ZyXEL Communications, Inc.______________________________________________Prestige Application Notes
Last modified: December 20, 1996
Bridging IPX Between Two Prestiges
NetWare
Client
Prestige 2
Note: The IPX network numbers shown above are examples only!
This configuration note explains how to set up a workstation on a network to use a Prestige to make a
connection to another Prestige to bridge IPX. In this configuration, the workstation has NetWare client
software so that you will be able to log into the NetWare server on the remote network. There will be
three items that you need to set up. These are the workstation and the two Prestiges.
I.
Workstation Setup (NetWare Client)
To set up the workstation (W/S), you will need to set the following parameters:
IPX Frame Type - First determine the frame type that the NetWare server that you wish to login
to is using, and set the same frame type on the NetWare client workstation.
Server Name - In some cases, you may need the name that has been configured for the NetWare
server you wish to login to. In the previous example, that would be 'Server_1'.
The procedure for configuring these parameters for your workstation may differ depending on the
type of IPX client software you are using on your workstation. If you are unfamiliar with how to set
these parameters, you can refer to the technical notes corresponding to your software.
DOS workstation w/ NetWare Client (VLM) software
Windows 95/NT LAN Setup
II. Prestige 2 Setup
In order to configure the Prestige on the NetWare client side for this application, make sure you have
the following menus configured correctly.
Note that the fields are indicated in bold type.
Prestige 1
NetWare
Server
BRG00001: 1
Advertisement
Table of Contents
Related Manuals for ZyXEL Communications DI-106
Summary of Contents for ZyXEL Communications DI-106
- Page 1 ZyXEL Communications, Inc.______________________________________________Prestige Application Notes Last modified: December 20, 1996 Bridging IPX Between Two Prestiges NetWare Client Prestige 2 Note: The IPX network numbers shown above are examples only! This configuration note explains how to set up a workstation on a network to use a Prestige to make a connection to another Prestige to bridge IPX.
- Page 2 ZyXEL Communications, Inc.______________________________________________Prestige Application Notes Menu 1: System Name= Pres_2 Location= San Jose Contact Person's Name= CC Route IP= No Route IPX= N/A Route AppleTalk= N/A Bridge= Yes Press ENTER to Confirm or ESC to Cancel: In menu 1, make sure the Bridge field is set to ‘Yes’. Menu 2: Switch Type= Northern Telecom Custom B Channel Usage= Switch/Switch...
- Page 3 Make sure the remote node is enabled by setting Active to ‘Yes’. My Login and My Password is the login information that this Prestige will use to connect to the remote router. The Pri Phone # field should be set to the correct phone number to dial.
- Page 4 ZyXEL Communications, Inc.______________________________________________Prestige Application Notes Menu 11.2: Menu 11.2 - Remote Node Network Layer Options IP Options: Rem IP Addr: Rem Subnet Mask= N/A My WAN Addr= N/A Metric= N/A Private= N/A RIP= N/A IPX Options: Dial-On-Query= N/A Rem LAN Net #= N/A My WAN Net #= N/A Hop Count= N/A Tick Count= N/A...
- Page 5 ZyXEL Communications, Inc.______________________________________________Prestige Application Notes Menu 2: Switch Type= Northern Telecom Custom B Channel Usage= Switch/Switch 1st Phone #= 5551214 SPID #= 408555121400 Analog Call= Modem 2nd Phone #= 5551215 SPID #= 408555121500 Analog Call= Voice Press ENTER to Confirm or ESC to Cancel: In menu 2, set your switch type, phone numbers, and SPIDs (if necessary).
- Page 6 Make sure the remote node is enabled by setting Active to ‘Yes’. Rem Login and Rem Password is the login information that this Prestige will expect from the remote router. Route should be set to ‘None’ The Bridge field should be set to ‘Yes’.
