Antsig AA1200 Installation Manual page 7

Stage 5. FINAL INSTALLATION
Final installation of the antenna should be done as per example below:
ANTENNA
ANTENNA
MAST
CABLE
DRIP LOOP
Recommended for low signal areas
Mount on antenna mast or near by wall
TO
ANTENNA
MASTHEAD
AMPLIFIER
MASTHEAD AMPLIFIER
POWER
PASS
VHF/UHF IN UHF IN OUT OUT
BALUN
TO
TRANSMITTER
SPLITTER
OPTION 1.
Masthead Amplifier
Requires 240 volt supply
TV
IN
TV 1
TV 1
'F' CONNECTOR
TV OUTLET
RG6 QUAD
CABLE
'F' CONNECTOR
TV OUTLET
OPTION 2.
Distribution Amplifier
Recommended for multiple TV's
Requires roof cavity mounting
Requires 240 volt supply
TO
ANTENNA
7
FLY LEAD
DISTRIBUTION
AMPLIFIER
VHF/ 1 2 3 4
UHF
Combo
TV 1
TO
OTHER TV
OUTLETS
Fig.5
