- Page 1 7" Swivel Portable DVD Player with Digital TV Tuner and USB/SD/MMC inputs MODEL NO.:NPDT-750 INSTRUCTION MANUAL BEFORE USING THIS PRODUCT, READ, UNDERSTAND, AND FOLLOW THESE INSTRUCTIONS. Save this booklet for future reference.
- Page 2 TROUBLESHOOTING (CONTINUED) Symptom [DVD] Remedy Play does not start even Confirm the region code setting is right. when title is selected. Audio soundtrack and/or subtitle If the audio soundtrack and/or subtitle language does not language is not the initial settings. exist on the disc, the language selected at the initial settings will not be seen/heard.
-
Page 3: Safety Information
SPECIFICATIONS SAFETY INFORMATION Power requirements: (2) Compact disc(VIDEO CD) 12 cm disc AC 100 -240V~ 50/60Hz CAUTION: 8 cm disc Power source: DVD/VIDEO CD/CD PLAYER IS A CLASS 1 LASER PRODUCT. HOWEVER THIS DVD/ Video output level: AC adaptor (normal: DC12V) VIDEO ,CD/CD PLAYER USES A VISIBLE LASER BEAM WHICH COULD CAUSE Audio output level Power consumption:... -
Page 4: Disc Handling And Maintenance
DEFINITION OF TERMS Read all instructions before using Do not use this product near water. Do not ceiling- or wall-mount the product. Install the product in accordance with the operating instructions. This refers to a high-density optical disc on which high-quality pictures and sound have been Do not set the product near heat sources, such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. -
Page 5: Accessories
Do not use record cleaning sprays, benzine, thinner, static electricity prevention liquids. 6 SYSTEM SETUP Be careful not to drop or bend the disc. Do not install more than 1 disc on the disc compartment. System Setup Do not try to close the disc cover when the disc is not installed properly. Be sure to store the disc in its exclusive case when not in use. -
Page 6: Table Of Contents
5.PROGRAM CONTROL SETUP TABLE OF CONTENTS Input Password Getting Started: Please enter the password by 0-9 Safety information DISC handling and maintenance Accessories Features Control reference guide -Press up or down button to select this item, and press right button to enter INPUT PASSWORD Basic connection page, Input 0000(In this unit, the original password is 0000) to enter PROGRAM CONTROL... -
Page 7: Features
2.2 SKIP FEATURES -Press up or down button to select skip item, then press left or right button to select on or off . ON: If SKIP is ON, channel number what you select will be skipped when selecting channel 7 TFT DISPLAY "... -
Page 8: Control Reference Guide
MAIN MENU CONTROL REFERENCE GUIDE Common procedure for initial settings Main unit 1.Press MENU button. U SB P H O N E AV OU T S D /M MC IN PU T 9 -1 2V --- POW ER 2.Use the UP or DOWN button to select preferred page, then press RIGHT button to enter. Each page for setting the value will display. - Page 9 CONTROL REFERENCE GUIDE It is used to set the caption mode. Remote control -Keep pressing CC button to select different mode as desired. 1.MUTE -To mute the sound. MUTE STANDBY INVERSION USB/CARD/DVD -Option:On/Off 2.INVERSION button -Press this button to inversion the picture which played.
-
Page 10: Basic Connection
BASIC CONNECTION TV OPERATIONS Ensure all the cables are disconnected from the main unit before connecting to AC power TURN ON THE UNIT source . Read through the instructions before connecting other equipment. 1. Push POWER switch at the right side of the unit to turn on the unit. 2. - Page 11 Connecting to TV set 2. AUDIO SETUP TV set --AUDIO SETUP PAGE-- SPEAKER SETUP EQUALIZER To video input connector (yellow) To audio input connectors (red, white) Video/audio cable GOTO AUDIO SETUP PAGE TO AV OUT JACK U SB PH ON E A V OU T SD/M MC POW E R IN P U T 9-1 2V ---...
-
Page 12: Remote Control Preparation
REMOTE CONTROL PREPARATION 1.1 TV TYPE-It is for selecting the TV system according to the colour system of the TV. Option:PAL Battery installation NTSC Insert the battery while observing the correct 1.2 TV DISPLAY - It is for selecting TV output mode. (+) and (-) polarities as illustrated at right(Fig 1). -
Page 13: Dvd Operations
Viewing from different DVD OPERATIONS angle (DVD only) Before enjoying DVD/Video CD/CD The On-Screen menu language of the unit has been factory pre-set to English. If you want Some DVDs may contain scenes which have to change the menu language to other been shot simultaneously from a number of language, please refer to "DVD operations / different angles. -
Page 14: Stopping Play
Stopping play GO TO Press GO TO button continuously to select the itemyou want to set and enter a time number, chapter number, track number etc. Accordingly, the disc wil l be played fromthe selected point. Press the STOP button to stop playing a disc. NOTE: When player is stopped, the player records the point where STOP was pressed Changing subtitle language... -
Page 15: Slow-Motion Play(Dvd/Vcd)
Slow-motion play(DVD/VCD) Repeat play Press REPEAT button during play, it will Press the SLOW button during playback. repeat play one chapter or one title (for DVD 1) Plays the disc at a 1/2 of normal speed at disc), or repeat play track (for VCD/CD). first. -
Page 16: Mp4 Playback
On screen display information Mp4 playback Press DISP button to display playing information. 1.Insert the disc containing the files in Mp4 format to be played and after several DVD disc seconds, the monitor will show all the TI TLE ELA PSED TIT LE REMAIN folders on the disc: T: 02/03 C: 07/28... -
Page 17: Card Playback
CARD Playback JPEG CD 1.Insert the CARD(SD/MMC/MS) containing Slide show effects the files in VCD/SVCD/DVD/MP3/WMA/MP4/ JPEG CD format to be played. Press PROGRAM button to select one of the 2.Press USB/CARD/DVD button to switch the effects when changing from one picture to unit in CARD reader mode. -
Page 18: Usb
JPEG CD USB Playback ROTATING 1.Insert USB containing the files in VCD/SVCD/ For JPEG picture CD, select the folder you DVD/MP3/WMA/MP4/JPEG format to be want to play using the navigation buttons and played. press ENTER button to confirm. 2.Press USB/CARD/DVD button to switch the The files in this folder are displayed and unit in USB reader mode.
