StarTech.com PRESREMOTEG Quick Start Manual

Wireless Presentation Remote with Green Laser Pointer
ATTENTION!
DO NOT STARE INTO BEAM
DO NOT POINT AT AIRCRAFT
Class 2 Laser Product
LASER RADIATION
WAVELENGTH: 532 ± 10nm
Max optical power: 1mW
Product Diagram (PRESREMOTEG)
9
7 8 10
1
2
3
Button/LED
Indicates remote activity, lights up when buttons on the
Remote are pressed.
Notes: The USB Wireless Receiver must be removed
1
LED Indicator
from the remote for the LED Indicator to work.
The LED Indicator will flash when the batteries need to
be replaced.
Starts or ends the presentation within compatible
software.
2 Play/ESC
Used as the Back button when in menus.
Used as the zoom out function when zoomed in.
Moves to the previous action. (animations, transitions,
3
Last
slides, etc.).
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
11
4 5
Function
Button/LED
4 Tab
5
Laser
USB Wireless
6
Receiver
7
Volume Up
8 Volume Down
9 Blank
10
Next
11 Enter
Requirements
6
For the latest requirements, please visit www.startech.com/PRESREMOTEG.
• Host Computer with USB-A Port.
Battery Installation
1. Press down on the Battery Bay and slide the Battery Cover away to reveal the
Battery Compartment.
2. Insert two AAA Batteries (included), aligning the positive (+) and negative (-) ends
of the batteries with the indicators inside the Battery Compartment.
3. Align the Battery Cover on the back of the Remote and slide it back into place.
Connecting the Remote
1. Remove the USB Wireless Receiver from the Storage Slot on the bottom of the
Remote.
2. Connect the USB Wireless Receiver to a USB-A Port on the Host Computer.
Note: The Remote will appear as 2.4G PRESENTER in system menus on the Host
Computer.
Function
Cycles through on-screen elements.
Note: When not presenting, the Tab Button cycles
through screen elements on the screen the mouse
indicator is located.
Activates the Laser Pointer.
Note: The USB Wireless Receiver must be removed
from the remote for the Laser Pointer to work.
Connects the Remote to the Host Computer.
Turns the Host Computer's volume up.
Turns the Host Computer's volume down
Turns the screen Off/On.
Moves to the Next action (animations, transitions,
slides, etc.).
Emulates the Enter/Return button on a keyboard.
Quick-Start Guide
