- Page 1 Installation Guide Avigilon High Definition H.264 IP Dome Camera Models: 1.0-H3-DO1, 1.0-H3-DO1-IR, 1.0-H3-DO2, 1.3L-H3-DO1, 1.3L-H3-DO2, 2.0-H3-DO1, 2.0-H3-DO1-IR, 2.0-H3-DO2, 3.0W-H3-DO1, 3.0W-H3-DO1-IR, 3.0W-H3-DO2, 5.0-H3-DO1, 5.0-H3-DO1-IR and 5.0-H3-DO2 920-0050D-Rev1...
- Page 3 Power over Ethernet (PoE), rated 48 VDC, 10 W min. • Any external power supply connected to this product may only be connected to another Avigilon product of the same model series. External power connections must be properly insulated. •...
- Page 4 • Do not use strong or abrasive detergents when cleaning the device body. • Use only accessories recommended by Avigilon. • Use of controls or adjustments or performance of procedures other than those specified in this document may result in hazardous radiation exposure.
- Page 5 Changes or modifications made to this equipment not expressly approved by Avigilon Corporation or parties authorized by Avigilon Corporation could void the user’s authority to operate this equipment. Disposal and Recycling Information...
- Page 6 The contents of this manual and the specifications of this product are subject to change without notice. Avigilon reserves the right to make changes without notice in the specifications and materials contained herein and shall not be...
-
Page 7: Table Of Contents
Table of Contents Overview ......1 Cover View ....... 1 Bottom View . -
Page 9: Overview
Overview Cover View Tamper Proof Screws Dome Cover Cable Entry Hole Feature Description Dome Cover Vandal proof dome cover constructed out of plastic with a polycarbonate bubble. Tamper Proof Screws TORX tamper-resistant captive screws to fix the dome cover to the base. Cable Entry Hole An entry hole for network, power and I/O cables. -
Page 10: Bottom View
Bottom View Cable Entry Hole Dome Mounting Holes Feature Description Cable Entry Hole An entry hole for network, power and I/O cables. Mounting Holes Mounting points for the dome camera. -
Page 11: Front View
Front View Serial Number Tag Azimuth Control Tilt Lock Thumb Screw Link LED Pan Lock Thumb Screw Connection Status Ethernet Port Power Connector Block I/O Terminals Audio/Video Connector Feature Description Tilt Lock Thumb Provides a locking mechanism for the image tilt Screws adjustment. -
Page 12: Ir View
IR View IR Illuminator Ring Feature Description IR Illuminator Ring Provides scene illumination in the IR spectrum. The IR illuminator ring is not included with all models. -
Page 13: Installation
Small slotted screwdriver with 5/64” or 2 mm blade width — for connecting power when not using Power over Ethernet. Camera Package Contents Ensure the package contains the following: • Avigilon High Definition IP Dome Camera • Terminal block • T20 TORX tamper resistant key •... -
Page 14: Removing The Dome Cover
Removing the Dome Cover Remove the dome cover by loosening the tamper-proof screws that fix the cover to the base. The tamper resistant key included with the dome camera can be used to loosen the screws. NOTE: Be careful not to scratch or touch the dome bubble. The resulting marks or fingerprints may affect the overall image quality. - Page 15 When installing the dome camera outdoors, ensure the conduit and its fitting are designed for outdoor use and have a suitable IP rating. The conduit must be sealed to ensure excessive moisture does not enter the dome and cause condensation. Use the drill template to drill four mounting holes in the ceiling or wall.
-
Page 16: Connecting Cables
Figure: Dome camera installation. Connecting Cables Refer to the diagrams in the Overview section for the location of the different connectors. To connect the cables required for proper operation, complete the following: If there are external input or output devices that need to be connected to the camera (for example: door contacts, relays, etc), connect the devices to the camera I/O Terminals. -
Page 17: Assigning An Ip Address
Zeroconf, the IP address is in the 169.254.0.0/16 subnet. The IP address settings can be changed using one of the following methods: • Avigilon Camera Installation Tool software application. • Camera's web browser interface: http://<camera IP address>/ •... -
Page 18: Aiming The Dome Camera
Rotate the azimuth control ring to set the image to the correct angle. In the Avigilon Camera Installation Tool, adjust the camera’s Image and Display settings to achieve the desired zoom position. Installing the Dome Cover... -
Page 19: Focusing The Dome Camera
• In the Avigilon Camera Installation Tool, use the camera’s Image and Display settings to focus the camera lens. Click the Auto Focus button to focus the lens. -
Page 20: Cable Connections
Cable Connections Connecting External Power NOTE: Do not perform this procedure if Power over Ethernet (POE) is used. If PoE is not available, the dome camera needs to be powered through the removable power connector block. Refer to the diagrams in this guide for the location of the power connector block. -
Page 21: Connecting To External Devices
Connecting to External Devices External devices are connected to the camera through the I/O terminal. The pinout for the I/O terminal is shown in the following table and diagram. Table:External I/O Terminals Function Description Ground Ground Input To activate, connect the Input to the Ground pin. -
Page 22: Connecting To Microphones, Speakers And Video Monitors
When the camera flicker control is set to 60 Hz, the video output signal is NTSC. When the flicker control is set to 50 Hz, the video output signal is PAL. Use the Avigilon Camera Installation Tool to configure the camera’s flicker control in the Image and Display setup. -
Page 23: Led Indicators
LED Indicators Once the camera is connected to the network, the Connection Status LED will display the camera’s progress in connecting to the Network Video Management software. The following table describes what the LEDs indicate: Table:LED Indicators Connection Connection Description State Status LED Obtaining IP... -
Page 24: Reset To Factory Default Settings
Reset to Factory Default Settings If the camera no longer functions as expected, you can choose to restore the camera to its factory default settings. Use the firmware revert button to reset the camera. Firmware Revert Button Figure: The firmware revert button on the side of the dome camera. Disconnect power from the camera. -
Page 25: Setting The Ip Address Through The Arp/Ping
Setting the IP Address Through the ARP/Ping Method Complete the following steps to configure the camera to use a specific IP address: Locate and copy down the MAC Address (MAC) listed on the Serial Number Tag for reference. Open a Command Prompt window and enter the following commands: arp -s <New Camera IP Address>... -
Page 26: Specifications
Specifications H3-DO1 H3-DO2 Camera Audio Input Line input, A/V mini-jack (3.5 mm) Video Output NTSC/PAL, A/V mini-jack (3.5 mm) Lens 3-9mm, F1.2, P-iris 9-22mm, F1.6, P-iris Network Network 100Base-TX Cabling Type CAT5 Connector RJ-45 ONVIF compliance version 1.02, 2.00, Profile S (www.onvif.org) Security Password protection, HTTPS encryption, digest authentication, WS authentication, user access log... -
Page 27: Limited Warranty & Technical Support
Limited Warranty & Technical Support Avigilon warrants to the original consumer purchaser, that this product will be free of defects in material and workmanship for a period of 3 years from date of purchase. The manufacturer’s liability hereunder is limited to replacement of the product, repair of the product or replacement of the product with repaired product at the discretion of the manufacturer. - Page 28 © 8/20/13 Avigilon Corporation...
