STEREO RADIO CASSETTE RECORDER
COMPACT DISC PLAYER
GPS219PLLR
Instruction Manual
For improvement purposes, specification and design are subject to change without notice.
Goodmans Product Information Helpline 0870 873 0080
www. goodmans.co.uk
IMPORTANT SAFEGUARDS
PRE FITTED MAINS PLUGS
For your convenience a mains plug has been fitted to this appliance. For your safety please
observe the following information.
1. Should the fuse in the plug fail, remove the plug from the wall socket and replace the fuse with
a 3 Amp ASTA approved to BS 1362 fuse.
2. Never use the plug without the fuse cover fitted. Replacement fuse covers are available from
your dealer or most electrical retail outlets.
3. If the mains plug is cut off the cable, rewire the replacement plug in accordance with
instruction given in this manual.
4. CAUTION: Under no circumstances should the discarded plug be inserted mains socket. To
prevent a shock hazard carefully dispose of the discarded plug. Do not leave the plug lying
around where children might see it.
WARNING:
To prevent fire or shock hazard do not expose this unit to rain or moisture.
CAUTION: DANGEROUS VOLTAGES EXIST INSIDE THIS UNIT, DO NOT REMOVE COVER
(OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL. DISCONNECT FROM MAINS SUPPLY
WHEN NOT IN USE.
PLUG WIRING DETAILS
E
L
BLUE
FUSE
BROWN
N
CORD
GRIP
WARNING: UNDER NO CIRCUMSTANCES MUST THE LIVE OR NEUTRAL WIRES BE
CONNECTED TO THE EARTH TERMINAL IN A 3-PIN MAINS PLUG.
This symbol means that this unit is double insulated.
An earth connection is not required.
The wires in this mains lead are coloured in
accordance with the following wiring codes:
Blue................................................. Neutral
Brown................................................... Live
The wires in this mains lead must be
connected to the terminals in the plugs as
follows:
Blue Wire..................................... N or Black
Brown Wire..................................... L or Red
Only a 3 Amp fuse should be fitted in the plug
or a 5 Amp fuse at the distribution board.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Goodmans GPS219PLLR
Summary of Contents for Goodmans GPS219PLLR
- Page 1 CONNECTED TO THE EARTH TERMINAL IN A 3-PIN MAINS PLUG. This symbol means that this unit is double insulated. An earth connection is not required. For improvement purposes, specification and design are subject to change without notice. Goodmans Product Information Helpline 0870 873 0080 www. goodmans.co.uk...
-
Page 2: Important Notes
CAUTION IMPORTANT NOTES CLASS 1 LASER PRODUCT Use of Controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. Your hearing is very important to you and to us so please take care when operating LASER SAFETY this equipment. -
Page 3: Safety Precautions
TABLE OF CONTENTS SAFETY PRECAUTIONS 1. POWER SOURCES Power Sources ..........1 1. As the laser beam used in this compact AC MAINS OPERATION BATTERY OPERATION disc player is harmful to the eyes, do not Player Maintenance..........2 attempt to disassemble the casing. Disc Cleaning, Power failure.... -
Page 4: Disc Cleaning, Power Failure
3. DISC CLEANING, POWER FAILURE 4. LOCATION OF CONTROLS Cleaning the Disc LOCATION OF CONTROLS 1. PHONES SOCKET 1 2 3 4 2. VOLUME CONTROL 1. To handle a disc use only one of the two 3. TAPE BUTTON 4. STANDBY INDICATOR methods illustrated. -
Page 5: Radio Operation
PRESETTING STATIONS 5. RADIO OPERATION UP TO 10 FM AND 10 MW STATIONS CAN BE STORED INTO THE PRESET MEMORIES. (THEY WILL REMAIN IN MEMORY AS LONG AS THE BATTERIES ARE 1. Press the Radio button after the ON/OFF INSTALLED, OR AC POWER CORD IS CONNECTED.) button has been pressed. -
Page 6: Listening To A Compact Disc
5. To start playback, press the CD TO LISTEN TO PRESET MEMORY Play/Pause Button. The first track STATIONS number " " will appear in the Display, and the disc will start playing. The 1. Press the Radio button to select the radio. elapsed time will be shown in the display 2. -
Page 7: Program Play Operation
4. Press the Program Button. The Display SKIPPING TRACKS (SEARCH) will show " ". 5. Repeat steps 3 and 4 until all the Twist the Skip/Search/Tuning Control desired tracks are programmed. anti-clcokwise once or repeatedly to Press the CD Play/Pause button to select the next or one of the subsequent commence playback after programming. -
Page 8: Repeat All Tracks
REPEAT ALL TRACKS TO PLAY A CASSETTE TAPE To repeat ALL TRACKS on a disc and 1. Open the Cassette Door by pressing the play them again and again. Cassette Stop/Eject Button if a tape is 1. Press the Repeat Button twice during already playing press this button twice, to playback . -
Page 9: Recording From Radio
RECORDING FROM THE BUILT-IN 11. RECORDING FROM RADIO/MICROPHONE/CD MICROPHONE 1. Load a blank cassette tape into the Cassette door (full reel or spool on right RECORDING FROM RADIO side). 2. Press TAPE button. 1. Follow the instructions to select the 3. -
Page 10: Product Specifications
7. Press (and release) the Cassette Pause 13. PRODUCT SPECIFICATIONS button when you wish to start recording. 8. Press the Cassette Stop/Eject button to stop the recording. 9. The recording will stop when the tape PICK-UP has reached the end and the Record System Compact disc digital audio system and Play buttons will pop up.
