  • Page 1 FPS-1031 Print Server w/ 1 Parallel Port User Manual Ver. 1.00-0803...
  • Page 2 The LevelOne Support Team can not support questions or compatibility issues with the following operating systems: Windows NT/95/98/98se/Me...

  • Page 3: Table Of Contents

    ABLE OF ONTENTS ............................5 OPYRIGHT 1. INTRODUCTION..........................6 ........................6 RODUCT VERVIEW ......................6 OMPONENTS AND EATURES ........................ 7 ARDWARE NSTALLATION ........................8 ETWORK NVIRONMENT ................... 8 IRED ETWORK WITH RINT ERVER 2. PRINT SERVER INSTALLATION ....................9 ............................ 9 REPARATION ....................
  • Page 4 UNIX I ........................59 NSTALLATION 8. UPGRADING PRINT SERVER ....................63 ............................63 VERVIEW ................63 PGRADING THE PRINT SERVER FROM DMIN NT/2000/XP/2003 (T TCP/IP) ..63 PGRADING THE PRINT SERVER FROM INDOWS HROUGH UNIX (T TCP/IP)..........64 PGRADING THE PRINT SERVER FROM HROUGH ................

  • Page 5: Copyright

    Trademarks NetWare is a registered trademark of Novell Inc and Windows 95/98/Me and Windows NT/2000/XP/2003 are registered trademarks of Microsoft Corp. All other brands and product names are trademarks of their respective companies. Copyright No part of this publication may be reproduced in any form or by any means or used to make any derivative (such as translation, transformation or adaptation) without the express written consent of the manufacturer as stipulated by the United States Copyright Act of 1976.

  • Page 6: Introduction

    1. Introduction Product Overview The external print servers enhance capability by letting you place your printers at convenient locations directly on the Ethernet network, and by increasing network printer performance and management. Please note that the print server does not support printing with host-based printers, e.g.

  • Page 7: Hardware Installation

    LED Indicators State Indication Blinking for POST When power switched on, the Status indicator will flash five Status (Yellow) times, and then on. 100Mbps On (Green) LAN Port has a valid network connection at 100Mbps. 10Mbps On (Yellow) LAN Port has a valid network connection at 10Mbps. Before you start, you should prepare the following items: One Windows-based computer with print server setup CD One printer with a Parallel port...

  • Page 8: Network Environment

    To printer Reset Button Network Environment Wired Network with Print Server: Print Server Printer Computer Computer Computer...

  • Page 9: Print Server Installation

    Print Server Installation Preparation To meet users’ network printing needs in today’s heterogeneous and multiple protocol networking environments, the print server supports industrial standard protocols, including TCP/IP, IPX/SPX, NetBEUI and AppleTalk. This means that the print server supports the most popular network operating systems today, including NetWare, Windows 95/98/Me/NT/2000/XP/2003, UNIX systems and Macintosh computer.
  • Page 10 Windows Remote Print server solution for continual management of NT/2000/XP/200 management of multiple printers- anywhere on your LAN print server, include alert and consumables Internet Printing Protocol Windows Printing via the Allows saving distribution of HQ hardcopy NT/2000/XP/200 internet to document over Internet, replacing fax, mail Internet Printing Protocol-...

  • Page 11: Software Installation

    To enable network communication with print server, your computer must have a proper IP address, e.g. 192.168.0.100 Insert the setup CD into your CD-ROM and the following message appears. Choose FPS-1031. Choose Setup Wizard to install the print server and configure the connected printer. Note: The setup CD will install the print server’s driver, PSAdmin and Setup Wizard into your...
  • Page 12 Click Next, the wizard will automatically discover the print server. From the Select A Print Sever screen, select the print server that you want to configure and click Next.
  • Page 13 On the Change Settings screen, select No or Yes: Click No if you want the print server to keep using the default IP address and keep the default settings: IP address: 192.168.0.10 Subnet Mask: 255.255.255.0 Click Yes if you want change IP address to the print server, and then click Next. Note: 1.
  • Page 14 Select Add New Printer if the print server is connected to a printer that hasn’t been installed before and does not appear in the list.
  • Page 15 Click Add New Printer to launch Windows Add Printer Wizard. 10. Click Next and select Local Printer, make sure the Automatically detect and install my Plug and Play printer check box is NOT checked. Then click Next.
  • Page 16 11. Make sure the Use the following port radio-button is clicked and select LPT1: (recommended Printer Port) from the pull-down list. Then click Next. 12. Select Manufacturer and Printer from the lists of printer’s driver. Then click Next.
  • Page 17 13. If you already have the printer’s driver installed, you will be asked whether to keep it or to replace it. Click Next. Supply a name for the printer and choose whether you want to make it your default printer. Then click Next. 14.
  • Page 18 17. Right-click, select Properties -> Ports and verify that the print server’s port appears.

  • Page 19: Using Psadmin

    18. Go to General; click Print Test Page to verify the configuration. 19. Done. Note: If you want to install more print servers, start setup wizard from your Windows Start menu: start -> All Programs -> Network Print Server -> PSWizard and repeat the installation procedure.

  • Page 20: Wizard

    Wizard Wizard is a configuration program that can assist you in setting up the necessary parameters for your print server device to function. Setup a print server by using Wizard. TCP/IP Wizard Click Wizard button just like a picture ＜ ＞.and select TCP/IP Wizard.
  • Page 21 (Optional) In the Subnet Mask option, type the Subnet Mask your LAN or network segment is currently configured to use. (Optional) In the Gateway field, type the IP address of gateway. When done, click OK button. The program will save the above settings into the print server.

  • Page 22: Manual Setup

    Manual Setup Manual Setup is a configuration program designed for more experienced users of NetWare. To setup the print server by using Manual Setup follow the steps: 1. Run PCONSOLE in NetWare 3.x or NetWare 4.x and create the necessary parameters (Refer to your Novell NetWare print server/Services manual for details).
  • Page 23 Properties –TCP/IP Options The TCP/IP options allow you to modify the print server’s TCP/IP settings. Each option is detailed as follows. Obtain an IP address from a DHCP server: This option enables or disables the DHCP feature of the print server. When this option is enabled, the print server will obtain an IP address automatically from the DHCP server on your LAN.

  • Page 24: Refresh

    Upgrade Upgrade allows the user to upgrade the print server device. In order to upgrade the unit please perform the steps as follows: 1. Click Upgrade button just like a picture ＜ ＞, as shown as follow picture elect General Upgrade. Make sure that the upgrade file is located in the same directory as PSAdmin.

  • Page 25: Multiple Print Queues Configuration

    Note: Configure the print speed in the Advanced label, must match the printer’s speed which connect to the print server. Undependable configuration will cause printer to abnormal printing. Multiple Print Queues Configuration To configure the print server to service multiple print queues, please follow the instructions listed below: 1.
  • Page 26 Click Change or Remove Programs tab. Select Network Print Monitor for Windows 95/98/NT/2000/XP/2003 and click Change/Remove button. The un-installation wizard program will be launched. Follow the directions on the screen to complete the un-installation procedure.

  • Page 27: Internet Printer Connection And Hp Web Jetadmin

    4.Internet Printer Connection and HP Web JetAdmin IPP Overview Print server(s) support the Internet Printing Protocol (IPP). Using the appropriate software on your system, you can create an IPP print path from your system as Windows PC over the Internet. Note: For incoming print path requests, the network administrator have to configure the firewall to accept incoming IPP requests.
  • Page 28 6.In URL’s box, input print server’s IP address, for example, http://192.168.10.182/lp1. Then Click Next. ** One port should be the port name as lp1. It will check print server to connect to HP printer, if not, it will appear as follow picture. Then Click OK.

  • Page 29: Hp Web Jetadmin Overview

    9.If you want your Windows-based programs to use this printer as the default printer, please select “Yes”, and Click Next. It will appear as follow picture 20. Click Finish button. 21. Done. HP Web JetAdmin Overview HP Web JetAdmin allows you to use a Web browse to revise, view, manage and diagnose devices connected to the print server or any standard printer MIB devices.

  • Page 30: Installing Hp Web Jetadmin

    Installing HP Web JetAdmin Before installing the HP Web JetAdmin software, you must have domain administrator or root privileges: Download the installation files from HP Customer Care Online at http://www.hp.com/go/webjetadmin/. Follow the instructions on the screen to install the HP Web JetAdmin software. Note: Installation instructions are also contained in the HP Web JetAdmin install file.

  • Page 31: Configuration From Embedded Web Server

    5. Configuration from Embedded Web Server Overview The Print Server contains an embedded web server that can be accessed through a supported web browser on a LAN, for example, IE 4.0, Netscape 4.0 or above is recommended. The embedded web server provides access to configuration and management pages for the print server and the connected peripheral device.
  • Page 32 Print Server Name: This option allows you to view device name of the print server. To correct the print server’s device name. System Contact: This option allows you to view contact name of the print server. To check the print server’s contact name who in charge of this device. System Location: This option allows you to view Location name of the print server.
  • Page 33 Printer Status Click Status, it then appears the sub-menu. Click Printer, it then as shown in the following picture. Manufacturer: This option allows you to view manufacturer of the printer. When the printer connected with the print server, it will be show in the manufacture box. Model Number: This option allows you to view model of the printer.
  • Page 34 Use DHCP/BOOTP: This option allows you to view DHCP/ BOOTP status. If there is a DHCP/BOOTP server on your network, this option allows the print server to obtain IP-related settings automatically from your DHCP server. IP Address: This option allows you to view IP address from the print server. The IP address must meet the IP addressing requirements of the network segment.
  • Page 35 General Settings: Print Server Name: This option allows you to view print server’s name would be configured by PSAdmin utility. Polling Time: This option allows you to view polling time from the print server. This function is search for NetWare Server by per time NetWare NDS Setting: Use NDS Mode: Enable or Disable.
  • Page 36 AppleTalk Status Click Status, it then appears the sub-menu. Click AppleTalk, it then as shown in the following picture. AppleTalk Settings: If no any zone exists, the print server itself displays the zone name as an asterisk (*) in the current AppleTalk Status of the print server in the web browser.
  • Page 37 SNMP Communities: This option allows you to view SNMP communities from the print server. There are two communities that control message from the network management of the print server. SNMP Traps: This option allows you to view SNMP traps from the print server. SMB Status Click Status, it then appears the sub-menu.

  • Page 38: Setup Menu

    Shared Name: This option allows you to view the Shared Name from the print server. Setup Menu Meanwhile, you have finished the IP address configuration with print server. You should use web browser to configure the print server. The setup menu of the print server helps administrator to setup the print server’s System, Printer, NetWare, TCP/IP, SNMP and AppleTalk.
  • Page 39 Email Alert: This option allows you to Enable/Disable the Email Alert support. SMTP Server IP Address: This option allows you to input the IP address of your Email SMTP server. Administrator E-mail Address: This option allows you to input your Email address that you want to receive the notification by Email.
  • Page 40 Bi-directional Settings: This option allows you to select the bi-directional of the print server. There are two ways to select this option, includes Disable or Auto Detect. TCP/IP Setup: 3. Click Setup, it then appears the sub-menu. Click TCP/IP, it then as shown in the following picture.
  • Page 41 DHCP/BOOTP: This option allows you to select DHCP/ BOOTP option. If there is a DHCP/BOOTP server on your network. This option allows the print server to obtain IP-related settings automatically from your DHCP server. IP Address: This option allows you to input IP address from the print server. The IP address must meet the IP addressing requirements of the network segment.
  • Page 42 Print Server Name: This option allows you to input print server name which configured by PSAdmin utility or PCOMSOLE program. Polling Time: The time interval in which the print server unit polls the file server for servicing of print queues. Logon Password: This option allows you to input encrypted password from the print server.

  • Page 43: Installing Print Server On Net Ware 4. X /5. X

    Installing Print Server on NetWare 4.x/5.x Due to its architecture and functionality, the print server must work under NetWare 4.x/5.x NDS Bindery Emulation. When you install the NetWare file server for the first time, by default, the installation program will automatically set up the Bindery Emulation function for you by adding “SET BINDERY CONTEXT =”...
  • Page 44 9. From your NetWare client computer, such as Windows 95/98/Me, create a printer that is connected (redirected) to the NetWare print queue serviced by the print server. Note: Please refer to NetWare’s Print Server/Services manuals for detailed PCONSOLE commands. AppleTalk Setup The print server can print jobs submitted from Macintosh workstations connected to an Ethernet using AppleTalk protocol.

  • Page 45: Setting Up A Macintosh Computer

    Note: The default print server’s Chooser name is as shown as follows: <ATALK_PS>-xxxxxx-1, where xxxxxx represents the last six digits of the device’s Node ID. For example: ATALK_PS-40EEED-1. You may also change the <ATALK_PS> to a name you like for identification purpose in this option. The print server will append the last six digits to the name you specify.
  • Page 46 SNMP Setup TCP/IP networks use a standard management protocol called Simple Network Management Protocol (SNMP). SNMP is widely used in the industry as a solution for remote network management and monitoring of networking devices. SNMP actually includes a protocol, a database structure specification, and a set of database objects. The database objects are contained in a standard database called Management Information Base (MIB) that is stored on the networking device called SNMP agent.
  • Page 47 snmp.snmpEnableAuthenTraps Enables disables function sending SNMP Authentication Failure trap message network administrator, if the community name within a SNMP request is not correct. Users can set up print server’s SNMP functions by using their browsers. Click Setup, it then appears the sub-menu. Click SNMP, it then as shown in the following picture.
  • Page 48 The print server supports the SMB (Server Message Block) protocol, user can send the print jobs through Network Neighborhood without installing print server’s driver. 1. Click Setup, it appears the sub-menu. 2. Click SMB, it as shown in the following picture. 3.

  • Page 49: Network Print Monitor

    6. Network Print Monitor Preparation The print server supports TCP/IP, IPX/SPX and NetBEUI protocols under Windows 95/98/Me. Please make sure that the following steps have been completed before proceeding with installation under Windows PC. Select A Desired Protocol TCP/IP The TCP/IP Protocol must be installed. For further information, please read “TCP/IP Protocol Installation”...

  • Page 50: Tcp/Ip Protocol Installation

    TCP/IP Protocol Installation 1. Click Start, point to Settings and select Control Panel. 2. Double click the Network icon. 3. If the TCP/IP Protocol is not already installed, click Add. 4. Select Protocol and click Add. 5. Select Microsoft from the Manufacturers list. 6.

  • Page 51: Netbeui Protocol Installation

    NetBEUI Protocol Installation 1. Click Start, point to Settings, and select Control Panel. 2. Double click the Network icon. 3. If the NetBEUI is not already installed, click Add. 4. Select Protocol and click Add. 5. Select Microsoft from the Manufacturers list. 6.
  • Page 52 10. A message reading, “After your printer is installed, Windows can print a test page so you can confirm that the printer is set up properly.” Select No and click Finish. 11. Double-click the newly created Printer Name icon. 12. Select Printer and Properties. 13.

  • Page 53: Uninstalling Network Print Port On Windows 95/98/Me/Nt/2000/Xp/2003

    By default, the computer will first search for the print server(s) on the network by using the IPX/SPX protocol. If the IPX/SPX protocol is installed, the print server will be displayed along with its Node ID, as shown in Node column. (The last 6 digits of the Node ID, located on the back of the print server unit).

  • Page 54: Tcp/Ip Lpr Port Printing Installation

    7. TCP/IP LPR Port Printing Installation Basic TCP/IP Installation Overview When installing your print server in a TCP/IP environment, IP addresses are essential as a basic means of communications. It is therefore necessary to first assign an IP address to your print server unit.
  • Page 55 From the Printer Ports box as shown in the following picture, select the LPR Port. 6. The Add LPR compatible printers box will then appear as shown in the following picture. Type in the IP address assigned to the print server in the Name or address of server providing lpd box.

  • Page 56: Windows 2000/Xp/2003 Standard Tcp/Ip Port Printing Installation

    Windows 2000/XP/2003 Standard TCP/IP Port Printing Installation lick Start, point to Settings, and select Printer. Run Add Printer, Click Next. The Add Printer Wizard screen will appear, Select Local Printer and click Next. From the type of Create a new port box as shown in the following picture, select the Standard TCP/IP Port, Click Next and Next.
  • Page 57 In the Add Standard TCP/IP Printer Port Wizard box as shown in the following picture, Select Custom, Click Settings button, and click Next. In the Configure Standard TCP/IP Port Monitor box as shown in the following picture, select LPR form Protocol, type in a queue name, for example, lp1. Click OK, and Next.
  • Page 58 10. Select the appropriate printer manufacturer and printer type list and click Next. 11. Type in a new Printer name or leave it in default, and click Next button. 12. A message reading, “To confirm that the printer is installed properly, you can print a test page”.

  • Page 59: Unix Installation

    UNIX Installation After the static IP address is assigned, the Print Server is ready to be configured. For some UNIX/Linux systems, we include the detailed installation procedures below. If you can’t find the installation procedure corresponding to your UNIX system, please refer to your UNIX manuals for details about configuring your UNIX for the “remote printing system”.
  • Page 60 Redhat Linux 9 The Print Server can work under any Linux-based systems, including Slackware, RedHat, etc, without any problems. Basically, the Linux's printing system is based on BSD system. Although many commercial Linux systems are available in the market and their commands will vary slightly, depending upon which version is used, the functionality of the Linux-based variants is exactly the same.
  • Page 61 7. In the Name field, type a user-defined name, click Forward. 8. In the Queue Type field, choose Networked UNIX. 9. In the Server field, type the IP address of print server 10. In the Queue field, type a print server’s port name, which connect to the printer. For example: lp1.
  • Page 62 13. Choose the model of printer and click Forward. 14. Done.

  • Page 63: Upgrading Print Server

    8.Upgrading Print Server Overview Upgrading print server will allow you to upgrade its firmware inside the print server while the newer software version of the print server is available from your local dealer. Depending on the different systems users might use, this chapter is divided into several Sections; please refer to the following lists for your systems.

  • Page 64: Upgrading The Print Server From Unix (Through Tcp/Ip)

    3. Wait for the transfer successful message. 4. Done. Upgrading the print server from UNIX (Through TCP/IP) 1. Log in as root 2. Ensure binary file is located in your current working directory. 3. Type “tftp <print server’s IP address>”. 4.
  • Page 65 Click Browse… and select the firmware file. Click Upgrade. Done.

  • Page 66: Troubleshooting

    9. Troubleshooting General Troubleshooting Overview The most common problems, which cause the print server to perform improperly, are covered in this chapter. If a problem still exists after reading this chapter, please contact your dealer for technical support. LED Light Indicators The print server is equipped with LED lights to assist in diagnosing problems that are the result of the network and/or the print server hardware itself.

  • Page 67: Windows 95/98/Me/Nt/2000/Xp/2003 Troubleshooting

    Windows 95/98/Me/NT/2000/XP/2003 Troubleshooting Multi-Segment LAN Environment Installation (through the Network Print Port) If your print server and Windows 95/98/Me/NT/2000/XP/2003 are located on two different segments, and your Windows NT server is used as the router/gateway you will need to implement the following procedures in order for your print server to function properly: Add the RIP for NWLink IPX/SPX compatible transport.

  • Page 68: Moving The Print Server Toa New Segment

    Moving the print server to A New Segment If the print server is moved from one network segment to another after the initial installation, through the Network Print Port, the print server must be reconfigured on the original Windows NT server or on each Windows 95/98 computer using this print server in order for the print server’s driver on each computer to re-establish a new connection.

  • Page 69: Moving Your Computer Toa New Segment

    Moving Your Computer to A New Segment If you are using the print server through the Network Print Port on your NT or Windows 95/98/Me computer and your computer is going to be moved onto another segment, you have to reconfigure the print server on your computer to use your print server. However, this situation is like moving the print server to a new segment.
  • Page 70 If this is the case, please consult your network administrator to obtain an unused IP address for your print server. C. The print server is on one segment and your Windows NT server is on the other segment. (This troubleshooting guide will also apply to a multiple-segmented network while installing the print server) For example, assuming the print server is on Segment A, NT server is on Segment B, and there is a gateway computer between Segment A and Segment B.
  • Page 71 6. In your editor, modify "BoxIPAddress" field from "0.0.0.0" to "192.72.214.100". Leave other options as default and do not change their values. When done, save this new file and quit from your editor. Please note, in this step you must specify an IP address which is valid on Segment B, such as 192.72.214.100 in this example, rather than 192.72.214.68.

  • Page 72: Appendix

    Appendix: Rendezvous with Mac OS X 10.3.7 1. Enable the Rendezvous settings from the print server’s WEB configuration. 2. Click "Printer Setup Utility” from the bottom toolbox of Mac.
  • Page 73 3. Click "Add".
  • Page 74 4. Choose "Rendezvous", and then Mac OS will automatically search the print server on the network. Choose the proper printer model that connected to print server, and then click "Add".
  • Page 75 6. Now the network printer with Rendezvous has been successfully installed. SMB Printing with Windows XP 1. Enable the SMB settings from the print server’s WEB configuration. Assume your computers use the “WORKGROUP” as the SMB workgroup name in Windows. Please assign the same SMB name to your print server.
  • Page 76 2. Now you can find the print server from the SMB workgroup of Windows. Then, double click it. 3. Double click it again.
  • Page 77 4. Now you have to install the printer’s driver. 5. Choose it from the “Add Printer Wizard”.
  • Page 78 6. Install printer successfully. 7. Now, you can find your printer’s icon and you can use the SMB printing mode.
  • Page 79 Reset Button Reboot the Print server: 1. Verify the power of print server is turned on. 2. Press the reset button once, and then release it. WARNING: This will restart the print server and stop all on-going and pending print jobs! Perform a Factory Default: 1.
  • Page 80 Print Self-test Page: 1. Verify the power of print server is turned on. 2. Press the reset button for 5 seconds, and then release it. 3. Then the self-test page including the factory default settings will be printed. Note: 1. It is strongly recommended to use Laser Printer for self-test page printing. 2.

  • Page 81: Frequently Asked Questions

    Frequently Asked Questions Question A Print jobs are sent to the print queue successfully, but fail to be sent to the printer. Possible explanations 1. The Print server Name/Print Queue configuration in PCONSOLE is incorrect. 2. The Print server name specified and stored in the print server memory doesn’t match the same one set in PCONSOLE.
  • Page 82 Question D The Status LED light keeps blinking after POST. Possible explanation and solution The last upgrade process was not completed. The print server must be upgraded again by using the PSAdmin. Please see Chapter 3 for details. Question E The PSAdmin reports “Create Print server Error”, “Create Printer Error”, or “Create Print Queue Error”...

  • Page 83: Additional Installation Instructions

    Question H When I try the POST function (Power On Self Test), the light on the HP 948c/895Cxi is flashing, which indicates lack of paper, but there is paper in the printer. Although the light on the HP 948c/895Cxi is flashing when you are trying the POST function, the printer server and printers are still working normally.
