- Page 1 ASSEMBLY INSTRUCTIONS FOR THE DF4500 PRO POWER RACK 750 LB WEIGHT CAPACITY (888) 258-0533 FOR YOUR SAFETY READ ALL INSTRUCTIONS CAREFULLY *NOTE IF YOU ARE MISSING HARDWARE OR HAVE ANY FIT UP PROBLEMS PLEASE CONTACT DELTECH FITNESS TOLL FREE (888) 258-0533...
-
Page 2: Box Contents
PART #DF4521 PART #DF4500 LOWER LOWER CHIN UP BAR INSTRUCTIONS CROSSMEMBER CROSSMEMBER QTY 1 QTY 1 QTY 1 QTY 1 *NOTE IF YOU ARE MISSING HARDWARE OR HAVE ANY FIT UP PROBLEMS PLEASE CONTACT DELTECH FITNESS TOLL FREE (888) 258-0533... - Page 3 (6 PCS) PULL PIN (2 PCS) 3/8” KNOBS (4 PCS) 1/2” x 4 1/4” BOLT FOR YOUR SAFETY READ ALL INSTRUCTIONS CAREFULLY *NOTE IF YOU ARE MISSING HARDWARE OR HAVE ANY FIT UP PROBLEMS PLEASE CONTACT DELTECH FITNESS TOLL FREE (888) 258-0533...
- Page 4 Figure 1 (NOTE: THE NUTS USED ON THIS RACK ARE LOCK NUTS, THIS MEANS YOU MUST TIGHTEN THEM DOWN PAST THE PLASTIC INSERT.) TOOLS REQUIRED FOR ASSEMBLY ADJUSTABLE WRENCHES OR METRIC SOCKET SET TAKE THE LEFT FOOT (1) AND THE RIGHT FOOT (2), AND SLIDE THE 2” x 3” RUBBER SHOES (14) ON, THEN ATTACH TO THE REAR CROSS MEMBER (11) USING THE 1/2”...
- Page 5 Figure 2 PUT THE SPOTTER BAR (8) & (9) TOGETHER AND SLIDE IT OVER THE UPRIGHTS (3) ON EACH SIDE. SLIDE THE WEIGHT HOLDERS (10) ON BOTH FRONT OR BACK UPRIGHTS (3) DEPENDING ON YOUR PREFERENCE.
- Page 6 Figure 3 (NOTE: THE NUTS USED ON THIS RACK ARE LOCK NUTS, THIS MEANS YOU MUST TIGHTEN THEM DOWN PAST THE PLASTIC INSERT.) ATTACH THE SIDE TOP FRAME SUPPORTS (4) & (5) ONTO EACH SIDE OF THE FRAME USING THE 1/2” x 3” BOLTS (18), THE 1/2” FLAT WASHERS (15), AND THE 1/2”...
- Page 7 Figure 4 (NOTE: THE NUTS USED ON THIS RACK ARE LOCK NUTS, THIS MEANS YOU MUST TIGHTEN THEM DOWN PAST THE PLASTIC INSERT.) INSTALL THE BACK CROSSMEMBER (7) USING THE 1/2” x 3- 1/4” (19), THE 1/2” LOCK NUTS (17) AND THE 1/2” FLAT WASHERS (15). ATTACH THE TOP CROSSMEMBER AND CHIN UP BAR (6) TO THE TOP SUPPORTS (5) USING THE 1/2”...
-
Page 8: Safety Notice
ADJUSTING THE WEIGHT HOLDERS: RAISE AND LOWER THE WEIGHT HOLDERS BY TURNING THE TIGHTENING KNOB TO LOOSEN, THEN USE THE PULL PIN TO MAKE THE HEIGHT ADJUSTMENT. MAKE SURE THE PULL PIN IS SECURE IN THE ADJUSTMENT HOLE THEN TURN THE KNOB TO TIGHTEN BEFORE USE. * NOTE MAKE SURE THE WEIGHT HOLDERS ARE THE SAME HEIGHT ON BOTH SIDES BEFORE USE. - Page 9 T-SHIRT ORDER FORM DELTECH FITNESS T - SHIRT SIZES AVAILABLE ARE M-XXL. THE COLOR OF THE SHIRTS ARE WHITE. RED AND BLACK LOGO. ONLY $12.99 DELTECH FITNESS MUSCLE SHIRT SIZES AVAILABLE M-XXL THE COLOR AVAILABLE IS BLACK. RED AND WHITE LOGO.
