F3X46 Series
User Manual
F3X46 Series User Manual
The user manual is suitable for the following model:
Product Version
V1.01
Product Name：F3X46
Model
F3446
WCDMA Dual-SIM WIFI ROUTER
F3646
EVDO Dual-SIM WIFI ROUTER
F3746
LTE/TD-SCDMA Dual-SIM WIFI ROUTER
F3846
LTE/WCDMA Dual-SIM WIFI ROUTER
F3A46
LTE Dual-SIM WIFI ROUTER
Xiamen Four-Faith Communication Technology Co., Ltd.
Add：J1-J3,3rd Floor,No.44,GuanRi Road,SoftWare
Park,XiaMen,China
Tel：+86 592-6300466 ，6300465，6300464
Fax:+86 592-5912735
http://www.four-faith.com
Product Type
Zip Code:361008
Page
Total:87
