Char-Broil 463675016 Product Manual

Char-Broil 463675016 Product Manual

Professional 2-burner gas grill
Hide thumbs

Advertisement

Quick Links

Serial number | Numéro de série | Número de serie
See rating Label on grill for serial number.
Ce numéro se trouve sur l´étiquette signalétique sur
i´appareil.
El número de serie se encuentra en la etiqueta de
especificaciones de la parrilla.
Date purchased | Date d'chat | Fecha de compra
If you have questions or need assistance
during assembly, please call 1-888-430-7870.
Si vous avez des questions ou besoin d´aide
pendant l'assemblage, S'il vous plaît appelez
1-888-430-7870
Si tiene alguna pregunta o si Necesita
ayuda durante el Ensamblado, llámenos Al
1-888-430-7870
Convertit facilement de forme (LP)
propane liquide (NG) de gaz naturel
ENSEMBLE DE CONVERSION
#4584609
05/25/16 • G362-001-200801
463675016
Professional
2-Burner Gas Grill

Advertisement

loading
Need help?

Need help?

Do you have a question about the 463675016 and is the answer not in the manual?

Questions and answers

Related Manuals for Char-Broil 463675016

Summary of Contents for Char-Broil 463675016

  • Page 1 Professional 463675016 2-Burner Gas Grill Serial number | Numéro de série | Número de serie See rating Label on grill for serial number. Ce numéro se trouve sur l´étiquette signalétique sur i´appareil. El número de serie se encuentra en la etiqueta de especificaciones de la parrilla.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS CAUTION For Your Safety ....... . . 2-4 For residential use only.
  • Page 3 WARNING CAUTION Using pots larger than 6 quarts in capacity could exceed Failure to follow all manufacturer’s instructions could result in weight limit of the side burner shelf or side shelf, resulting serious personal injury and/or property damage. in failure of grill cart components. CAUTION Read and follow all safety statements, assembly instructions, and use and care directions before attempting...

  • Page 4: Use And Care

    Installation Safety Precautions LP Cylinder •The LP cylinder used with your grill must meet the •Use grill, as purchased, only with LP (propane) gas and the following requirements: regulator/valve assembly supplied. If your grill is Dual Fuel •Use LP cylinders only with these required measurements: 12" ready, a conversion kit must be purchased for use with (30.5cm) (diameter) x 18"...
  • Page 5 Connecting Regulator to the LP Cylinder LP Cylinder Exchange •Many retailers that sell grills offer you the option of replacing 1.LP cylinder must be properly secured onto grill. (Refer to assembly section.) your empty LP cylinder through an exchange service. Use only 2.Turn all control knobs to the OFF position.
  • Page 6 WARNING WARNING • Outdoor gas appliance is not intended to be installed in or • Do not use grill until leak-tested. on a boat. • If a leak is detected at any time, STOP! Turn off gas at source and correct leak. •...
  • Page 7 Ignitor Lighting WARNING • Do not lean over grill while lighting. 1. Turn gas burner control valves to (off). 2. Open lid during lighting or re-lighting. For Safe Use of Your Grill and to Avoid Serious Injury: 3. Turn ON gas at LP cylinder. •...
  • Page 8 Burner Flame Check • Remove cooking grates and heat tents. Light burners, rotate knobs from HIGH to LOW. You should see a smaller flame in LOW position than seen on HIGH. Perform burner flame check on side burner, also. Always check flame prior to each use. If only low flame is seen refer to "Sudden drop or low flame"...
  • Page 9 Cleaning the Burner Assembly Follow these instructions to clean and/or replace parts of burner CAUTION assembly or if you have trouble igniting grill. 1. Turn gas off at control knobs and LP cylinder. 2. Remove cooking grates and heat tents. SPIDER ALERT! 3.

  • Page 10: Assembly

    ASSEMBLY/ ASSEMBLAGE/ ARMADO NOTE: DO NOT over tighten screws and washers that come into contact with porcelain coated surfaces. Over tightening may cause the porcelain coating to crack and break, resulting in exposed metal that will be prone to rust. REMARQUE: NE serrez PAS excessivement les vis et les rondelles qui sont en contact avec les surfaces au revêtement en porcelaine.
  • Page 11 THIS SIDE UP CE CÔTÉ VERS LE HAUT ESTE LADO HACIA ARRIBA...
  • Page 12 Note: remove the tie wraps Remarque: retirez l'attache de câble Nota: retire los cordones de amarre Tie wrap Attache Cordón de amarre...
  • Page 15 Remove and reuse in next step Enlevez et réemploi dans l'étape suivante Retire y vuelva a usar en el siguiente paso Tighten the screws Serrez les vis Apriete los tornillos...
  • Page 16 Inspect your infrared grate before each use to ensure that the openings are not covered with debris. See the Grilling Guide for detailed cleaning instructions. Inspectez votre grille infrarouge avant chaque utilisation pour vous assurer que les orifices ne sont pas recouverts de débris.
  • Page 18 Tie wrap Attache Cordón de amarre Note: remove the tie wraps Remarque: retirez l'attache de câble Nota: retire los cordones de amarre CAUTION Failure to install grease tray will cause hot grease to drip from bottom of grill with risk of fire or property damage. ATTENTION Si le plateau d'écoulement de la graisse n'est pas installé, de la graisse chaude...
  • Page 19 PRESS OPRIMA APPUYEZ...
  • Page 20 LP Cylinder (not included) Réservoir de gaz (non compris) Tanque de gas (no viene incluido) CAUTION Cylinder valve must face to front of cart once tank is attached. Failure to install cylinder correctly may allow gas hose to be damaged in operation, resulting in the risk of fire.

  • Page 21: Troubleshooting

    EMERGENCIES: If a gas leak cannot be stopped, or a fire occurs due to gas leakage, call the fire department. Emergencies Possible Cause Prevention/Solution Gas leaking from • Damaged hose. •Turn off gas at LP cylinder or at source on natural gas systems. Discontinue use of cracked/cut/burned hose.
  • Page 22 Troubleshooting (continued) Problem Possible Cause Prevention/Solution Sudden drop in gas flow or • Check for gas in LP cylinder. • Out of gas. low flame. • Excess flow valve tripped. • Turn off knobs, wait 30 seconds and light grill. If flames are still low, turn off knobs and LP cylinder valve.

  • Page 23: Parts Diagram

    PARTS DIAGRAM/ SCHÉMA DES PIÈCES / VISTA ESQUEMÁTICA DE PIEZAS...

  • Page 24: Parts List

    PARTS LIST Qty Description Qty Description TOP LID BOTTOM SHELF LOGO PLATE F/ LID TANK SCREW, F/ BOTTOM SHELF RUBBER BUMPER, W/ HOLE, F/ TOP LID RAIL, F/ GREASE TRAY LID BUMPER, ROUND GREASE TRAY HANDLE F/ LID HEAT SHIELD, F/ TANK BEZEL, F/ LID HANDLE CASTER, LOCKING THERMOMETER...
  • Page 25 HARDWARE LIST/ LISTA DE HERRAJES/ LISTE DES FERRURES Key/ Réf./ Clave Description/ Description/ Descripción Qty/ Qté/ Cant Picture/ Illustré/ Ilustra 1/4-20x1-1/2" Screw Vis ¼-20×1½ po Tornillo de 1/4 -20 x 1-1/2" 1/4-20x1/2" Screw Vis ¼-20×½ po Tornillo de 1/4 -20 x 1/2"...
  • Page 26 ©2015 Char-Broil, LLC. Columbus, GA, 31902. Printed in China. Imprimé en China. Impreso en China. ©2015 Assembly instructions. ©2015 Assemblée des instructions. ©2015 Instrucciones de ensamblado.
