IES-1881
18-Port Industrial L2 Managed Fast Ethernet PoE
Switch, 802.3at PoE, 2 Ports Gigabit SFP/RJ45 Combo,
-40°C to 75°C, 16 PoE Outputs
User Manual
1
IES-1881 Manual

Advertisement

Table of Contents
loading

Related Manuals for LevelOne IES-1881

Summary of Contents for LevelOne IES-1881

  • Page 1: Quick Start Guide

    IES-1881 18-Port Industrial L2 Managed Fast Ethernet PoE Switch, 802.3at PoE, 2 Ports Gigabit SFP/RJ45 Combo, -40°C to 75°C, 16 PoE Outputs User Manual IES-1881 Manual...

  • Page 2: Physical Description

    10/100Base-TX Steady A valid network connection established. Link/ACT Transmitting or receiving data. Flashing ACT stands for ACTIVITY. Steady Connecting at 100Mbps speed. 10/100 Connecting at 10Mbps speed. Steady Power Device (PD) is connected. Power Device (PD) is disconnected. IES-1881 Manual...

  • Page 3: Functional Description

    RS-232 console, Telnet, SNMP v1 & v2c & v3, RMON, Web Browser,  and TFTP management. Supports Command Line Interface in RS-232 console.  Supports 8192 MAC addresses. Provides 2M bits memory buffer.  Supports IEEE802.3at Power over Ethernet (PoE) Power Sourcing  Equipment (PSE). IES-1881 Manual...
  • Page 4 For use in Pollution Degree 2 Environment.  Hardened metal case.  Supports Rack Mounting installation.  <Note> Make sure to readjust RTC Time of this switch to function accurately after this switch has been powered off for over 72 hours. IES-1881 Manual...

  • Page 5: Console Configuration

     At the “switch_a>” prompt just type in “enable” and press <Enter> to logon to Privileged Exec Mode (or Enable Mode). And the “switch_a#” prompt will show on the screen. Logon to Configure Mode (Configure Terminal Mode):  IES-1881 Manual...

  • Page 6: Web Configuration

    192.168.1.10/24” and press <Enter> to set new IP address (192.168.1.10) and new IP subnet mask (255.255.255.0) for Switch. Web Configuration Login the switch:  Specify the default IP address (192.168.1.10) of the switch in the web browser. A login window will be shown as below: IES-1881 Manual...
  • Page 7 Enter the factory default login ID: root.  Enter the factory default password (no password). Then click on the “Login” button to log on to the switch. IES-1881 Manual...

  • Page 8: Preface

    To get the most out of this manual, you should have an understanding of Ethernet networking concepts. In this manual, you will find: Features on the Illustrative LED functions  Installation instructions  Management Configuration   SNMP, IGMP… Specifications  IES-1881 Manual...

  • Page 9: Table Of Contents

    OWER Redundant 47~55VDC DC Terminal Block Power Inputs Alarms for Power Failure ONNECTING TO ETWORK Cable Type & Length Cabling Switch Management ANAGEMENT CCESS VERVIEW (CLI) DMINISTRATION ONSOLE Direct Access Modem Access ANAGEMENT SNMP-B ASED ETWORK ANAGEMENT ROTOCOLS IES-1881 Manual...
  • Page 10 VLAN SNMP 802.1 THER ROTOCOLS Command Line Console Management DMINISTRATION ONSOLE Exec Mode (View Mode) Privileged Exec Mode (Enable Mode) Configure Mode (Configure Terminal Mode) YSTEM WITCHING RUNKING VLAN SNMP 802.1 THER ROTOCOLS Specifications Appendix A Appendix B IES-1881 Manual...

  • Page 11: Product Overview

    When you unpack the product package, you shall find the items listed below. Please inspect the contents, and report any apparent damage or missing items immediately to your authorized reseller.   IES-1881 Manual  RS-232 cable  Rackmount brackets with screws IES-1881 Manual...

  • Page 12: Product Highlights

    @ -40℃ to 85℃ (-40℉ to 185℉). UL508 Industrial Control Equipment certified Maximum Surrounding Air Temperature @ 75℃ (167℉). For use in Pollution Degree 2 Environment.  Hardened metal case.  Supports Rack Mounting installation.  IES-1881 Manual...

  • Page 13: Management Support

    Console port access via RS-232 cable (CLI, Command Line Interface)  Telnet remote access  SNMP agent:  MIB-2 (RFC1213) Bridge MIB (RFC1493) RMON MIB (RFC2819) – statistics, history, alarm and events VLAN MIB (IEEE802.1Q/RFC2674) Private MIB Web browser  TFTP software-upgrade capability  IES-1881 Manual...

  • Page 14: Front Panel Display

    ACT stands for ACTIVITY. Steady Connecting at 100Mbps speed. No connection. 10/100/1000Base-TX, 1000Base-SX/LX/BX Steady A valid network connection established. Link/ACT Transmitting or receiving data. Flashing ACT stands for ACTIVITY. Steady Connecting at 1000Mbps speed. 1000 Not connecting at 1000Mbps speed. IES-1881 Manual...

  • Page 15: Physical Ports

    SC connector on 100Base-BX fiber port  SC connector on 1000Base-SX/LX/BX fiber port  MODE SELECTION 10Base-T full-duplex mode  10Base-T half-duplex mode  100Base-TX full-duplex mode  100Base-TX half-duplex mode  100Base-FX full-duplex mode  1000Base-T/SX/LX full-duplex mode  Auto-negotiating mode  IES-1881 Manual...

  • Page 16: Switch Management

    Administration console via RS-232 serial port (CLI) The switch provides an onboard serial port, which allows the switch to be configured via a directly connected terminal. External SNMP-based network management application The switch can also be configured via SNMP. IES-1881 Manual...

  • Page 17: Installation

    -The relative humidity should be less than 95 percent, non-condensing. -Surrounding electrical devices should not exceed the electromagnetic field (RFC) standards. -Make sure that the switch receives adequate ventilation. Do not block the ventilation holes on each side of the switch. Wiring Diagram IES-1881 Manual...

  • Page 18: Installation And Placement Instructions

    Step 3: Proceed to the “Connecting to Power” section. Connecting to Power Redundant 52~57VDC DC Terminal Block Power Inputs There are two pairs of power inputs for use with redundant power sources. You only need to have one power input connected to run the switch. IES-1881 Manual...

  • Page 19: Alarms For Power Failure

    The relay contact closes if Power1 and Power2 are both failed. FAULT Special note: The relay output is normal open position when there is no power to the switch. Please do not connect any power source to this terminal to prevent shorting your power supply. IES-1881 Manual...

  • Page 20: Connecting To Your Network

    100Base-BX 200 Mbps SMF (10μm) 20, 40 km 1000Base-SX 2000 Mbps 220 m (62.5μm) 2 km 1000Base-SX 2000 Mbps 550 m (50μm) 1000Base-LX 2000 Mbps SMF (10μm) 10, 20, 50 1000Base-BX 2000 Mbps SMF (10μm) 20, 40 km IES-1881 Manual...

  • Page 21: Cabling

    Connect one end of the cable to the switch and the other end to a desired device. Step 5: Once the connections between two end devices are made successfully, turn on the power and the switch is operational. IES-1881 Manual...

  • Page 22: Switch Management

    The switch gives you the flexibility to access and manage the switch using any or all of the following methods. The web browser interface and administration console (CLI) support are embedded in the switch software and are available for immediate use. IES-1881 Manual...

  • Page 23: Administration Console (Cli)

    A Macintosh or PC attachment can use any terminal-emulation program for connecting to the terminal serial port. A workstation attachment under UNIX can use an emulator such as TIP. IES-1881 Manual...

  • Page 24: Modem Access Management

    MIBs. However, if it only knows the get community string, it can only read MIBs. The default get and set community strings for the switch are public. IES-1881 Manual...

  • Page 25: Protocols

    (e.g. SNMP agent of web browser). The management architecture of the switch adheres to the IEEE open standard. This compliance assures customers that the switch is compatible with, and will interoperate with other solutions that adhere to the same open standard. IES-1881 Manual...

  • Page 26: Web-Based Browser Management

    The switch provides a web-based browser interface for configuring and managing the switch. This interface allows you to access the switch using a preferred web browser. This chapter describes how to configure the switch using its web-based browser interface. IES-1881 Manual...

  • Page 27: Snmp & Rmon Management

    MIB-II, Bridge MIB, and RMON MIB. RMON activities are performed at a Network Management Station running an SNMP network management application with graphical user interface. SNMP Agent and MIB-2 (RFC 1213) The SNMP Agent running on the switch manager CPU is responsible for: IES-1881 Manual...

  • Page 28: Rmon Mib (Rfc 2819) And Bridge Mib (Rfc 1493)

    RMON MIB definition. RMON Groups Supported The switch supports the following RMON MIB groups defined in RFC 2819: - RMON Statistics Group – maintains utilization and error statistics for the switch port being monitored. IES-1881 Manual...

  • Page 29: Bridge Groups Supported

    This group is applicable to transparent operation only and SRT bridges. - The dot1dStatic Group – contains objects that describe the entity’s destination-address filtering status. This group is applicable to any type of bridge which performs destination-address filtering. IES-1881 Manual...

  • Page 30: Web-Based Browser Management

    In your web browser, specify the IP address of the switch. Default IP address is 192.168.1.10. LOGIN Enter the factory default login ID: root. PASSWORD Enter the factory default password (no password). Or enter a user-defined password if you followed the instructions later and changed the factory default password. IES-1881 Manual...

  • Page 31: Understanding The Browser Interface

    Configuration, Port Status, Rate Control, RMON Statistics, Per Port Vlan Activities SWITCHING Bridging, Static MAC Entry, Port Mirroring, PoE, PoE Scheduling TRUNKING Port Trunking STP / RING Global Configuration, RSTP Port Setting, MSTP Properties, MSTP Instance Setting, MSTP Port Setting, Ring Setting IES-1881 Manual...
  • Page 32 VLAN VLAN Mode Setting, 802.1Q VLAN Setting, 802.1Q Port Setting, Port Based VLAN Global Configuration, 802.1p Priority, DSCP SNMP SNMP General Setting, SNMP v1/v2c, SNMP v3 802.1X Radius Configuration, Port Authentication OTHER PROTOCOLS GVRP, IGMP Snooping, NTP IES-1881 Manual...

  • Page 33: System

    System System Information The System name, Firmware version, MAC address, Default gateway, DNS Server, VLAN ID, IP Address, and IP Subnet Mask of Switch. IES-1881 Manual...
  • Page 34 Password: Click in “Password” text box. Type a password. Retype Password: Click in “Retype Password” text box. Type the same password in “Password” text box again to verify it. Updating setting: Click “Updating setting” button to update your settings. IES-1881 Manual...
  • Page 35 DNS Server Setting for the switch. Click the text box and type a new address to change the DNS Server. (Need to choose “Enable” from the “DNS Server” drop-down menu.) Submit: Click “Submit” button when you finished DNS Server. IES-1881 Manual...
  • Page 36 “Enable” from the “Auto save” drop-down list to disable or enable Auto save for the switch. Auto save interval (5~65536 sec): Click in “Auto save interval” text box and type a decimal number between 5 and 65536. Submit: Click “Submit” button when you finished Auto save configuration. IES-1881 Manual...
  • Page 37 Upgrade: Click “upgrade” button to upgrade firmware to the switch. Please follow the message on the screen during the firmware upgrade process. Do not turn off the power or perform other functions during this period of time. Reboot the switch after completing the upgrade process. IES-1881 Manual...
  • Page 38 Please follow the message on the screen during the firmware upgrade process. Do not turn off the power or perform other functions during this period of time. IES-1881 Manual...
  • Page 39 Firmware has been upgraded successfully to the switch. Reboot the switch after completing the upgrade process. IES-1881 Manual...
  • Page 40 “Power1~Power3” from the “Name” drop-down list. Trigger Enabled: Click “Trigger Enabled” drop-down menu to choose “YES” or “NO” from the “Trigger Enabled” drop-down list to enable or disable Trigger. Update Setting: Click “Update Setting” button to update settings to the switch. IES-1881 Manual...
  • Page 41 Reboot Reboot: Click “Reboot” button to restart the switch. Logout Logout: Click “Logout” button to logout of the switch. IES-1881 Manual...

  • Page 42: Port

    “Speed” drop-down list for the port. Flow control: Click “Flow control” drop-down menu to choose “Disable” or “Enable” from the “Flow control” drop-down list to disable or enable Flow control for the port. Submit: Click “Submit” button when you finished configurations. IES-1881 Manual...
  • Page 43 Port Status View the Link Status, Speed, Duplex, and Flow control status for all ports. IES-1881 Manual...
  • Page 44 Egress Rate Control for the port. Rate Values: 64kbps, 128kbps, 192kbps, … , 1792kbps. 2Mbps, 3Mbps, 4Mbps, … , 100Mbps. 104Mbps, 112Mbps, 120Mbps, … , 1000Mbps. <Note>: M = 1024k. Update setting: Click “Update setting” button when you finished these Rate Control settings. IES-1881 Manual...
  • Page 45 RMON Statistics Click Port 1 ~ Port 18 to view corresponding RMON Statistics. IES-1881 Manual...
  • Page 46 Per Port Vlan Activities Click Port 1 ~ Port 18 to view corresponding vlan activities. IES-1881 Manual...

  • Page 47: Switching

    “DFL-Multicast“ from “Storm-control enabled type” for the port. DLF (Destination Lookup Failure). Storm-control enabled type: Choose “Broadcast” and/or “DLF-Multicast” from “Storm-control enabled type” for the port. Update Setting: Click “Update Setting” button when you finished Threshold level and Storm-control enabled type settings. IES-1881 Manual...
  • Page 48 MAC address to be discarded for the VLAN. VLAN ID: VLAN ID: Click “VLAN ID” drop-down menu and choose a VLAN ID from the “VLAN ID” drop-down list. Delete MAC address: Click “Delete MAC address” drop-down menu and IES-1881 Manual...
  • Page 49 (Port 1 ~ Port 18) from “Mirror To” drop-down list. Mirror Mode: Click “Mirror Mode” drop-down menu to Choose “Tx/Rx”, “Tx”, or “Rx” from “Mirror Mode” drop-down list. Submit: Click “Submit” button when you finished Port Mirroring settings. IES-1881 Manual...
  • Page 50 “Medium”, or “Low” from the “Power Priority” drop-down list to determine power priority of this port. Power Down Alarm: Check or uncheck “Power Down Alarm” to enable or disable power down alarm on this port. Submit: Click “Submit” button when you finished PoE Port Setting. IES-1881 Manual...
  • Page 51 Powered Device (PD) connected to this port. PoE Per Port Setting: Port: Click “Port” drop-down menu to choose a port from “Port” drop-down list and configure PoE scheduling to this port. Submit: Click “Submit” button when you finished PoE Scheduling for this port. IES-1881 Manual...

  • Page 52: Trunking

    Trunk 1: Click Port 1 ~ Port 16 to assign ports to Trunk 1. (Maximum 4 ports per Trunk.) GE Trunking: Trunk 3: Check “Static” or “Disable” to enable or disable Trunk 3 for Gigabit Ethernet ports. Submit: Click “Submit” button when you finished Port Trunking settings. IES-1881 Manual...

  • Page 53: Stp / Ring

    Forward Delay (sec) (4..30): Click in “Forward Delay” text box and type a decimal number between 4 and 30. STP Version: Click “STP Version” drop-down menu to choose “MSTP”, “RSTP” or “STP compatible” from “STP Version” drop-down list. Update setting: Click “Update setting” button when you finished Global Configuration. IES-1881 Manual...
  • Page 54 Edge Port: Click “Edge Port” drop-down menu to Choose “Enable”, “Disable”, or “Auto” from “Edge Port” drop-down list to set Enable, Disable, or Auto Edge Port for the port. Update setting: Click “Update setting” button when you finished RSTP IES-1881 Manual...
  • Page 55 Port Setting. MSTP Properties STP Version: Click “STP Version” drop-down menu to choose “MSTP” IES-1881 Manual...
  • Page 56 MST. Specifying the max hops for a BPDU prevents the messages from looping indefinetely in the network. When a bridge receives a MST BPDU that has exceeded the allowed max-hops, it discards the BPDU. Update setting: Click “Update setting” button when you finished MSTP Properties setting. IES-1881 Manual...
  • Page 57 MST instance to the value specified. The lower the priority of the bridge, the better the chances are the bridge becoming a root bridge or a designated bridge for the LAN. Update setting: Click “Update setting” button when you finished VLAN Instance Configuration. IES-1881 Manual...
  • Page 58 IES-1881 Manual...
  • Page 59 0-240. The priority values can only be set in increments of 16. Admin. Path Cost: Click in “Admin. Path Cost” text box to set the cost of a path associated with an interface. Update setting: Click “Update setting” button when you finished MSTP Port Setting. IES-1881 Manual...
  • Page 60 “Ring port 1” drop-down list. Ring port 2: Click “Ring port 2” drop-down menu to choose Ring port 2 from “Ring port 2” drop-down list. Update setting: Click “Update setting” button when you finished Set ring port. IES-1881 Manual...

  • Page 61: Vlan

    VLAN VLAN Mode Setting VLAN Mode Setting: Click “VLAN Mode Setting” drop-down menu to Choose “Tag-based VLAN” or “Port-based VLAN” from “VLAN Mode Setting” drop-down list. Update Setting: Click “Update Setting” button when you finished VLAN Mode Setting. IES-1881 Manual...
  • Page 62 IES-1881 Manual...
  • Page 63 Delete VLAN: Click “Delete VLAN” button. Select a VLAN ID: Click “Select a VLAN ID” drop-down menu from “Select a VLAN ID” drop-down list to choose the VLAN to be deleted. Submit: Click “Submit” button when you finished VLAN setting. IES-1881 Manual...
  • Page 64 “Trunk” Mode for the port. And the port will be Tag or Untag port if you choose “Hybrid” Mode for the port. PVID: Click in the “PVID” textbox and specify a new PVID number for the port. Update Setting: Click “Update Setting” button when you finished VLAN Port Setting. IES-1881 Manual...
  • Page 65 Port Based VLAN VLAN: Choose the port to be added to or deleted from the VLAN. Select all: Click “select all” button to choose Port 1 ~ Port 18 all to be added to the VLAN. IES-1881 Manual...
  • Page 66 Delete all: Click “delete all” button to choose Port 1 ~ Port 18 all to be deleted from the VLAN. Submit: Click “Submit” button when you finished Port Based VLAN setting. IES-1881 Manual...

  • Page 67: Qos

    Weighted Round Robin: Click in the “Weight(1~55)” textbox and specify a new number from 1 ~ 55 for Queue 0 ~ 3. Submit: Click “Submit” button when you finished Global Configuration. IES-1881 Manual...
  • Page 68 802.1p Priority Priority: Click “Priority” drop-down menu from “Priority” drop-down list to choose 0 ~ 3 for VLAN Priority 0 ~ 7. Submit: Click “Submit” button when you finished 802.1p priority. IES-1881 Manual...
  • Page 69 DSCP Priority: Click “Priority” drop-down menu from “Priority” drop-down list to choose 0 ~ 3 for DSCP Priority 0 ~ 63. Submit: Click “Submit” button when you finished DSCP. IES-1881 Manual...

  • Page 70: Snmp

    “Trap Community Name” textbox and specify a trap community name. Trap Host IP Address: For each “Trap Host IP Address”, Click in the “Trap Host IP Address” textbox and specify a trap host IP address. Cold Start Trap: Click “Cold Start Trap” drop-down menu from “Cold IES-1881 Manual...
  • Page 71 Get Community Name: Click in the “Get Community Name” textbox and specify a get community name. Set Community Name: Click in the “Set Community Name” textbox and specify a set community name. Update Setting: Click “Update Setting” button when you finished SNMP V1/V2c Setting. IES-1881 Manual...
  • Page 72 Auth-MD5”, “SNMPv3 Auth-SHA”, “SNMPv3 Priv Auth-MD5”, or “SNMPv3 Priv Auth-SHA”.  SNMPv3 No-Auth: Add a user using SNMP v3 without authentication.  SNMPv3 Auth-MD5: Add a user using SNMP v3 with authentication. Click in the “Auth. Password” textbox and specify an authentication password. IES-1881 Manual...
  • Page 73 Delete User: Click “Delete User” button. The “Select User Name” window appears. Select User Name: Click “Select User Name” drop-down menu from “Select User Name” drop-down list to choose the user to be deleted from using SNMP v3. Sumit: Click “Sumit” button when you finished user deletion. IES-1881 Manual...
  • Page 74 Radius Configuration Radius Status: Click “Radius Status” drop-down menu from “Radius Status” drop-down list to choose “Enable” or “Disable” to globally enable or disable authentication. Update Setting: Click “Update Setting” button when you finished Radius Status Setting. Add Radius: IES-1881 Manual...
  • Page 75 Select Radius Server IP: Click “Select Radius Server IP” drop-down menu from “Select Radius Server IP” drop-down list to choose the IP address of the remote radius server host to be deleted. Sumit: Click “Sumit” button when you finished radius server deletion. IES-1881 Manual...
  • Page 76 “Enable” or “Disable” to enable or disable periodic reauthentication. Reauthentication Period <1-4294967295>: Click “Reauthentication Period” textbox and specify the seconds between reauthorization attempts. The default time is 3600 seconds. Update Setting: Click “Update Setting” button when you finished port-based authentication setting. IES-1881 Manual...

  • Page 77: Other Protocols

    “Disable” to enable or disable Dynamic VLAN creation. GARP (Generic Attribute Registration Protocol) provides IEEE802.1Q compliant VLAN pruning and dynamic VLAN creation on IEEE802.1Q trunk ports. Update Setting: Click “Update Setting” button when you finished GVRP Global Setting. IES-1881 Manual...
  • Page 78 There is only one querier on a network at any time. Update Setting: Click “Update Setting” button when you finished IGMP mode settings. VLAN ID: Click “VLAN ID” drop-down menu from “VLAN ID” drop-down IES-1881 Manual...
  • Page 79 IGMP reports for the group to the multicast routers. This feature prevents duplicate reports from being sent to the multicast devices. Update Setting: Click “Update Setting” button when you finished IGMP Snooping. IES-1881 Manual...
  • Page 80 NTP Server (IP Address or Domain name): Click in the “NTP Server” textbox and specify the IP address or Domain name of NTP server. Sync Time: Click “Sync Time” button to synchronize time with NTP server. Time Zone: Click “Tmie Zone” drop-down menu from “Tmie Zone” IES-1881 Manual...
  • Page 81 Update Setting: Click "Update Setting" button when you finished Daylight Saving Setting. <Note> The “Week”, “Hour”, “Minute”, and “Day” fields would not accept the alphabetic characters (Like Jan, Feb, sun, mon). They only accept the two digit numbers (0 throught 9). IES-1881 Manual...

  • Page 82: Command Line Console Management

    HyperTerminal) to the switch console port. When using the management method, configure the terminal-emulation program to use the following parameters (you can change these settings after login): [Default parameters] 115,200bps 8 data bits No parity 1 stop bit IES-1881 Manual...

  • Page 83: Exec Mode (View Mode)

    Exec Mode (View Mode) Logon to Exec Mode (View Mode) At the switch_a login: prompt just type in “root” and press <Enter> to logon to Exec Mode (or View Mode). switch_a login: root IES-1881 Manual...
  • Page 84 At the switch_a> prompt just press <?> to list the above basic commands. switch_a>? At the switch_a> prompt just type in the full or partial command string then typing a question mark “?” to display the command keywords or parameters along with a short description. switch_a>show ? IES-1881 Manual...
  • Page 85 (60 seconds) to indicate authentication attempt timed out. And the switch_a login: prompt will show on the screen. Logon back to Exec Mode (View Mode) At the switch_a login: prompt just type in “root” and press <Enter> to logon IES-1881 Manual...
  • Page 86 Exec Mode (or View Mode). switch_a login: root Exit from Exec Mode (View Mode) At the switch_a> prompt just type in “exit” and press <Enter> to exit from Exec Mode (or View Mode). switch_a>exit IES-1881 Manual...

  • Page 87: Privileged Exec Mode (Enable Mode)

    Privileged Exec Mode (or Enable Mode). And the switch_a# prompt will show on the screen. switch_a>enable Commands Privileged Exec Mode (or Enable Mode) allows users to run commands as following. At the switch_a# prompt just press <?> to list the commands. switch_a#? IES-1881 Manual...
  • Page 88 At the switch_a# prompt just type in the full or partial command string then typing a question mark “?” to display the command keywords or parameters along with a short description. switch_a#show ? IES-1881 Manual...
  • Page 89 (60 seconds) to indicate authentication attempt timed out. And the switch_a login: prompt will show on the screen. Logon back to Exec Mode (View Mode) At the switch_a login: prompt just type in “root” and press <Enter> to logon IES-1881 Manual...
  • Page 90 Exec Mode (or View Mode). switch_a login: root Exit from Privileged Exec Mode (or Enable Mode) At the switch_a# prompt just type in “exit” and press <Enter> to exit from Privileged Exec Mode (or Enable Mode). switch_a#exit IES-1881 Manual...

  • Page 91: Configure Mode (Configure Terminal Mode)

    Configure Mode (or Configure Terminal Mode). And the switch_a(config)# prompt will show on the screen. switch_a#configure terminal Commands Configure Mode (or Configure Terminal Mode) serves as a gateway into the modes as following. At the switch_a(config)# prompt just press <?> to list the commands. switch_a(config)#? IES-1881 Manual...
  • Page 92 At the switch_a(config)# prompt just type in the full or partial command string then typing a question mark “?” to display the command keywords or parameters along with a short description. switch_a(config)#show ? IES-1881 Manual...
  • Page 93 And the switch_a login: prompt will show on the screen. Logon back to Exec Mode (View Mode) At the switch_a login: prompt just type in “root” and press <Enter> to logon back to Exec Mode (or View Mode). switch_a login: root IES-1881 Manual...
  • Page 94 Exit from Configure Mode (or Configure Terminal Mode) At the switch_a(config)# prompt just type in “exit” and press <Enter> to exit from Configure Mode (or Configure Terminal Mode). switch_a(config)#exit IES-1881 Manual...

  • Page 95: System

    Use enable password command to modify or create a password to be used when entering the Enable mode. Command Syntax: enable password PASSWORD PASSWORD specifies the new password of the system. Example: The following example sets the new password mypasswd to switch: switch_a(config)#enable password mypasswd switch_a(config)# IES-1881 Manual...
  • Page 96 The switch_a(config)# prompt will show on the screen. switch_a(config)# Usage: Use ip default-gateway command to set the IP address of the default gateway. Use the no ip default-gateway command to remove the IP address of the default gateway. Command Syntax: IES-1881 Manual...
  • Page 97 Usage: Use install image command to load configuration file from tftp server to switch. Command Syntax: install image IP-ADDRESS WORD IP-ADDRESS specifies the IP address of tftp server. WORD specifies the file name to be loaded to switch. IES-1881 Manual...
  • Page 98 This is the same as the write memory command. Command Syntax: copy running-config startup-config Example: The following example specifies writing configurations to the file to be used at startup to switch: switch_a#copy running-config startup-config switch_a# IES-1881 Manual...
  • Page 99 The following example enables or disables auto save configuration to switch: switch_a(config)#service auto-config enable switch_a(config)#no service auto-config enable switch_a(config)# Auto Save Interval (5~65536 sec): Command Mode: Configure mode Logon to Configure Mode (Configure Terminal Mode). The switch_a(config)# prompt will show on the screen. IES-1881 Manual...
  • Page 100 (IP address: 192.168.1.100) to switch: switch_a#install image 192.168.1.100 flash.tgz switch_a# Please follow the message on the screen during the firmware upgrade process. Do not turn off the power or perform other functions during this period of time. IES-1881 Manual...
  • Page 101 At the “switch_a#” prompt just type in “reload” and press <Enter> to reboot the switch after completing the upgrade process. IES-1881 Manual...
  • Page 102 The following example enables alarm trigger of power “1” to switch: switch_a(config)#alarm-trigger power 1 switch_a(config)# Reboot Command Mode: Privileged Exec mode Logon to Privileged Exec Mode (Enable Mode). The switch_a# prompt will show on the screen. switch_a# Usage: Use reload command to restart switch. IES-1881 Manual...
  • Page 103 The switch_a> or switch_a# prompt will show on the screen. switch_a> switch_a# Usage: Use logout command to exit from the Exec mode or Privileged Exec mode. Command Syntax: logout Example: The following example specifies to exit from the Exec mode or Privileged Exec mode. switch_a>logout switch_a login: IES-1881 Manual...

  • Page 104: Port

    The switch_a(config-if)# prompt will show on the screen. switch_a(config)#interface fe1 switch_a(config-if)# Usage: Use this command to specify the bandwidth for each interface. The bandwidth value is in bits. Use the no parameter with this command to remove the bandwidth for each interface. IES-1881 Manual...
  • Page 105 The following example shows the use of duplex MODE (full) to the interface fe1 (port 1): switch_a(config)#interface fe1 switch_a(config-if)#duplex full switch_a(config-if)# Flow control: Command Mode: Interface mode Logon to Configure Mode (Configure Terminal Mode). Then logon to Interface mode. fe1 means port 1. IES-1881 Manual...
  • Page 106 Example: The following example shows the use of show interface to display interface configuration and status of the interface fe1 (port 1): switch_a>show interface fe1 Rate Control Command Mode: Interface mode Logon to Configure Mode (Configure Terminal Mode). IES-1881 Manual...
  • Page 107 IFNAME specifies the name of the interface for which RMON statistics is desired. Example: The following example shows the use of show interface statistics to display RMON statistics of the interface fe1 (port 1): switch_a>show interface statistics fe1 IES-1881 Manual...
  • Page 108 Use show vlan command to display information about a particular VLAN by specifying the VLAN ID. Command Syntax: show vlan <2-4094> <2-4094> VLAN ID. Example: The following is an output of show vlan command displaying information about VLAN 2: switch_a>show vlan 2 IES-1881 Manual...

  • Page 109: Switching

    Use storm-control level command to specify the rising threshold level for broadcasting, multicast, or destination lookup failure traffic. The storm control action occurs when traffic utilization reaches this level. Command Syntax: storm-control level LEVEL LEVEL <0-100> specifies the percentage of the threshold; percentage of the IES-1881 Manual...
  • Page 110 Then logon to Interface mode. fe1 means port 1. The switch_a(config-if)# prompt will show on the screen. switch_a(config)#interface fe1 switch_a(config-if)# Usage: Use storm-control multicast enable command to enable multicast traffic. Use no storm-control multicast command to disable multicast traffic. IES-1881 Manual...
  • Page 111 The following example shows setting storm-control dlf enable to the interface fe1 (port 1): switch_a(config)#interface fe1 switch_a(config-if)#storm-control dlf enable switch_a(config-if)# Static MAC Entry Static-MAC-Entry Forward: Command Mode: Configure mode Logon to Configure Mode (Configure Terminal Mode). The switch_a(config)# prompt will show on the screen. switch_a(config)# IES-1881 Manual...
  • Page 112 VLANID The VID of the VLAN on the bridge <1-4094>. Example: The following example configures a bridge GROUP (1) to discard matching frames (MAC address 2222.2222.2222) in vlan VLANID (1): switch_a(config)#bridge 1 address 2222.2222.2222 discard vlan 1 switch_a(config)# IES-1881 Manual...
  • Page 113 Use this command to specify the power budget (Watts) to be set to Switch. Command Syntax: poe system-power-budget LEVEL LEVEL <1-800> specifies the power budget (Watts) to be set to Switch. Example: The following example sets new power budget 246 Watts to Switch: IES-1881 Manual...
  • Page 114 Use poe power-classification enable command to enable this port to provide power to PD according to classification of maximum power range used by PD. Use the no poe power-classification enable to disable this function. Command Syntax: (no) poe power-classification enable IES-1881 Manual...
  • Page 115 Logon to Configure Mode (Configure Terminal Mode). Then logon to Interface mode. fe1 means port 1. The switch_a(config-if)# prompt will show on the screen. switch_a(config)#interface fe1 switch_a(config-if)# Usage: Use this command to specify the power priority to this port. Command Syntax: IES-1881 Manual...
  • Page 116 Logon to Configure Mode (Configure Terminal Mode). Then logon to Interface mode. fe1 means port 1. The switch_a(config-if)# prompt will show on the screen. switch_a(config)#interface fe1 switch_a(config-if)# Usage: Use this command to enble PoE scheduling to this port. IES-1881 Manual...
  • Page 117 DAY <0-6> specifies Sunday ~ Saturday to Switch. HOUR <0-23> specifies hours to Switch. no poe schedule-time DAY Example: The following example sets PoE scheduling to the interface fe1 (port 1): switch_a(config)#interface fe1 switch_a(config-if)#poe schedule-time 3 0-10,12,14-20, 22-23 switch_a(config-if)# IES-1881 Manual...

  • Page 118: Trunking

    Command Syntax: static-channel-group <1-3> no static-channel-group <1-3> Channel group number. Maximum 4 ports in static-channel-group 1 and static-channel-group 2. Maximum 2 ports in static-channel-group 3 Example: following example adding interface (port static-channel-group 1: switch_a(config)#interface fe1 switch_a(config-if)#static-channel-group 1 switch_a(config-if)# IES-1881 Manual...

  • Page 119: Stp

    Use this command to enable the Multiple Spanning Tree protocol on a bridge. Use the no form of the command to disable the Multiple Spanning Tree protocol on a bridge. Command Syntax: bridge GROUP multiple-spanning-tree enable no bridge GROUP multiple-spanning-tree enable BRIDGE-FORWARD IES-1881 Manual...
  • Page 120 The switch_a(config)# prompt will show on the screen. switch_a(config)# Usage: Use this command to enable the Spanning Tree protocol on a bridge. Use the no form of the command to disable the Spanning Tree protocol on a bridge. IES-1881 Manual...
  • Page 121 Hello Time (sec) (1..9): Command Mode: Configure mode Logon to Configure Mode (Configure Terminal Mode). The switch_a(config)# prompt will show on the screen. switch_a(config)# Usage: Use this command to set the hello-time, the time in seconds after which (if IES-1881 Manual...
  • Page 122 The following example sets the max-age MAXAGE (28) of bridge GROUP (1): switch_a(config)#bridge 1 max-age 28 switch_a(config)# Forward Delay (sec) (4..30): Command Mode: Configure mode Logon to Configure Mode (Configure Terminal Mode). The switch_a(config)# prompt will show on the screen. IES-1881 Manual...
  • Page 123 GROUP <1-1> the ID of the bridge group. PRIORITY <0-240> The priority to be assigned to the group. Example: The following example sets the priority PRIORITY (100) of the interface fe1 (port 1) of bridge GROUP (1): switch_a(config)#interface fe1 switch_a(config-if)#bridge 1 priority 100 switch_a(config-if)# IES-1881 Manual...
  • Page 124 Use the no spanning-tree link-type command to set a port to its default state and to disable rapid transition. Command Syntax: (no) spanning-tree link-type LINKTYPE LINKTYPE The link type to be assigned to the port. point-to-point Enable rapid transition. IES-1881 Manual...
  • Page 125 Logon to Configure Mode (Configure Terminal Mode). Then logon to Interface mode. fe1 means port 1. The switch_a(config-if)# prompt will show on the screen. switch_a(config)#interface fe1 switch_a(config-if)# Usage: Use spanning-tree edgeport command to set a port as an edge-port and to enable rapid transitions. IES-1881 Manual...
  • Page 126 The following example creates an MST region and specifies a name (regionname) to it in bridge GROUP (1): Switch_a(config)#spanning-tree mst configuration switch_a(config-mst)#bridge 1 region regionname switch_a(config-mst)# Revision Level: Command Mode: MST Configuration mode Logon to Configure Mode (Configure Terminal Mode). IES-1881 Manual...
  • Page 127 GROUP max-hops GROUP <1-1> Specify the bridge-group ID. HOP_COUNT Maximum hops the BPDU will be valid for. Example: The following example specifies the maximum allowed hops (25) for BPDU in bridge GROUP (1): switch_a(config)#bridge 1 max-hops 25 switch_a(config)# IES-1881 Manual...
  • Page 128 The lower the priority of the bridge, the better the chances are the bridge becoming a root bridge or a designated bridge for the LAN. The priority values can be set only in increments of 4096. Command Syntax: IES-1881 Manual...
  • Page 129 1 instance 3 switch_a(config-if)# Bridge-Group Instance Priority: Command Mode: Interface mode Logon to Configure Mode (Configure Terminal Mode). Then logon to Interface mode. fe1 means port 1. The switch_a(config-if)# prompt will show on the screen. IES-1881 Manual...
  • Page 130 A lower path-cost indicates a greater likelihood of the specific interface becoming a root. Command Syntax: bridge GROUP instance INSTANCE_ID path-cost PATH_COST GROUP <1-1> Specify the bridge-group ID. INSTANCE_ID <1-15> Specify the instance ID. PATH_COST <1-200000000> Specify the cost of path in the range of <1-200000000>. IES-1881 Manual...
  • Page 131 The switch_a(config)# prompt will show on the screen. switch_a(config)# Usage: Use this command to set Ring port 1 and Ring port 2. Command Syntax: ring set-port RING_PORT_1 RING_PORT_2 RING_PORT_1 Specify the Ring port 1. RING_PORT_2 Specify the Ring port 2. IES-1881 Manual...
  • Page 132 Example: The following example sets the fe1 and fe2 as Ring port 1 and Ring port 2: switch_a(config)#ring set-port fe1 fe2 switch_a(config)# IES-1881 Manual...

  • Page 133: Vlan

    VLANID bridge GROUP name VLAN_NAME state enable/disable no vlan VLANID bridge GROUP VLANID The VID of the VLAN that will be enabled or disabled on the bridge <2-4094>. GROUP <1-1> The ID of the bridge-group on which the VLAN will be IES-1881 Manual...
  • Page 134 (port 1): switch_a(config)#interface fe1 switch_a(config-if)#switchport mode access switch_a(config-if)# Switchport mode hybrid: Command Mode: Interface mode Logon to Configure Mode (Configure Terminal Mode). Then logon to Interface mode. fe1 means port 1. The switch_a(config-if)# prompt will show on the screen. IES-1881 Manual...
  • Page 135 Use the no switchport trunk command to reset the mode of the Layer-2 interface to access (default). Command Syntax: switchport mode trunk no switchport trunk Example: The following example sets the switchport mode trunk of the interface fe1 (port 1): switch_a(config)#interface fe1 IES-1881 Manual...
  • Page 136 The following example specifies to add the interface fe1 (port 1) to VLANID (2) and enable the egress-tagged for the outgoing frames on interface fe1 (port 1): switch_a(config)#interface fe1 switch_a(config-if)#switchport hybrid allowed vlan add 2 egress-tagged enable switch_a(config-if)# Switchport trunk allowed vlan: IES-1881 Manual...
  • Page 137 For a VLAN list, specify the VLAN numbers separated by commas. Example: The following example specifies to add the interface fe1 (port 1) to VLANID (2): switch_a(config)#interface fe1 switch_a(config-if)#switchport trunk allowed vlan add 2 switch_a(config-if)# Port Based VLAN Switchport portbase add/remove vlan: Command Mode: Interface mode IES-1881 Manual...
  • Page 138 VLANID The ID of the VLAN will be added to or removed from the Layer-2 interface. Example: The following example specifies to add the interface fe1 (port 1) to VLANID (2): switch_a(config)#interface fe1 switch_a(config-if)#switchport portbase add vlan 2 switch_a(config-if)# IES-1881 Manual...

  • Page 139: Qos

    Use the no mls qos trust command to turn off QoS trust CoS or DSCP. Command Syntax: (no) mls qos trust cos/dscp cos Class of Service. dscp Differentiated Service Code Point. Example: The following example turns on QoS trust CoS on the switch: switch_a(config)#mls qos trust cos switch_a(config)# IES-1881 Manual...
  • Page 140 Range is 1-55. Example: The following example specifies the bandwidth ratios of the transmit queues on the switch: switch_a(config)#wrr-queue bandwidth 1 2 4 8 switch_a(config)# 802.1p Priority Command Mode: Configure mode Logon to Configure Mode (Configure Terminal Mode). IES-1881 Manual...
  • Page 141 DSCP_VALUE DSCP values. Up to 8 values (separated by spaces). Range is 0-63. QUEUE_ID Queue ID. Range is 0-3. Example: The following example shows mapping DSCP values 0 to 3 to queue 1 on the switch: switch_a(config)#mls qos map dscp-queue 0 1 2 3 to 1 switch_a(config)# IES-1881 Manual...

  • Page 142: Snmp

    Use snmp-server description command to specify and no snmp-server description command to remove description for SNMP. Command Syntax: snmp-server description DESCRIPTION no snmp-server description DESCRIPTION The description for SNMP. Example: The following example specifies description (description) for SNMP: switch_a(config)#snmp-server description description switch_a(config)# IES-1881 Manual...
  • Page 143 CONTACT The contact for SNMP. Example: The following example specifies contact (contact) for SNMP: switch_a(config)#snmp-server contact contact switch_a(config)# Trap Community Name: Command Mode: Configure mode Logon to Configure Mode (Configure Terminal Mode). The switch_a(config)# prompt will show on the screen. IES-1881 Manual...
  • Page 144 IP-ADDRESS The trap host IP address for SNMP. A.B.C.D specifies the IP address. Example: The following example specifies trap host 1 IP address (192.168.1.20) for SNMP: switch_a(config)#snmp-server trap-ipaddress 1 192.168.1.20 switch_a(config)# Cold Start Trap: Command Mode: Configure mode Logon to Configure Mode (Configure Terminal Mode). IES-1881 Manual...
  • Page 145 Link Down Trap: Command Mode: Configure mode Logon to Configure Mode (Configure Terminal Mode). The switch_a(config)# prompt will show on the screen. switch_a(config)# Usage: Use snmp-server trap-type enable linkDown command to enable link IES-1881 Manual...
  • Page 146 The switch_a(config)# prompt will show on the screen. switch_a(config)# Usage: Use snmp-server trap-type enable authenticationFailure command to enable authentication failure trap for SNMP. Use the no snmp-server trap-type enable authenticationFailure command to disable authentication failure trap for SNMP. Command Syntax: IES-1881 Manual...
  • Page 147 Use snmp-server community get command to specify and no snmp-server community get command to remove get community name for SNMP. Command Syntax: snmp-server community get NAME no snmp-server community get NAME The get community name for SNMP. Example: IES-1881 Manual...
  • Page 148 Command Syntax: (no) snmp-server v3-user USERNAME (ro｜rw) noauth USERNAME Specify a user name. ro read-only access mode rw read-write access mode Example: The following example adds a user (myuser) using snmp v3 with read-only access mode and without authentication: IES-1881 Manual...
  • Page 149 Add a user using snmp v3 with read-only or read-write access mode, MD5 or SHA authentication, and privacy. Use the no form of the command to delete this user. Command Syntax: (no) snmp-server v3-user USERNAME (ro ｜ rw) priv auth (md5 ｜ sha) AUTH_PASSWORD des PRIV_PASS_PHRASE USERNAME Specify a user name. IES-1881 Manual...
  • Page 150 AUTH_PASSWORD authentication password PRIV_PASS_PHRASE encryption pass phrase Example: The following example adds a user (myuser) using snmp v3 with read-write access mode, MD5 authentication (mypassword), and encryption pass phrase (mypassphrase): switch_a(config)#snmp-server v3-user myuser rw priv md5 mypassword des mypassphrase switch_a(config)# IES-1881 Manual...
  • Page 151 PORT specifies the UDP destination port for authentication requests. The host is not used for authentication if set to 0. Example: The following example specifies the IP address (192.168.1.100) of the remote radius server host and assigns authentication and accounting destination port number (1812): IES-1881 Manual...
  • Page 152 SEC <1-1000> The number of seconds for a Switch to wait for a server host to reply before timing out. Enter a value in the range 1 to 1000. Example: The following example specifies 20 seconds for the Switch to wait for a server host to reply before timing out: IES-1881 Manual...
  • Page 153 Use dot1x reauthetication command to enable reauthentication on a port. Use no dot1x reauthetication command to disable reauthentication on a port. Command Syntax: (no) dot1x reauthentication Example: The following example specifies to enable reauthetication on the interface fe1 (port 1): IES-1881 Manual...
  • Page 154 Logon to Configure Mode (Configure Terminal Mode). Then logon to Interface mode. fe1 means port 1. The switch_a(config-if)# prompt will show on the screen. switch_a(config)#interface fe1 switch_a(config-if)# Usage: Use this command to set the interval between reauthorization attempts. IES-1881 Manual...
  • Page 155 SECS <1-4294967295> Specify the seconds between reauthorization attempts. The default time is 3600 seconds. Example: The following example specifies to set the interval 25 seconds between reauthorization attempts: switch_a(config)#interface fe1 switch_a(config-if)#dot1x timeout re-authperiod 25 switch_a(config-if)# IES-1881 Manual...

  • Page 156: Other Protocols

    Use set gvrp dynamic-vlan-creation enable bridge command to enable and set gvrp dynamic-vlan-creation disable bridge command to disable dynamic VLAN creation for a specific bridge instance. Command Syntax: set gvrp dynamic-vlan-creation enable bridge GROUP set gvrp dynamic-vlan-creation disable bridge GROUP GROUP Bridge-group ID used for bridging. IES-1881 Manual...
  • Page 157 The switch_a(config)# prompt will show on the screen. switch_a(config)# Usage: Use this command to set the GVRP applicant state to normal or active. Command Syntax: set gvrp applicant state active/normal IFNAME active Active state normal Normal state IFNAME Name of the interface. Example: IES-1881 Manual...
  • Page 158 The following example sets GVRP registration to fixed registration mode on the interface fe1 (port 1): switch_a(config)#set gvrp registration fixed fe1 switch_a(config)# IGMP Snooping IGMP mode: Querier: Command Mode: Configure mode Logon to Configure Mode (Configure Terminal Mode). The switch_a(config)# prompt will show on the screen. switch_a(config)# Usage: IES-1881 Manual...
  • Page 159 IGMP version: Command Mode: Interface mode Logon to Configure Mode (Configure Terminal Mode). Then logon to Interface mode. vlan1.1 means vlan 1. The switch_a(config-if)# prompt will show on the screen. switch_a(config)#interface vlan1.1 switch_a(config-if)# IES-1881 Manual...
  • Page 160 Use the no ip igmp snooping fast-leave command to disable fast-leave processing. Command Syntax: (no) ip igmp snooping fast-leave Example: The following example enables IGMP snooping fast-leave on vlan1.1: switch_a(config)#interface vlan1.1 switch_a(config-if)#ip igmp snooping fast-leave switch_a(config-if)# IGMP querier: Query-interval: IES-1881 Manual...
  • Page 161 The switch_a(config-if)# prompt will show on the screen. switch_a(config)#interface vlan1.1 switch_a(config-if)# Usage: Use ip igmp query-max-response-time command to configure the maximum response time advertised in IGMP queries. restore default value, igmp query-max-response-time command. Command Syntax: ip igmp query-max-response-time RESPONSETIME no ip igmp query-max-response-time IES-1881 Manual...
  • Page 162 IGMP passive snooping: Report suppression: Command Mode: Interface mode Logon to Configure Mode (Configure Terminal Mode). Then logon to Interface mode. vlan1.1 means vlan 1. The switch_a(config-if)# prompt will show on the screen. IES-1881 Manual...
  • Page 163 HOUR <0-23> specifies hour to Switch. MINUTE <0-59> specifies minute to Switch. SECOND <0-59> specifies second to Switch. Example: The following example adjusts system time to Switch: switch_a(config)#rtc adjust-system-time 2009 1 1 0 14 4 switch_a(config)# NTP Status: IES-1881 Manual...
  • Page 164 192.168.1.100 switch_a(config)# Sync Time: Command Mode: Configure mode Logon to Configure Mode (Configure Terminal Mode). The switch_a(config)# prompt will show on the screen. switch_a(config)# Usage: Use ntp sync-time command to synchronize time with NTP server. IES-1881 Manual...
  • Page 165 Use this command to specify the polling interval. Command Syntax: ntp polling-interval MINUTE MINUTE <1-10080> The polling interval. Enter a value in the range 1 to 10080 minutes. Example: The following example specifies the polling interval 60 minutes: switch_a(config)#ntp polling interval 60 switch_a(config)# IES-1881 Manual...
  • Page 166 Example: The following example sets clock summer-time TIMEZONE (onehour) as daylight saving offset 60 minutes from 4 April AM0:00 to 31 October AM0:00: switch_a(config)#clock summer-time onehour date 4 4 0 0 31 10 0 0 60 switch_a(config)# IES-1881 Manual...

  • Page 167: Specifications

    -40°C to 85℃ (-40℉ to 185℉) Humidity 5%-95% non-condensing Safety UL508 FCC Part 15, Class A EN61000-6-4: EN55022, EN61000-3-2, EN61000-3-3 EN61000-6-2: EN61000-4-2 (ESD Standard) EN61000-4-3 (Radiated RFI Standards) EN61000-4-4 (Burst Standards) EN61000-4-5 (Surge Standards) EN61000-4-6 (Induced RFI Standards) EN61000-4-8 (Magnetic Field Standards) IES-1881 Manual...
  • Page 168 Environmental Test IEC60068-2-6 Fc (Vibration Resistance) Compliance IEC60068-2-27 Ea (Shock) IEC60068-2-32 Ed (Free Fall) NEMA TS1/2 Environmental requirements for traffic control equipment IES-1881 Manual...
  • Page 169 Appendix A DB9 DCE pin assignment Pin no. Name RS232 Signal name Data Carrier detect Received data Transmit data Signal ground Data set Ready Clear to send IES-1881 Manual...
  • Page 170 WET, Atlantic/Faeroe, Atlantic/Madeira, Atlantic/Canary PWT0PST Europe/Lisbon, Portugal MST-3MDT Europe/Moscow, W-SU EUT-1EUTDST America/Scoresbysund, Atlantic/Azores EUT-2EUTDST Asia/Beirut, Europe/Simferopol EUT-3EUTDST Asia/Tbilisi EUT-4EUTDST Europe/Samara EUT-6EUTDST Asia/Almaty, Asia/Qyzylorda EUT-8EUTDST Asia/Ulaanbaatar Russian Federation RFT-2RFTDST Europe/Kaliningrad RFT-3RFTDST Europe/Moscow RFT-4RFTDST Asia/Yerevan, Asia/Baku, Asia/Oral, Asia/Ashkhabad RFT-5RFTDST Asia/Aqtobe, Asia/Aqtau, Asia/Bishkek, IES-1881 Manual...
  • Page 171 America/Coral_Harbour, America/Cayman, America/Jamaica, America/Panama, EST, Jamaica, SystemV/EST5 AST10ADT America/Adak, America/Atka, US/Aleutian YST9YDT Canada/Yukon NST3:30NDT America/St_Johns, Canada/Newfoundland NAST3NADT America/Godthab, America/Miquelon NAST9NADT Pacific/Pitcairn, America/Juneau, America/Yakutat, America/Anchorage, America/Nome, US/Alaska, SystemV/YST9YDT, SystemV/PST8 South America & Central America TTST4 America/Port_of_Spain SAT3 America/Argentina/Buenos_Aires, America/Argentina/Cordoba, America/Argentina/Tucuman, IES-1881 Manual...
  • Page 172 Asia/Macau, Asia/Macao, Hongkong, PRC, Oceania CST-9:30CDT Australia/Adelaide, Australia/Broken_Hill, Australia/South, Australia/Yancowinna EST-10EDT Australia/Brisbane, Australia/Lindeman, Australia/Currie, Australia/Melbourne, Australia/Sydney, Australia/ACT, Australia/Canberra, Australia/NSW, Australia/Queensland, Australia/Tasmania, Australia/Victoria LHT-10:30LHDT Australia/Lord_Howe, Australia/LHI TST-10TDT Australia/Hobart NZST-12NZDT Antarctica/McMurdo, Pacific/Auckland, Antarctica/South_Pole, NZ CIST-12:45CIDT Pacific/Chatham, NZ-CHAT Africa SAST-2 Africa/Maseru, Africa/Johannesburg, IES-1881 Manual...
  • Page 173 America/Puerto_Rico, America/St_Kitts, America/St_Lucia, America/St_Vincent, America/Tortola, America/St_Thomas, America/Aruba, America/La_Paz, America/Porto_Velho, America/Curacao, America/Caracas, America/Guyana, Etc/GMT+4, America/Virgin, SystemV/AST4 UCT5 America/Guayaquil, America/Eirunepe, America/Lima, Etc/GMT+5 UCT6 America/Belize, America/El_Salvador, America/Tegucigalpa, Pacific/Galapagos, Etc/GMT+6 UCT7 Etc/GMT+7 UCT8 Etc/GMT+8 UCT9 Pacific/Gambier, Etc/GMT+9, SystemV/YST9 UCT10 Pacific/Rarotonga, Pacific/Tahiti, Pacific/Fakaofo, Pacific/Johnston, IES-1881 Manual...
  • Page 174 Asia/Colombo, Etc/GMT-6, Asia/Dacca, Asia/Thimbu UCT-6:30 Asia/Rangoon, Indian/Cocos UCT-7 Antarctica/Davis, Asia/Phnom_Penh, Asia/Jakarta, Asia/Pontianak, Asia/Vientiane, Asia/Bangkok, Asia/Saigon, Indian/Christmas, Etc/GMT-7 UCT-8 Antarctica/Casey, Asia/Brunei, Asia/Taipei, Asia/Makassar, Asia/Manila, Asia/Singapore, Etc/GMT-8, Asia/Ujung_Pandang, Singapore UCT-9 Asia/Dili, Asia/Jayapura, Pacific/Palau, Etc/GMT-9 UCT-9:30 Australia/Darwin, Australia/North UCT-10 Antarctica/DumontDUrville, Pacific/Guam, IES-1881 Manual...
  • Page 175 Etc/GMT+12 North America (Canada) PST8PDT_CA America/Vancouver, America/Dawson_Creek, America/Whitehorse, America/Dawson, Canada/Pacific MST7MDT_CA America/Edmonton, America/Yellowknife, America/Inuvik, Canada/Mountain CST6CDT_CA America/Rainy_River, America/Winnipeg, America/Rankin_Inlet, Canada/Central EST5EDT_CA America/Montreal, America/Toronto, America/Thunder_Bay, America/Nipigon, America/Iqaluit, Canada/Eastern AST4ADT_CA America/Goose_Bay, America/Halifax, America/Glace_Bay, Canada/Atlantic North America (Cuba) EST5EDT_CU America/Havana, Cuba IES-1881 Manual...
  • Page 176 North America (Mexico) PST8PDT_MX America/Tijuana, America/Ensenada, Mexico/BajaNorte MST7MDT_MX America/Chihuahua, America/Hermosillo, America/Mazatlan, Mexico/BajaSur CST6CDT_MX America/Guatemala North America (Turks and Caicos) EST5EDT_TC America/Grand_Turk Additions Since 10g RTM EST5EDT_INDIANA America/Indiana/Indianapolis, America/Indiana/Marengo, America/Indiana/Vevay, America/Fort_Wayne, America/Indianapolis, America/Indiana/Knox, America/Knox_IN, US/Indiana-Starke, US/East-Indiana UCT-8_WA Australia/Perth, Australia/West IES-1881 Manual...

Table of Contents
