Hitachi CP-X5022WN Specifications

CP-X5022WN LCD Projector
AMX Device Discovery
3LCD Technology
Key Features
•5,000 ANSI Lumens
•Native XGA
•3000:1 Contrast Ratio
•Hybrid 5,000 Hour Filter*
•Throw Ratio 1.8 -3.0 @ 60" Screen
•1.7X Zoom Lens
•Perfect Fit 4 corners 4 sides
•Horizontal/Vertical Lens Shift
•HDMI (HDCP)/Component/
Composite/S-Video
•BNC/RGB In/RGB Out
•WiFi Capable
•iOS app Compatible
Aspect Ratio 4:3
Aspect Ratio 4:3
Screen Size* Throw Distance*
Screen Size* Throw Distance
Diagonal* Width* Min*
Diagonal Min
30 24 35
30 0.9m
60 48 71
60 1.8m
80 64 95
80 2.4m
100 80 119
100 3.0m
120 96 143
150 3.6m
150 120 180
200 4.5m
200 160 240
250 6.1m
300 240 361
300 9.1m
Throw Ratio: 1.5 - 2.5:1 (distance : width)
Throw Ratio: 1.5 - 2.5:1 (distance : width)
*Measured in inches
*Measured in cms
Disclaimer: Please use this throw distance calculator for reference purpose only. For permanent
installation purpose, we recommended that you assume 10% calculation margin of error or to test the
unit on site.
** Actual lamp life will vary by individual lamp and based on environmental conditions, selected operating
mode, user settings and usage. Hours of average lamp life specified are not guaranteed and do not
constitute part of the product or lamp warranty. Lamp brightness decreases over time.
* Actual filter life will vary by individual filter and based on environmental conditions, selected operating
mode, user settings and usage. Hours of average filter life specified are not guaranteed and do not
constitute part of the product warranty.
For sales information, please call 1800 HITACHI
Printed 10.10
Crestron Integrated Partner
HDMI
3 Year Warranty
•Network Control, Maintenance and Security
•Network Bridge RS-232 Control
•USB Connection to Computer
•PC-Less Presentation
•Network Messenger
•Present Content via LAN
•.5 Watt Power Saving Mode
•16W Speaker Output
•Standby Audio
Model Name
•Template Function
Liquid Crystal Panel Structure
•Easily Stackable for 2X Light Output
Number of Pixels
•29dB (Eco Mode)
Resolution
• Auto Eco Mode
Colors
Aspect Ratio
Lens
Throw Ratio (distance : width)
Lamp
Brightness
Color Light Output
Expected lamp Life
Contrast Ratio
Speaker Output
Power Supply
Power Consumption
Operating Temperature
Input Signals
Acoustic Noise Level
H-Sync
V-Sync
Horizontal Keystone
Vertical Keystone
Approvals
RGB Input
RGB Output
Digital Input
Video Input
Audio
Max*
Ethernet
Max
58
Control Terminals
1.5m
Other
118
Dimensions (W x D x H)
3.0m
Weight
158
4.0m
Additional Features
198
5.0m
238
6.0m Supplied Accessories
298
7.5m
Projector Part #
398
Lamp Part #
10.1m
Remote Control Part #
597
Filter Part #
15.1m
CP-X5022WN
0.63" polysilicon active-matrix TFT x 3
786,432 pixels
540 TV lines
Video
RGB 1024 dots X 768 lines
16.7 million colors
Native 4:3
Zoom 1.7X / focus (F=1.6 ~ 2.1, f=19~32mm)
1.5 - 2.5:1
245W UHP
5,000 ANSI Lumens
5,000 ANSI Lumens
Approximately 3,000 hours (normal) 5,000 hours (Eco Mode)**
3000 : 1 (using active IRIS)
16W
AC100 - 120V / AC220 - 240V 50/60 Hz Power
380W
5˚C - 35˚C (41˚F - 95˚F)
RGB VGA, SVGA, XGA,WXGA, SXGA, SXGA+, UXGA, MAC 13", MAC 16"
NTSC, NTSC4.43, PAL, SECAM, PAL-M, PAL-N
Composite Video
480i, 576i, 480p, 720p, 1080i, 1080p
Component Video
36 dB (30 dB in Eco Mode)
15 Hz - 106 Hz
50 kHz - 120 kHz
+ / - 40˚
+ / - 40˚
UL, C-UL, FCC, CE, RoHS
Analog RGB 15pin Mini-Dsub x 1, BNC x 5 (RGBHV)
15pin Mini-Dsub x 1
RGB
HDMI x 1 (HDCP Compliant)
Mini DIN 4-pin connector x 1
S-Video
Composite Video RCA jack x 1
Component Video Share with Analog RGB
Stereo Mini jack x 2, RCA(L/R) x 1 pair,
Input
Microphone Jack(stereo mini) x 1
Output RCA(L/R) x 1 pair
RJ-45 port
9-pin D-sub connector x 1 (RS-232 control)
USB-A, USB-B
401 x 318 x 103
4.6 KG
Kensington Slot, Digital Gamma Correction, Whiteboard / Blackboard Mode, Input
Source Naming, MyMemory / MyScreen / MyButtons / MyText, Auto V Keystone, Serial
Number on Side, Transition Detector, Security Bar
Remote Control, Batteries (AA), RGB Cable, US Power Cord, Multiple Language
Operator / Safety Manual, Lens Cap, Security Label
CP-X5022WN
DT01171
HL02771
MUO7791
HDMI
USB Type A
LAN
Audio In 1
Audio In 2
Audio In 3
Security Bar
Kensington Lock
Mic
Audio Out
All specifications subject to change without notice.
3LCD and the 3LCD logo are registered trademarks of the Seiko Epson Corporation.
©2012 Hitachi Australia Pty. Ltd. All Rights Reserved.
USB Type B
Computer In 1
Analog RGB In 2
Monitor Out
Remote Control
Control (RS-232C)
Component Video
Composite Video
S-Video
