Cordless glue gun 7.2v lithium ion

Advertisement

CORDLESS
GLUE GUN
7.2V Lithium Ion
INSTRUCTION MANUAL
SPECIFICATIONS
Input:
7.2V
Glue Stick Diameter:
7.2mm
Glue Stick Length:
190mm
Heating Time:
15sec
Working Time:
45min
Battery Power:
1.3Ah Lithium Ion
Charge time:
3-5 Hours
Weight:
0.38kg
ozito.com.au
WHAT'S IN THE BOX
Cordless Glue Gun
Glue Stick x 3
Charging Adaptor
GGL-7000

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GGL-7000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Ozito GGL-7000

  • Page 1 7.2V Lithium Ion INSTRUCTION MANUAL SPECIFICATIONS Glue Stick x 3 Input: 7.2V Glue Stick Diameter: 7.2mm Glue Stick Length: 190mm Heating Time: 15sec Working Time: 45min Battery Power: 1.3Ah Lithium Ion Charge time: 3-5 Hours Weight: 0.38kg ozito.com.au Charging Adaptor GGL-7000...
  • Page 2: Know Your Product

    KNOW YOUR PRODUCT SETUP & PREPARATION CORDLESS GLUE GUN 1. BATTERY 1 Protective Nozzle Cover 5 7.2V Battery 2 Trigger Flow Control 6 Charging Socket CAUTION! THE POWER SUPPLY FOR THIS CHARGER 3 On / Off Button 7 Glue Display SHOULD BE PROTECTED BY A RESIDUAL CURRENT 4 LED Indicator Lights 8 Glue Stick Entry...
  • Page 3: Operation

    OPERATION 2. LOADING THE GLUE STICK 3. SWITCHING THE GLUE GUN ON Switching the Glue Gun On WARNING! ENSURE THE TOOL IS SWITCHED OFF AND ALLOWED TO COOL DOWN BEFORE PERFORMING ANY OF THE FOLLOWING TASKS. 1 Hold the on/off switch down for 2 seconds to start the glue gun.
  • Page 4 2 Press the surfaces to be glued together within 15 seconds for a strong bond. 3 T o stop the flow of glue from the gun, release the trigger flow control. WARNING! DO NOT ALLOW HOT GLUE TO COME IN CONTACT WITH PRODUCT HOUSING DURING USE. GGL-7000...
  • Page 5: Maintenance

    Check that the charging jack is securely connected to the charging cradle. Note: Ozito Industries will not be responsible for any damage or injuries caused by repair of the glue gun by an unauthorised person The battery has a short run time or by mishandling.
  • Page 6 Model No. GGL-7000 How To Order Available spare parts can be ordered through the Special Orders Desk at any Bunnings Warehouse. If you have any further questions, please contact Ozito Customer Service on: Australia: 1800 069 486 New Zealand: 0508 069 486...
  • Page 7: Electrical Safety

    ELECTRICAL SAFETY WARNING! The power supply for this product should be protected by a residual current device (rated at 30mA or less). A When using mains-powered tools, basic safety precautions, including the residual current device reduces the risk of electric shock. following, should always be followed to reduce risk of fire, electric shock, personal injury and material damage.
  • Page 8: Warranty

    • Failure to perform maintenance as set out within the instruction manual. • If the tool is disassembled or tampered with in any way. OzITO Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175. 0415...
