To see an example of the for loop use the situation alluded to above. That is, a need
to clear each string element in a string array. A program to accomplish this might
look like the following.
DIGITAL_INPUT clearArray;
INTEGER i;
STRING stringArray[50][14];
PUSH clearArray
{
for (i = 0 to 14)
{
stringArray[i] = "";
print("cleared element %d\n",i); // debug message
}
}
In this example, the loop index i is set to run from 0 to 14, which represents the first
and last elements in stringArray respectively. Also notice that the step keyword is
omitted. This keyword is optional and if it is not used, the loop index increments by
1 each time through the loop. To clear only the even-numbered array elements, the
following could have used.
for (i = 0 to 14 step 2)
{ . . . }
The step value can also be negative, allowing the loop index to be reduced by some
value each time though the loop.
The for loop flexibility can be enhanced further by using expressions instead of
constant values for the start, end, and step values. For example, there might be a need
to add up the value of each byte in a string in order to calculate the value of a
checksum character. Since the length of the string can change as the program runs,
the number of iterations through the loop is unknown. The following code uses the
built-in function, len, to determine the length of the string and only run through the
for loop the necessary number of times. System functions are described in detail in
"Using System Functions" on page 30.
checksum = 0; // initialize the chucksum variable
/* iterate through the string and add up the bytes.
Note that the { } braces are not needed here
because the contents of the for-loop is only
a single line of code */
for (i = 1 to len(someString))
checksum = checksum + byte(someString,i);
/* now add the checksum byte on to the string
using the chr function. Note that in this
example we only use the low-order byte from
the checksum variable */
someString = someString + chr(checksum);
Crestron SIMPL+
// a trigger signal
// the index variable
// a 15-element array
// event function
// set the ith element
// to an empty string
// this ends the for
// loop
// this ends the push
// function
