Summary of Contents for AirTight C-65
- Page 1 Installation Guide C-65 Access Point/Sensor ©2014-2015 AirTight Networks, Inc. All rights reserved. 339 N. Bernardo Avenue, # 200, Mountain View, CA 94043 www.airtightnetworks.com...
- Page 2 This page is intentionally left blank.
- Page 3 WIPS, AirTight Cloud Services, and AirTight devices under any legal theory, including but not limited to lost profits, lost data, or business interruption, even if AirTight Networks knows of or should have known of the possibility of such damages. Regardless of the cause of action or the form of action, the total cumulative liability of AirTight...
- Page 4 FOR COUNTRY CODE SELECTION USAGE (WLAN DEVICES) Note: The country code selection is for non-US models only and is not available to all US models. Per FCC regulations, all Wi-Fi products marketed in the US must be fixed to US operation channels only. C-65 Installation Guide...
- Page 5 Cet equipement est conforme aux limites d’exposition aux rayonnements IC etablies pour un environnement non controle. Cet equipement doit @tre installe et utilise avec un minimum de 20 cm de distance entre la source de rayonnement et votre cmps. C-65 Installation Guide...
-
Page 6: About This Guide
4. Manually Configuring C-65 5. Config Shell Commands 6. Troubleshooting Note: All instances of the term ‘server’ in this document refer to the AirTight Wi-Fi / AirTight WIPS server, unless the server name or type is explicitly stated. Product and Documentation Updates To receive important news on product updates, please visit our website at http://www.airtightnetworks.com. -
Page 7: Package Contents
Package Contents Please ensure that the items shown in Figure 1-1 are included in the C-65 device package: Figure 1-1 C-65 Package Contents Note: The MAC address of the device is printed on a label at the bottom of the product and the packaging box. - Page 8 C-65 Overview C-65 is a 2x2:2 802.11 a/b/g/n/ac access point/sensor. This chapter provides an overview of the C-65 and describes front and the rear panels. The front panel of the C-65 has 4 LEDs that indicate the working of the device.
- Page 9 Green The rear panel of the C-65 has an Ethernet port labeled LAN1, that enables you to connect the device a wired LAN through a switch or a hub and provides the power for the device by using the 802.3af standard.
- Page 10 802.3af standard The Reset Pin Hole is shown in the figure above. The Reset Pin Hole resets the C-65 device to factory defaults. To reset the device, power cycle the device (remove the power cable once and connect it back again) and while plugging the power cable back into the power source, press and hold down the Reset Pin Hole for 45 seconds until the power, LAN1, 2.4 GHz LEDs go green.
-
Page 11: Installing The C
(802.1Q capable) on a switch. The device then monitors the VLANs that are configured on that trunk port and are chosen by the user. In this mode, an C-65 can monitor up to 16 VLANs. The wireless interface of the sensor is enabled for WIPS operations. - Page 12 Ceiling Mounting Use the mounting bracket to install the C-65 on the ceiling. To mount the device: 1. Attach the mounting bracket to the device. 2. Slide the device on to the T-rail affixed to the ceiling. Given below is the diagrammatic representation of ceiling mounting of the C-65 device.
- Page 13 Figure 3-2 Wall Mounting Power On C-65 A C-65 device can be powered on by 802.3af Class 0 Power Over Ethernet (PoE) of Nominal input voltage 48V DC. You can connect the device to the network using PoE or a power adapter.
- Page 14 Wait until the device is ready. Refer to the respective LED details table based on the configured device mode. Figure 3-4. Power Up C-65 To connect C-65 to the network, perform the following steps: 1. Ensure that a DHCP server is available on the network to provide network configuration to the C-65. C-65 Installation Guide...
- Page 15 2. Connect one end of the network interface cable to the Ethernet port at the rear of the C-65. 3. Connect the other end of the network interface cable to an Ethernet jack on the desired subnet. Wait until the device is ready (approx. 10 mins).
-
Page 16: Configuring Ap Through Config Shell
Device is placed on a subnet that is not DHCP enabled. Configuring AP through Config Shell The Config Shell supports a pre-defined set of commands used to configure the C-65 device. Log in to the device console using the SSH shell. - Page 17 9. Remove the crossover connection to the computer and connect the Ethernet port to the local switch. Configure IPv6 settings C-65 is IPv6 capable. Use the set ipv6 config command to configure advanced options such as DHCP settings, auto negotiation, and manual configuration.
- Page 18 To configure the communication key or passphrase kindly refer to Appendix A: AP-Server Mutual Authentication for further details. C-65 Installation Guide...
- Page 19 C-65 Config Shell Commands The following tables detail the C-65 config shell commands. C-65 Installation Guide...
- Page 20 Displays wireless profiles and associated clients. get ap status get presence Displays the value of the presence notification parameters, that is, RSSI value in dbm, notification time interval in seconds, and IP address or host name of the presence notification parameters server. C-65 Installation Guide...
- Page 21 RSSI value in dbm, IP address/hostname of the presence notification server parameters and time interval in seconds. The RSSI value can range between -127 and 0 dbm. The time interval can range between 0 and 14400 seconds. C-65 Installation Guide...
- Page 22 Disables the presence notification feature. presence notification disable reboot Reboots the AP restart Restarts the AP application Resets the AP to ‘out of the box’ status reset factory upgrade Upgrades the AP manually from a given IP address C-65 Installation Guide...
- Page 23 C-65 Troubleshooting Following are the troubleshooting guidelines for C-65. Symptoms Diagnosis Solution The device did not Ensure that the DHCP server is on and available on the receive a valid IP VLAN/subnet to which the device is connected. If the device...
-
Page 24: Appendix A: Access Point (Ap)-Server Mutual Authentication
Note: Although the server is backward compatible, that is, older version APs can connect to a newer version server, this is not recommended. C-65 Installation Guide...
