CONTROLS AND CONNECTORS

SIGNAL CABLE
• Connecting the Signal Cable: Connect the 15-pin signal cable to the back of the
monitor and the computer's VGA port�
• Connecting the Power Cord: Connect the AC-power cord to the LCD monitor's
AC input socket and the wall outlet�
• Connecting the DVI Cable: Connect the 24-pin DVI cable to the back of the
monitor and the computer's DVI port�
• Caution: If the AC wall outlet is not grounded (with three holes), install the proper
grounding adapter (not supplied)�
1
D2215H
1.
Power input
2.
DVI Signal input
3.
D-SUB Signal input
3
2
10
1
3
2
D2215HC
