INSTALLATION INSTRUCTIONS
1. If possible avoid placing the appliance near cookers, radiators or in direct
sunlight as this will cause the compressor to run for long periods. If installed next
to a source of heat or refrigerator, maintain the following minimum side
clearances:
From Cookers
From Radiators
From Fridges
2. Make sure that sufficient room is provided around the appliance to ensure free
air circulation. Ideally, ensure you allow gaps as shown in the below diagram.
3. The appliance should be located on a smooth surface.
4. Refer to "Cleaning and Care" section to prepare your appliance for use.
5. Fit the two plastic wall spacer supplied
with the appliance rotating 1/4 turn to
the condenser at the back of the
freezer (see diagram).
6. If the freezer is installed in unheated areas, garages etc., in cold weather
condensation may form on the outer surfaces.
This is quite normal and is not a fault. Remove the condensation by wiping with
a dry cloth.
12" (300 mm)
4
4" (100 mm)
4" (100 mm)
