Technical Speci Cations - D-Link DCS-1130 Specifications

Your Network Setup
CAMERA SPECIFICATIONS
+ Sensor: ¼" CMOS
+ Lens: 5.01mm, F2.8
+ Minimum Illumination: 1.0 Lux @ F2.8
+ 3A Control: AGC, AWB, AES
+ Electronic Shutter: 1/60 (1/50) ~ 1/15,000 sec.
+ 16x Digital Zoom
AUDIO
+ Built-in Omni-directional Microphone
+ Frequency: 50 ~ 16000Hz
+ S/N Ratio: 6mm, -40db + 3db
VIDEO FORMATS SUPPORTED
+ MPEG-4 and MJPEG (Simultaneous Dual Format
Compression)
+ JPEG for Still Images
DISPLAY TYPE
+ ActiveX
+ Java
MULTI PROFILE
Support 4 pro les simultaneously
FEATURES
+ Adjustable image size and quality
+ Time stamp and text overlay
+ Three con gurable motion detection windows
+ Flip and Mirror
RESOLUTION
+ Up to 30 frames at 640x480
+ Up to 30 frames at 320x240
+ Up to 30 frames at 160x120
CONNECTIVITY
+ Wireless (Draft 802.11n) Network
(Backward compatible with 802.11g)
+ Wired (10/100 Fast Ethernet) Network
SECURITY
Password Authentication
LED
Power/Link
Router must support UPnP™ and Application Layer Gateway (ALG).
1
The mobile device must be Internet-ready, support Real Time Streaming Protocol (RTSP) and be equipped with a 3G video player such as
2
PacketVideo™, QuickTime™, or RealPlayer™, and have Internet access.
1-Year Limited Warranty available only in the USA and Canada.
3
Latest Software and Documentation available at http://support.dlink.com.
4
Use of audio or video equipment for recording the image or voice of a person without their knowledge and consent is prohibited in certain states
or jurisdictions. Nothing herein represents a warranty or representation that the D-Link product provided herein is suitable for the end-user's
intended use under the applicable laws of his or her state. D-Link disclaims any liability whatsoever for any end-user use of the D-Link product
which fails to comply with applicable state, local or federal laws.
All references to speed are for comparison purposes only. Product speci cations, size and shape are subject to change without notice, and actual
product appearance may di er from that depicted on the package. See inside package for warranty details.
MINIMUM SYSTEM MULTIPLE CAMERA
REQUIREMENTS OPERATIONS REQUIRED
Wireless (Draft 802.11n) Network Wireless (Draft 802.11n) Network
PC with PC with
1.3GHz Processor 2.4GHz Processor
128MB Memory 512MB Memory
Windows Vista® or 32MB Video Card
Windows ® XP SP2 Windows Vista® or
Internet Explorer® v6 or later Windows® XP SP2
Internet Explorer® v6 or later

Technical Speci cations

NEWORKING PROTOCOLS
+ IPV4, ARP, TCP, UDP, ICMP
+ DHCP Client
+ NTP Client (D-Link)
+ DNS Client
+ DDNS Client (D-Link)
+ SMTP Client
+ FTP Client
+ HTTP Server
+ Samba Client
+ PPPoE
+ UPnP Port Forwarding
+ RTP
+ RTSP
+ RTCP
+ 3GPP
CERTIFICATIONS
+ FCC Class B
+ IC
+ CE
+ C-Tick
POWER
+ External Power Supply: 5VDC, 2.5A
+ Consumption: 4 Watts Max
TEMPERATURE
+ Operating: 32° to 104°F (0° to 40°C)
+ Storage: -4° to 158°F (-20° to 70°C)
OPERATING HUMIDITY
20% ~ 80% RH Non-condensing
DIMENSIONS L X W X H
+ Item: 1.5" x 3.2" x 4.7" (38mm x 81mm x 119mm)
+ Packaging: 1.6" x 10.8" x 8.2" (41mm x 274mm x 208mm)
WEIGHT
+ Item: 0.5 lbs (226.8 g)
+ Packaging: 2.0 lbs (907.2g)
WARRANTY
1-Year Limited
3
PACKAGE CONTENTS
D-Link Systems, Inc. 17595 Mt. Herrmann Street Fountain Valley CA 92708
Wireless N Network Camera
©2009 D-Link Corporation/D-Link Systems, Inc. All rights reserved. D-Link,
CAT5 Ethernet Cable
the D-Link logo, the D-Link RoHS logo, D-ViewCam, and mydlink are
2 Detachable Antennas
trademarks or registered trademarks of D-Link Corporation or its subsidiaries
Power Adapter in the United States and/or other countries. Other trademarks or registered
Camera Base and Mounting Kit
Quick Installation Guide
CD-ROM 4 with
Software
Product Documentation
DCS-1130
trademarks are the property of their respective owners.
