GAS/ELECTRIC RANGE
for residential use only
VEFSGE304P..
Models:
INSTALLATION INSTRUCTIONS
IMPORTANT - PLEASE READ AND FOLLOW
• Before beginning, please read these instructions completely and carefully.
• Do not remove permanently affixed labels, warnings, or plates from the product. This may
void the warranty.
• Please observe all local and national codes and ordinances.
• Please ensure that this product is properly grounded.
•
The installer should leave these instructions with the consumer who should retain
for local inspector's use and for future reference.
Installation must conform with local codes or in the absence of codes, the National Fuel Gas
Code ANSIZ223.1 - Iatest edition. Electrical installation must be in accordance with the Na-
tional Electrical Code, ANSI/NFPA70 - latest edition and/or local codes.
IN CANADA: Installation must be in accordance with the current CAN/CGA-B149.1 National
Gas Installation Code or CAN/CGA-B149.2, Propane Installation Code and/or local codes.
Electrical installation must be in accordance with the current CSA C22.1 Canadian Electrical
Codes Part 1 and/or local codes.
INSTALLATION IN MANUFACTURED (MOBILE) HOME: The installation must conform with
the Manufactured Home Construction and Safety Standard, Title 24 CFR, Part 3280 [formerly
the Federal Standard for Mobile Home Construction and Safety, Title 24, HUD (Part 280)]
or, when such standard is not applicable, the Standard for Manufactured Home Installations,
ANSI/NCSBCS A225.1, or with local codes where applicable.
INSTALLATION IN RECREATIONAL PARK TRAILERS: The installation must conform with
state or other codes or, in the absence of such codes, with the Standard for Recreational
Park Trailers, ANSI A119.5.
Installation of any gas-fired equipment should be made by a licensed plumber. A manual
shut-off valve must be installed in an accessible location in the gas line external to the ap-
pliance for the purpose of turning on or shutting off gas to the appliance (In Massachusetts
such shutoff devices should be approved by the Board of State Examiners of Plumbers &
Gas Fitters).
If an external electrical source is utilized, the appliance, when installed, must be electrically
grounded in accordance with local codes or, in the absence of local codes, with the national
Electrical Code, ANSI/NFPA 70.
Some models are supplied with a protective film on steel and aluminium
parts. This film must be removed before installing/using the appliance.
THIS RANGE IS FOR RESIDENTIAL USE ONLY
FOR INSTALLER ONLY
R
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Verona VEFSGE304P
Summary of Contents for Verona VEFSGE304P
- Page 1 GAS/ELECTRIC RANGE for residential use only VEFSGE304P.. Models: INSTALLATION INSTRUCTIONS IMPORTANT - PLEASE READ AND FOLLOW • Before beginning, please read these instructions completely and carefully. • Do not remove permanently affixed labels, warnings, or plates from the product. This may void the warranty. • Please observe all local and national codes and ordinances. • Please ensure that this product is properly grounded. • The installer should leave these instructions with the consumer who should retain for local inspector’s use and for future reference.
-
Page 2: What To Do If You Smell Gas
WARNING ! To reduce the risk of tipping the appliance, the appliance must be secured by properly installed anti-tip device packed with the appliance. • ALL RANGES CAN TIP • INJURY TO PERSONS COULD RESULT • INSTALL ANTI-TIP DEVICE PACKED WITH RANGE •... - Page 3 DATA PLATE CONVERSION LABEL This appliance is designed and manufactured solely for the cooking of domestic (household) food and in not suitable for any none domestic application and therefore should not be used in a com- mercial environmement. The appliance warranty will be void if the appliance is used within a none domestic environmement i.e. a semi commercial, commercial or communal environment.
-
Page 4: Installation Instructions
INSTALLATION INSTRUCTIONS WARNING! THIS APPLIANCE MUST BE INSTALLED BY A QUALIFIED INSTALLER. Improper installation, adjustment, alteration, services, or maintenance can cause injury or property damage. Consult a quali- fied installer, service agent, or the gas supplier. IMPORTANT: The use of suitable protective clothing/gloves is recommended when handling, installing of this appliance. -
Page 5: General Information
GENERAL INFORMATION WARNING!! 1. Installation must conform with local codes or, in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.1- ELECTRICAL GROUNDING INSTRUCTIONS Latest Edition, CAN/CGA-B149.1 or CAN/CGA-B149.2. The range must be electrically grounded in accordance with 2. Installation in manufactured (mobile) home: installation must local codes or, in the absence of local codes, with the Natio- conform with the Manufactured Home Construction and nal Electrical Code, ANSI/NFPA No. - Page 6 installation PROXIMITY TO SIDE CABINETS 1. This range may be installed directly adjacent to existing 36” (914 mm) high base cabinets. Range dimensions: • width: 29” 7/8 (759 mm) • depth: 24” 13/64 (614.9 mm) • height (without backguard): MIN 35” 21/32 (905.5 mm) - MAX 36” 11/32 (923 mm) • backguard (height): 3” (76 mm) Gas line opening: Wall - 37/64” (14.5 mm) from the right side to centre of range; from 5” 7/16 (138 mm) to 6” 1/8 (155.5 mm) [depending on feet regulation] from the floor. Grounded outlet: should be located 37/64” (14.5 mm) from the left side to centre of range; from 5” 7/16 (138 mm) to 6” 1/8 (155.5 mm) [depen- ding on feet regulation] from the floor. 2. The range CANNOT be installed directly adjacent to sidewalls, tall cabi- nets, tall appliances, or other side vertical surfaces above 36” (914 mm) high.
-
Page 7: Assembling The Backguard
GAS AND ELECTRIC CONNECTION Dotted line showing the position of the range when installed Ref. inch 5” 7/16 - 6” 1/8 138 - 155.5 14” 3/8 37/64” 14.5 (*) : Depending on feet regulation Area for ELECTRICAL connection Area for GAS connection Fig. 1.2 ASSEMBLING THE BACKGUARD It is mandatory to install the backguard. Assemble the backguard as shown in figure 1.3: • Screw the 2 screws “A” interposing the spacers. • Screw the central screw “B”. Fig. 1.3... -
Page 8: Oven Vent
PROXIMITY TO SIDE CABINETS STANDARD INSTALLATION Ref. inch Fig. 1.4a 0” 36” 11” 13/16 30” minimum 762 minimum 18” minimum 457 minimum 13” maximum 330 maximum 20” minimum 500 minimum Fig. 1.4b OVEN VENT OVEN VENT... - Page 9 PROXIMITY TO SIDE CABINETS ISLAND INSTALLATION Ref. inch Fig. 1.5a 0” 36” 11” 13/16 30” minimum 762 minimum 18” minimum 457 minimum 13” maximum 330 maximum 20” minimum 500 minimum 12” minimum 305 minimum Fig. 1.5b OVEN VENT OVEN VENT...
- Page 10 LEVELLING THE RANGE The range is equipped with 4 LEVELLING FEET and may be levelled by screwing or unscrewing the feet (figs. 1.6 - 1.7). It is important to observe the directions of figures 1.6, 1.8a, 1.8b. Fig. 1.6 Supplied with the range Supplied with the range in a separate kit in a separate kit 0” + 5/16” 0 mm + 8 mm + 5/16” + 11/16” + 8 mm Fig. 1.8a Fig. 1.8b + 17.5 mm Fig. 1.7 ANTI-TIP STABILITY DEVICE INSTALLATION INSTRUCTIONS YOU MUST USE STABILITY 1. The anti-tip bracket has to be attached as shown on figure below (only rear left side), ANTI TIP BRACKET TO it has to be fixed on the floor and on the rear wall by no. 6 (six) suitable screws (not PREVENT UNIT...
- Page 11 INSTALLING THE COOKTOP FRONT GUARD To increase the clearance between the front edge of the cooktop and the burners it is possible to install the cooktop front guard supplied with the appliance. IMPORTANT: To install/remove the guard it is necessary to remove the cooktop. Attempting to install/remove the guard without disassembling the cooktop will result in permanent damage to the appliance. Install the front guard as shown in figure 1.10: 1. Remove the backguard. 2. Remove the pan supports and the burner flame spreaders. 3. Unscrew cooktop fixing screws (“A” in figure below).
- Page 12 gas connection All gas connections must be made according to national and local codes. This gas supply (service) line must be the same size or greater than the inlet line of the appliance. Sea- lant on all pipe joints must be resistant to the action of LP/Propane gas. The range is equipped for the use with NATURAL gas. It is design-certified by CSA Inter- national for NATURAL and L.P. gases with appropriate conversion. The model/serial rating plate, located on the back of the appliance, has information on the type of gas that can be used. If this information does not agree with the type of gas available, check with the local gas supplier. See page from 16 to 19 for L.P. gas conver- sion instructions. Explosion Hazard Use a new CSA or UL approved 1. Manual Shut-off Valve (fig: 2.1) gas supply line. A manual shut-off valve must be installed in an accessible location in the gas line external Install a shut-off valve. to the appliance for the purpose of turning on or shutting off gas to the appliance (In Mas- Securely tighten all gas connec- sachusetts such shutoff devices should be approved by the Board of State Examiners of tions.
- Page 13 PRESSURE REGULATOR INSTALLATION STEP 1 Mount the 1/2” NPT (conical) male connector to the pressure regulator and tighten by using a wrench. LOCK Do not over tighten the connector. Over tightening may crack regulator. Arrow Fig. 2.2 STEP 2 Assemble the 1/2” NPT connector + pressure regulator group to the extension pipe interposing the gasket supplied. The regulator cover must be oriented toward the front side of the range. IMPORTANT: use two wrenches to tighten the connection. Gasket Regulator cover Fig. 2.3...
- Page 14 GAS CONNECTION SPEFICICATION Range manifold Manifold male pipe fitting 1/2” G cylindrical (ISO 228-1) male Gasket 1/2” G cylindrical To range (ISO 228-1) female Extension pipe female pipe fitting Extension pipe Extension 1/2” G cylindrical pipe male (ISO 228-1) male pipe fitting 1/2” G cylindrical Gasket (ISO 228-1) female 1/2” NPT (conical) Connector male 1/2” NPT To mains female connection Pressure regulator 1/2” NPT female...
- Page 15 b. Any conversion required must be performed by your dealer or a qualified licen- sed technician or gas service company. Please provide the service person with TEST POINT ADAPTER this manual before work is started on the range. (Gas conversions are the re- The Test Point adapter is available from the sponsibility of the dealer or end user.) After-Sales Service. c. This range can be used with NATURAL or LP/PROPANE gas. It is shipped from the factory adjusted for use with NATURAL gas. d. Manifold pressure should be checked with a manometer and by operating as below detailed: • Remove the injector from the rear left (or rear right) burner and mount the proper test point adapter which is available from the After-Sales Service (see side figure and the “OPERATIONS TO BE PERFORMED WHEN SUB- STITUTING THE INJECTORS” chapter).
-
Page 16: Conversion To Lp/Propane Gas
CONVERSION TO LP/PROPANE GAS Every range is provided with a set of injectors for the various types of gas. Select the injectors to be replaced according to the “INJECTORS TABLE”. The nozzle diameters, expressed in hundredths of a millimetre, are marked on the body of each injector. SETTING THE PRESSURE REGULATOR (fig. 2.6) The pressure regulator is accessible by removing the warmer drawer; the pressure regulator is positioned on the rear right side of the range (fig. 2.9). To remove the warming drawer: 1. Open the drawer completely (fig. 2.6) 2. Move down the lever of left guide (fig. 2.7) and up the lever of right guide (fig. 2.8). 3. Remove the drawer; the levers have to be keep moved (fig. 2.6). Fig. 2.8 Fig. 2.6 Fig. 2.7... - Page 17 To set the pressure regulator (fig. 2.9) 1. Unscrew the regulator cover. 2. Unscrew the “A” component, reverse and screw it accor- ding to the LP/PROPANE regulation. Pressure regulator REGULATOR COVER Fig. 2.9 NATURAL GAS LP/PROPANE REGULATION REGULATION Fitting the warming drawer (fig. 2.10) 1. Insert the drawer guides into the range guides (fig. 2.10). 2. Gently close the drawer completely; the safety catchs will be automatically hooked. Fig. 2.10...
-
Page 18: Injectors Table
INJECTORS TABLE NOMINAL REDUCED LP/PROPANE NATURAL GAS POWER POWER 11” W.C.P. 4” W.C.P. Ø injector Ø injector BURNERS BTU/hr BTU/hr [1/100 mm] [1/100 mm] Semirapid (SR) 8000 1500 42 (*) 70 (*) Inner crown 2100 1000 Dual (D) Inner & outer crown 17000 6500 115 (#) 200 (#) (*) inner crown (“J ” in figure 2.12) (#) outer crown (“J ” in figure 2.12) OPERATIONS TO BE PERFORMED WHEN SUBSTITUTING THE SEMI-RAPID BURNER INJECTORS •... - Page 19 SETTING THE BURNER MINIMUM When switching from one type of gas to another, the minimum flow rate must also be cor- rect: the flame should not go out even when passing suddenly from maximum to minimum flame. To regulate the flame (fig. 2.13) follow the instructions below: Semirapid burner • Light the burner. • Set the gas valve to “ ” position (minimum rate). • Remove the knob. • With a thin screwdriver, turn the regulation screw “R ” until adjustment is correct. Inside crown of DUAL burner • Light the DUAL burner. • Set the gas valve to “ ” position (minimum rate of inner crown). • Remove the knob • With a thin screwdriver, turn the regulation screw “R ” until adjustment is correct. Outside crown of DUAL burner •...
-
Page 20: Electrical Requirements
electrical connection ELECTRICAL REQUIREMENTS • This appliance must be properly installed and grounded by a qualified technician in WARNING accordance with the National Electrical Code ANSI/NFPA No.70 (latest edition) and local electrical code requirements. • This appliance may be connected by means of permanent “Hard Wiring” or “Power TO AVOID ELECTRICAL SHOCK HA- Supply Cord kit”. ZARD, BEFORE INSTALLING THE APPLIANCE, SWITCH POWER OFF • Power supply cord is not supplied, but it is available through your local electric sup- AT THE SERVICE PANEL AND LOCK ply house. THE PANEL TO PREVENT THE PO- •... - Page 21 3-Wire Power Cord Installation (See Figure 3.2) Fig. 3.1 Screws 1. Remove the Terminal Block Access Plate on the back of the range by unscrewing the 4 fixing Screws (Figure 3.1). 2. Check the correct positioning of the Power Cord Bracket as per figure 3.2. 3. Assemble the strain relief in the hole on Power Cord Bracket. 4. Insert the Power Cord through the strain relief and tighten. 5. Remove the 3 wire terminal nuts and washers from the Termi- nal Block. Screws 6. Plug the terminal holes of Power Cord. The Neutral or Ground Wire of the Power Cord must be con- nected to the neutral terminal located in the center of Terminal Block.
- Page 22 3-Wire Conduit Installation (See Figure 3.5) Fig. 3.4 Screws 1. Remove the Terminal Block Access Plate on the back of the range by unscrewing the 4 fixing Screws (Figure 3.4). 2. Check the correct positioning of the Conduit Bracket as per figure 3.5. 3. Feed 1/2” (1.3 cm) trade size Conduit through the hole in the Conduit Bracket and secure to the Conduit Bracket with a Conduit Clamp. 4. Plug the terminal holes of conductors. Screws The Neutral or Ground Wire must be connected to the neutral terminal located in the center of Terminal Block.
-
Page 23: Wiring Diagram
WIRING DIAGRAM... - Page 24 The manufacturer cannot be held responsible for possible inaccuracies due to printing or transcription errors in the present booklet. The manufacturer reserves the right to make all modifications to its products deemed necessary for manu- facture or commercial reasons at any moment and without prior notice, without jeopardising the essential functional and safety characteristics of the appliances. Cod. 1103877 - ß1...
