Summary of Contents for DaVinci RHYTHM 2
- Page 1 DAVINCI GLIDERS / RHYTHM2 REV. 1 FEB 2021 Davinci Products Inc. 53 Sinchon-gil, Okcheon-myeon, Yangpyeong-gun, Gyeonggi-do, South Korea. (12505) Tel. +82(0)10-9799-3472 Fax. +82(0)10-9799-3472 sales@dv-gliders.com www.flydavinci.com...
- Page 2 ANY OTHER PARAGLIDER WITHOUT PROPER INSTRUCTION FROM A CERTIFIED PROFESSIONAL INSTRUCTOR IS EXTREMELY DANGER- OUS TO YOURSELF AND BYSTANDERS. DAVINCI GLIDERS are carefully manufactured and inspect- ed at the factory. Please use the glider only as described in this manual.
- Page 3 DAVINCI GLIDERS / RHYTHM2 INDEX 1. Technical DATA 2. Materials DATA 11.3 Full stall 11.4 Deep stall 11.5 Asymmetrical stall 3. Introduction and Pilot Target 11.6 B stall 4. Harness 11.7 Cravat 5. Risers 12. Descent Techniques 6. Lines 12.1 Big ears 7.
-
Page 4: Technical Data
DAVINCI GLIDERS / RHYTHM2 1. Technical DATA RHYTHM2 Anzahl der Zellen Zellen Gesppert Fläche ausgelegt m² 21.2 23.0 25.0 27.0 29.5 Spannweite aus- FLAT 10.1 10.5 11.0 11.4 11.9 gelegt Streckung aus- gelegt Fläche projiziert m² 18.3 19.8 21.6 23.3 25.4... - Page 5 DAVINCI GLIDERS / RHYTHM2 2. Materials DATA CANOPY FABRIC CODE SUPPLIER UPPER SURFACE MJ40 MF MYUNGJIN TEXTILE BOTTOM SURFACE MJ40 MF MYUNGJIN TEXTILE PROFILES MJ38 HF / MJ32 HF MYUNGJIN TEXTILE DIAGONALS MJ32 HF MYUNGJIN TEXTILE SUSPENSION LINES FABRIC CODE...
- Page 6 DAVINCI GLIDERS / RHYTHM2 3. Introduction and Pilot Target The RHYTHM2 is an easy-going EN/LTF A glider that is suitable for the training of paragliding. The main focus of the design is on safety and maximum forgiveness in handling, but with an eye to handling and performance.
-
Page 7: Accelerator System
DAVINCI GLIDERS / RHYTHM2 5. Risers RHYTHM2 has 3 risers. The A riser has a red cover to easy identification. There is another line with red mailon. There is A’ and is for the big ears. A’ Standard Accelerated Travel length... -
Page 8: Pre-Flight Check
DAVINCI GLIDERS / RHYTHM2 8. Pre-flight check To know yourself with the glider it is a good idea to perform practice inflations and ground handling in advance. You should have no difficulties flying the RHYTHM2 for the first time in suitable conditions, but as with all new equipment. -
Page 9: In Flight Characteristics
DAVINCI GLIDERS / RHYTHM2 10. In flight characteristics RHYTHM2 has the best stable glide performance in a normal position with no any brakes. In strong thermals and turbulence, we recommend gently pull both brakes without acceleration to increase stability. The brakes provide feedback about the surrounding air, which is needed for active flying. -
Page 10: Full Stall
DAVINCI GLIDERS / RHYTHM2 11.3 Full stall The full stall can occur when you fully pull both brakes enough a long time. This means that the wing loses its forward momentum. To recover to the normal flight you must release both brakes. After this usually comes a front dive with a possible front deflation. -
Page 11: Descent Techniques
DAVINCI GLIDERS / RHYTHM2 11.7 Cravat In case a cravat should occur from an asymmetric collapse or other maneuvers, it is important to keep your flying direction by applying some brake on the opposite side and weight shift. You can also use strong deep pumps on the brake to the cravated side. If a pull of the brake line is unsuccessful, pulling the stable line which is the outermost line on the B-riser may work. -
Page 12: Maintenance And Cleaning
DAVINCI GLIDERS / RHYTHM2 13. Landing We recommend landing with trimmers to the normal slow position. Don’t use sharp turns or radical maneuvers. When you are 1-2m over the ground, you should face into the wind and standing upright and ready to run. -
Page 13: Caring Tips
Do not leave marked tracks and do not leave rubbish behind. Do not make unnecessary noise and respect sensitive biological areas. The materials used on a paraglider should be recycled. Please send old Davinci gliders back to us Davinci Gliders offices. We will undertake to recycle the glider. - Page 14 DAVINCI GLIDERS / RHYTHM2 Checked line sheet(with riser) DAVINCI GLIDERS / RHYTHM2 The measured values at the lower surface of the tailing edge, cll depth and spacing of the articulation points were determined under tensile load of 50N. The length difference is not more than ±10 mm.
- Page 15 DAVINCI GLIDERS / RHYTHM2 Checked line sheet(with riser) DAVINCI GLIDERS / RHYTHM2 The measured values at the lower surface of the tailing edge, cll depth and spacing of the articulation points were determined under tensile load of 50N. The length difference is not more than ±10 mm.
- Page 16 DAVINCI GLIDERS / RHYTHM2 Checked line sheet(with riser) DAVINCI GLIDERS / RHYTHM2 The measured values at the lower surface of the tailing edge, cll depth and spacing of the articulation points were determined under tensile load of 50N. The length difference is not more than ±10 mm.
- Page 17 DAVINCI GLIDERS / RHYTHM2 DAVINCI GLIDERS / RHYTHM2 Name Manufacturer Name Manufacturer Name Manufacturer Name Manufacturer Name Manufacturer Name Manufacturer TNL-80 TNL-80 TNL-80 TNL-80 TNL-80 TNL-80 TNL-80 TNL-80 TNL-80 TNL-80 TNL-80 TNL-80 TNL-80 TNL-80 TNL-80 TNL-80 TNL-80 TNL-80 TNL-80 TNL-80...
- Page 18 DAVINCI GLIDERS / RHYTHM2 Overview...
- Page 19 DAVINCI GLIDERS / RHYTHM2 Serial Number Date of Production Dealer Date of sales Check and repair information...
- Page 20 Test laboratory for paragliders, paraglider harnesses and paraglider reserve parachutes Line and Riser Measurements of flight test Paraglider PG_1770.2021 Rhythm2 XXS 17.03.2021 Report No. : Sample name: Date measure: Davinci Products ARTT-XXS22210-PRLBK Claude Thurnheer Manufacturer: S/N: Responsible: Total line length including risers [mm] Main...
- Page 21 Test laboratory for paragliders, paraglider harnesses and paraglider reserve parachutes Line and Riser Measurements of flight test Paraglider PG_1736.2020 Rhythm2 M 26.02.2021 Report No. : Sample name: Date measure: Davinci Products ART-M22820-GPYB Claude Thurnheer Manufacturer: S/N: Responsible: Total line length including risers [mm] Main...
- Page 22 Test laboratory for paragliders, paraglider harnesses and paraglider reserve parachutes Line and Riser Measurements of flight test Paraglider PG_1758.2020 Rhythm2 XS 26.02.2021 Report No. : Sample name: Date measure: Davinci Products ARTT-XS22900-GPYB Claude Thurnheer Manufacturer: S/N: Responsible: Total line length including risers [mm] Main...
- Page 23 Test laboratory for paragliders, paraglider harnesses and paraglider reserve parachutes Line and Riser Measurements of flight test Paraglider PG_1746.2020 Rhythm2 L 26.02.2021 Report No. : Sample name: Date measure: Davinci Products ARTT-L22920-PRLBK Claude Thurnheer Manufacturer: S/N: Responsible: Total line length including risers [mm] Main...
- Page 24 Test laboratory for paragliders, paraglider harnesses and paraglider reserve parachutes Line and Riser Measurements of flight test Paraglider PG_1759.2020 Rhythm2 S 26.03.2021 Report No. : Sample name: Date measure: Davinci Products ARTT-S22910-BYRBK Claude Thurnheer Manufacturer: S/N: Responsible: Total line length including risers [mm] Main...
