Interchangeable Lens
Digital Camera
E-mount
Instruction Manual
"Help Guide" (Web manual)
Refer to "Help Guide" for in-depth
instructions on the many functions of
the camera.
http://rd1.sony.net/help/ilc/1530/h_zz/
ILCE-7SM2
4-581-534-12(1)
