 CNAS 2P+1 AK45 EMC PL200 MD.ASY.SB18H FAV+HP XX15/16 40 20138835 (AK45) CONN HEADER 2P 2.5MM TOP 42 30001830 PL103 BLUE SD CONN HEADER 3P 2.5MM TOP 43 30001839 PL104 GREEN SD 44 30001891 RCA JACK 1P WHITE 28 FAV CON103 .
  • Page 63 88 30002183 RELAY SAFE MON15 KI-S-212M RL100 MD.ASY.RT45-ROTATION (TILT) 90 20108005 PL509 AK45 92 30001665 IC LM358N CONN HEADER 2P 2.5MM TOP 93 30001829 WHT SD 94 30001912 PIN F 5P/2.5MM (11.5MM) MD.SMD.RT45-ROTATION (TILT) 96 20108009 AK45 99 30000078 CAP MKT 1UF 100V M 100 30000353 CAP EL 100UF 25V M 101 30001452...
  • Page 64 BLUE SD CONN HEADER 3P 2.5MM TOP 133 30001839 PL703 GREEN SD 134 30009834 CABL 1P/60 SIS 136 30010921 DOUBLE-DECK SCART SOCKET PL204 138 30013658 IC MSP3410G SDIP64 IC700 TUNER WSP (PLL) 38.9 MK2 - 140 30009637 TU200 BATCH 142 30019493 IC VDP3133Y IC200 IC VIDEO SWITCH TEA6415C...
  • Page 65 171 35006161 HEATSINK AK38 AUDIO 172 40011922 EDGE SADDLE (CT-16) HE.ASY.45-HORIZANTAL 173 20113527 W/CABLE HOLDER 174 30001429 TR BUK444-200A Q600 175 30001441 TR BU2508AF Q602 176 35000158 NUT C ZN BOTTOM M3 KNURL WASHER C ZNSY 3*6*04 177 35000165 (M3) 178 35000181 SCREW C ZN YSMB M3*8 179 35000182...
  • Page 66 2.5MM(9.7MM) TOP CONN HEADER 2P 211 30001764 PL709 PL200 . 2.5MM(9.7MM) TOP BLACK CONN HEADER 5P 2.5MM TOP 212 30001783 PL500 CONN HEADER 6P 2.5MM TOP 213 30001784 PL502 CONN HEADER 2P 7.5MM TOP 214 30001792 PL100 PL602 . CONN HEADER 3P 5/7.5MM TOP 215 30001795 PL101 CONN HEADER 2P 2.5MM TOP...
  • Page 67 254 20000848 FUSE ASSY.TK79-A (2.5A) F100 255 30001731 FUSE SAFE 2.5A 250V 5*20MM 256 35000136 FUSE HOLDER TK79-A (GRAY) 259 20140108 PR.IC.45-SDA55XX TEAC 260 30011957 IC SDA55XX FLASH IC500 262 30000092 CAP MKT 220NF 63V J S219 PL219- 263 30009835 CABL 1P/150 SIS NOT-2 .
  • Page 68 309 30012709 RES SMD 1/16W 7.5K J (0603) R749 R754 310 30016126 CAP SMD 220NF 16V K R (0603) C763 C767 311 30016654 CAP SMD 100NF 16V K R (0603) C765 315 30012581 CAP SMD 1NF 50V K R (0603) C740 C741 316 30012657...
  • Page 69 380 30000459 RES CF 1/4W 100R J R266 R567 R568 R265 381 30000466 RES CF 1/4W 1K J R537 R150 R519 R658 R657 R336 R337 R338 382 30000470 RES CF 1/2W 10K J R601 383 30000471 RES CF 1/4W 10K J R505 R506 R612...
  • Page 70 418 30025271 PCB 11AK45B5 419 30000069 CAP MKT 1NF 100V J C648 420 30000074 CAP MKT 100NF 63V J C632 421 30000082 CAP MKT 15NF 63V J C609 422 30000092 CAP MKT 220NF 63V J C638 C718 C717 C643 423 30000107 CAP MKT 47NF 250V J C219 424 30000109...
  • Page 71 D114 D132 D134 D212 D612 D706 D628 D629 455 30001457 TR BC848B SMD Q108 Q113 Q501 Q109 Q502 Q203 Q114 Q503 Q216 Q504 Q500 Q220 Q201 Q222 Q704 Q223 456 30001458 TR BC858B SMD Q505 Q700 Q218 Q112 Q603 Q605 Q606 Q703 FERRITE BEAD (0805)
  • Page 72 484 30012590 CAP SMD 47NF 50V K (0603) C268 C273 C781 C783 C171 485 30012591 CAP SMD 5.6NF 50V K (0603) C644 C645 486 30012603 CAP SMD 100NF 25V K R (0603) C146 C126 C127 C633 C630 C264 C105 C361 C129 C174 C175...
  • Page 73 R621 R820 510 30012697 RES SMD 1/16W 5.1K J (0603) R146 511 30012698 RES SMD 1/16W 5.6K J (0603) R352 512 30012702 RES SMD 1/16W 560R J (0603) R274 R760 R763 R234 513 30012707 RES SMD 1/16W 680R J (0603) R286 R289 514 30012708...
  • Page 74 CRT B.ASSY.TP45B-5-DUAL 562 20141922 FOCUS (AK45) HE.ASY.52-CRT BOARD 564 20103005 IC900 (AK52/AK45) 565 30018768 IC TDA6109 IC900 566 35000131 HEATSINK 11TP18 RGB 567 35000158 NUT C ZN BOTTOM M3 KNURL WASHER C ZNSY 3*6*04 568 35000165 (M3) 569 35000180 SCREW C ZN YSMB M3*6 SOCKET CRT SAFE NAR.NECK 570 30001856 DUAL FOCUS...
  • Page 75 626 30027546 PL902 RGB W/DC+FER 627 35000135 TEST PIN 1.1MM PL905 PL909 . ARTWORK TEAC 628 20143448 EU3216STF(AK45)EKO R/C 1541 TEAC (S) 629 20142179 (EKO2GRAY(I) R/C 1541 NOBRAND (S) 630 20129851 (EKO2GRAY)(F) 631 20121852 R/C KIT 1541 632 20121796 MD.ASY.UK10 633 20121797 MD.ASY.UK10 (SMD)
  • Page 76 BOTTOM COVER RC 1541 653 40014912 EKO2GRAY (I) TOP CVR.R/C 1541 654 40014913 NOBRAND(S)(EKO2GRAY) CNAS SCART TO RCA (YUV) 655 30027396 150CM I/B TEAC EU3216STF 656 50045077 PLL/AK45/1541/ENG F CARTON BOX TEAC 657 20143449 EU3216STF(AK45)H.FUME LBL.BCK.CVR.TEAC EU3216STF 658 20143450 "45"...
  • Page 77 676 20098945 BUTTON FUNCTION xx15/16 (I) 677 60000003 ABS BLACK PAINT HIT.FUME C77 (SU 678 60000946 BAZ)L8342175 679 20125086 LENS 3216W LEFT (SILVER/P) 680 20125087 LENS 3216W LEFT EKO GRAY (I) . 681 60000001 ABS (NATURAL) MASTERBATCH EKO.GRAY GR 682 60001195 3216 SE1 PAINT SILVER 022-6485 (SU 683 60000895...
  • Page 78 SCREW SK C NI YFMB 2.9*6.5 SPONGE- bracketspeaker -160x57 738 40009944 (55Kg/m3) 739 50011720 LABEL HIGH END 32" CPT TUBE SAFE 50HZ 16:9 740 30015088 REALFLAT 741 30015231 ROTATION COIL AK33 29" 742 40001939 LOGO TEAC(D.C.-SILVER)(BIG) PLASTIZOTE BAG 743 50042313 (1450mm*1150mm)
  • Page 79 16.BLOCK DIAGRAM GENERAL BLOCK DIAGRAM OF CHASSIS 11 AK 45 SC3_V_OUT RGB AMPLIFIER TDA 6107 CVBS (PHILIPS) SC1_V_OUT TDA9885T Video K3958M EPCOS TU200 Filter 38.9MHz-TV TUNER VDP313XY Sound K9656M EPCOS Filter Vertical Stage Yoke Horizontal STV9379FA SC1_RGB PI5V330-SOIC RGB SW SC2_RGB/DVD/DVB EXT_CVBS/Y SC2_V_OUT...
  • Page 80: Circuit Diagrams

    17.CIRCUIT DIAGRAMS 11AK45B5-1 JVC AK45 Service Manual 01/12/2003...
  • Page 81 11AK45B5-2 JVC AK45 Service Manual 01/12/2003...
  • Page 82 11AK45B5-3 JVC AK45 Service Manual 01/12/2003...
  • Page 83 11AK45B5-4 JVC AK45 Service Manual 01/12/2003...
  • Page 84 11AK45B5-5 JVC AK45 Service Manual 01/12/2003...
  • Page 85 11TP45B-1 JVC AK45 Service Manual 01/12/2003...
  • Page 86 11SB107-4 JVC AK45 Service Manual 01/12/2003...
  • Page 87 11SW01-3 JVC AK45 Service Manual 01/12/2003...
  • Page 88 11LD13 JVC AK45 Service Manual 01/12/2003...
