Operating Instructions • Warning Information • Parts Breakdown
S P E C I F I C A T I O N S
Fluid Orifice .......................................................... 1.6mm
Air Inlet: ..................................................................1/4 NPT
Air Pressure ............................................................50-70 PSI
Rec. Max. Inlet Pressure: ..............................................50 PSI
SX80A
1
SX80A
D
ELUXE
S
G
PRAY
UN
& C
UP
Rev. 05/09/03
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Sunex Tools SX80A
Summary of Contents for Sunex Tools SX80A
- Page 1 Operating Instructions • Warning Information • Parts Breakdown SX80A S P E C I F I C A T I O N S Fluid Orifice ............1.6mm ELUXE Air Inlet: ..............1/4 NPT PRAY Air Pressure ............50-70 PSI & C Rec. Max. Inlet Pressure: ..........50 PSI SX80A Rev.
- Page 2 Protect yourself from ever there is a chance of inhaling sprayed mate- noise. Noise levels vary with work rials. The mask must be compatible with the mate- surface. Wear ear protectors. rial being sprayed and its concentration. SX80A Rev. 05/09/03...
- Page 3 Water Gauge Air pressure for atomization is regulated at Extractor extractor; fluid pressure at cup regulator. For heavy Cup Regulator fluids and internal mix nozzle spraying, fluid Air Hose Pressure Cup adjusted by control screw on gun. SX80A Rev. 05/09/03...
- Page 4 If the spray is too thick, close the fluid control face being finished. screw. Regulate the pattern width and repeat adjustment of spray as needed. Spray pattern may be infinitely adjusted from round to flat. SX80A Rev. 05/09/03...
- Page 5 Repeat with clean solvent if necessary. Remove solvent, discon- screw, realign, and try again. NEVER use excessive force in nect gun, remove air cap and clean. Wipe gun and cup with matching parts. rag dampened with solvent. SX80A Rev. 05/09/03...
- Page 6 A.) Move gun closer to surface. Thin, sandy coarse finish. B.) Atomization pressure set B.) Adjust atomization pressure. too high. Thick, dimpled finish Gun held too close to surface. Move gun further from surface. resembling orange peel. SX80A Rev. 05/09/03...
- Page 7 PARTS BREAKDOWN - SX80A RS801SK Includes all parts as asterisked on parts diagram SX80A Rev. 05/09/03...
- Page 8 This product carries a 90 day warranty. During this warranty period, Sunex Tools will repair or replace at our option any part or unit which proves to be defective in material or workmanship.
