- Page 1 USER MANUAL C20501 20" Pure Flat Screen Stereo Television Please read this manual carefully before using this TV set and keep it for future reference.
-
Page 2: Table Of Contents
PRECAUTIONS FCC WARNING-This equipment may CAUTION:USE OF CONTROLS OR generate or use radio frequency ADJUSTMENTS OR PERFORMANCE energy.Changes or modifications to this OF PROCEDURES OTHER THAN equipment may cause harmful THOSE SPECIFIED HEREIN MAY interference unless the modifications are RESULT IN HAZARDOUS RADIATION expressly approved in the instruction EXPOSURE. -
Page 3: Warning And Cautions
Important safety Instructions WARNING:TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. CAUTION THIS SYMBOL INDICATES THAT DANGEROUS RISK OF ELECTRIC SHOCK VOLTAGE CONSTITUTING A RISK OF ELECTRIC DO NOT OPEN SHOCK IS PRESENT WITHIN THIS UNIT. - Page 4 Important safety Instructions 11. GROUNDING OR POLARIZATION This unit is equipped with a polarized alternating-current line plug (a plug having one blade wider than the other). This plug will fit into the power outlet only one way. This is a safety feature.
- Page 5 Important safety Instructions 19. DAMAGE REQUIRING SERVICE Unplug this unit from the wall outlet and refer servicing to qualified service personnel under the following conditions: a. When the power-supply cord or plug is damaged. b. If liquid has been spilled, or objects have fallen into the unit. c.
-
Page 6: Installation
Installation Antenna connection Generally speaking, to enjoy a clearer picture, we recommend that you use a CATV system or an outdoor antenna .In different places, the suitable antenna type and position may vary. Mixer (not incl.) Antenna/ CATV input standard coaxial type AC power socket Note:... -
Page 7: Function Buttons And External Connections
Function Buttons and External Connections Front and side panel of the TV set VIDEO Video Input terminal Audio Input AUDIO terminal Power indicator Sensor window Power switch MENU Volume up/ down AV TV (input selector Channel selector Back panel Antenna input socket Video output terminal Audio right channel output terminal Video input terminal... -
Page 8: Using The Remote Control
Using the Remote Control Buttons on the remote control : To turn power ON or OFF 2. MENU: You can select the menu by pressing the MENU button. You can call on the menu by pressing the corresponding button on the remote MENU control. -
Page 9: Menu Functions
Menu Functions Information to user: This television receiver is equipped with close caption decoder and parental blocking technology as required by the FCC. Menu Functions Video Setup: Pressing MENU button once will bring the Video Setup menu on the TV. The following is shown on your TV screen: Video Picture... - Page 10 Menu Functions (Continued) Audio Setup: By pressing MENU button ,and then pressing VOL(-/+) buttons it will bring you to Audio Setup display. You will see the following menu on your TV screen: Audio Volume Follow the procedure below to adjust the sound quality: Press VOL (+) button to increase and VOL (-)button to decrease the level to your preference.
- Page 11 Menu Functions (Continued) Function Setup: By pressing the MENU button, and then pressing VOL(-/+) buttons will bring you to Function Setup menu. You will see the following menu on your screen: Setup Language English Background Black stretch Fade C. Caption Demo mode Follow the procedure below to select one of the above options: 1.Press the CH(+) and CH(-) button to go up and down the menu.
- Page 12 Menu Functions (Continued) Channel setup: By pressing MENU button ,and then pressing VOL-/+ button it will bring you to Channel Setup. You will see the following display on TV screen. Channel Channel System Auto Antenna Skip Current Ch. Fine Auto Program Follow the procedure below to select above options: 1.Press the CH(+) and CH(-) button to go up and down the menu.
- Page 13 Menu Functions (Continued) Calendar: Your TV has been designed with a calendar. By pressing MENU button ,and then pressing VOL(-/+) buttons it will bring you to Calendar. You will see the following display on TV screen. Calendar Solar 2005 9 14 Follow the procedure below to adjust the Calendar quality: Press the CH( +/-) buttons...
- Page 14 Menu Functions (Continued) V-CHIP Setup: Press the MENU Button on your remote control to go to Password menu, then input the password (0000). It will bring Parental Lock set up display on the screen. You will see the following menu on your screen: Parental Lock Passsword Password...
- Page 15 Menu Functions (Continued) When MPAA Rating is selected, you will see the following rating table on your TV screen. MPAA Rating P G - 1 3 NC-17 U Note: You can press CH(+/-) buttons to go up and down the menu, then press VOL(+) button to select "B"...
- Page 16 Menu Functions (Continued) V-Chip Technology: The "V-Chip Technology" allow you to use U.S. And Canada Movies and TV PROGRAMS Guide ratings to block certain types of TV programs and movies. To understand clearly about TV programs rating codes, read the following list: U.S.
- Page 17 Menu Functions (Continued) To understand clearly about movies rating codes, read the following list: U.S. Movies Rating Chart This means movie is not rated yet. It is pending government rating approval. General Audience-this type of movie rating means all ages admitted to see the movie.
-
Page 18: Connection To The External Audio And Video Equipment
Connecting the TV set to the other video and audio equipment Connection of AV input /output terminal The figure below shows how to connect external equipment using AV signals. DVD PLAYER Audio right input Audio left input Video input output Audio right output Audio left... -
Page 19: Troubleshooting Guide
Troubleshooting guide To assist in location possible faults use help guide below BREAKDOWN PHENOMENON CHECKING PICTURE SOUND The aerial direction and connection Picture with snow Noise This is called "ghosting" and can be minimized with an outside aerial, and good quality cable and terminations. -
Page 20: Specifications
Specifications The specifications offered you here are for reference only. With product improvement there may be some differences between the description and the final product. Specifications M o d e l C20501 Colour system NTSC Sound system Picture tube 20 colour picture tube... -
Page 21: Warranty
Citizen product or the loss of information. The purchaser will be responsible for any removal, reinstallation, transportation and insurance costs incurred. Correction of defects, in the manner...
