  • Page 1 Your Global Automation Partner RFID Tags with Password Function Instructions for Use...
  • Page 2 Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...

  • Page 3: Table Of Contents

    Feedback about these instructions................ 5 Notes on the Product .........................  6 Product identification.....................  6 Scope of delivery ...................... 6 Legal requirements...................... 6 Turck service........................ 6 For Your Safety............................  7 Intended use........................ 7 General safety notes .......................  7 Product Description ...........................  8 Device overview ......................
  • Page 4 12 Technical Data........................... 44 12.1 Technical data – TW-R…-M-B146................ 44 12.2 Technical data – TW-…-B320 .................. 45 13 Turck Subsidiaries - Contact Information .................. 46 Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...

  • Page 5: About These Instructions

    This symbol denotes actions that the user must carry out. RESULTS OF ACTION This symbol denotes relevant results of actions. Other documents Besides this document the following material can be found on the Internet at www.turck.com: Data sheet Quick start guide Configuration manual...

  • Page 6: Notes On The Product

    CAD files in numerous export formats. The contact details of Turck subsidiaries worldwide can be found on p. [} 46]. Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...

  • Page 7: For Your Safety

    The product is designed according to state-of-the-art technology. However, residual risks still exist. Observe the following warnings and safety notices to prevent damage to persons and property. Turck accepts no liability for damage caused by failure to observe these warning and safety notices.

  • Page 8: Product Description

    Fig. 2: Dimensions – TW-R10-M-B146 TW-R12-M-B146 ø 20 3.6 [0.14] Ø 4.3 [0.17] mm [Inch] Fig. 3: Dimensions – Fig. 4: Dimensions – TW-R4-3-M-B320 TW-R20-B320 Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...

  • Page 9: Properties And Features

    A–A 90° 8 [0.32] 4 [0.16] Ø 5.6 [0.22] ø 5,2 ø 30 Ø 34 [1.34] Fig. 5: Dimensions – Fig. 6: Dimensions – TW-R30-B320, IN TAG 300 SLIX2 TW-R34-M-B320 ø 5,2 ø 50 Fig. 7: Dimensions – Fig. 8: Dimensions – TW-R50-B320 TW-L36-18-F-B320… Properties and features Tags available for direct mounting on and in metal EEPROM memory...

  • Page 10: Installing

    Position the tags parallel to the active face of the read/write head. Fig. 9: Parallel alignment of tag and read/write head (example) Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...

  • Page 11: Installing The Tags In Metallic Environments

    5.1.2 Installing the tags in metallic environments The TW-…-M-… tags are suitable for direct mounting on and in metal. Other types of tag must not be mounted directly on metal. The following measures must be taken if these tags nevertheless have to be mounted in metal environments. „...
  • Page 12 Fig. 13: Metal support outside of the transmission zone between the tag and the read/write head Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...

  • Page 13: Installing Ferrite Tags - Tw-R

    Installing ferrite tags – TW-R…-M-B146 The TW-R10-M-B146 and TW-R12-M-B146 tags can be fitted flush to the installation environ- ment. An undermount installation (1 mm in metal) will reduce the read/write distance by ap- prox. 30 %. 5.2.1 Aligning tags to the read/write head „...

  • Page 14: Fastening Tags To The Object

    Let the adhesive cure in order prevent the tags from turning. „ Optional: Fill any recess or cavity with adhesive. „ Optional: Spread the adhesive to produce a flush surface. Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...

  • Page 15: Operation

    Operation NOTE The achievable read/write distances may vary according to factors such as compon- ent tolerances, mounting locations, ambient conditions and the effect of materials. For this reason, the application must be tested in all cases under real conditions (par- ticularly with read and write operations in motion).

  • Page 16: Protecting The Sensor With A Password

    TN-CK40-H1147/C53 7030732 1v85 1v97 TN-Q80-H1147 7030007 7v85_TN_TNLR-Q80 7v97_TN_TNLR_Q80 TN-Q80-H1147/C53 100010648 7v85_TN_TNLR-Q80 7v97_TN_TNLR_Q80 TN-Q14-0.15-RS4.47T 7030235 1v85 1v97 TN-Q14-0.15-RS4.47T/C53 7030779 1v85 1v97 Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...
  • Page 17 Read/write head Firmware status EM4233SLIC SLIX2 TNLR-Q80-H1147 7030230 3v85 7v97_TN_TNLR_Q80 7v85_TN_TNLR-Q80 TNLR-Q80-H1147/C53 100010649 3v85 7v97_TN_TNLR_Q80 7v85_TN_TNLR-Q80 TB-EM18WD-H1147 7030224 1v85 1v97 TN-EM18WD-H1147 7030223 1v85 1v97 TB-EM30WD-H1147 7030221 1v85 1v97 TN-EM30WD-H1147 7030222 1v85 1v97 TB-Q08-0.15-RS4.47T 7030553 1v85 1v97 TB-Q08-0.15-RS4.47T/C53 7030778 1v85 1v97 TNLR-Q80L400-H1147 7030204 5v85...
  • Page 18 For this the following entries must be made with all commands: CMDREF[x].CMD = 0x62 Refer to the descriptions of the individual commands for the values for CMDREF[x].length. Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...

  • Page 19: Set Transceiver Pwd Command

    7.2.1 Set Transceiver PWD command The Set Transceiver PWD command sets a password in the read/write head via a Get com- mand. The password is stored temporarily in the memory of the read/write head. After the power supply of the read/write head is reset, the password must be set again in the read/write head.

  • Page 20: Set Tag Password Command

    Get.request TXBUF[1] TXBUF[2] Password byte [0] TXBUF[3] Password byte [1] TXBUF[4] Password byte [2] TXBUF[5] Password byte [3] Get.response RXBUF[1] Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...

  • Page 21: Set Tag Protection Command

    7.2.3 Set Tag Protection command The Set Tag Protection command defines the password protection for the tag via a Get com- mand. For this it has to be specified whether a write protection or a read protection should be set and the area of the tag to which the password applies. Protection for all areas is defined with one command.
  • Page 22 Read, Bit 16 Write, Bit 17 Read, Bit 17 Write, Bit 18 Read, Bit 18 Write, Bit 19 Read, Bit 19 Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...
  • Page 23 Basic status Ready? ERROR = true Error? (UIN0 = true) DONE = true? Execute command TXBUF[1] = 7 TXBUF[2] = write, bit 0…7 TXBUF[6] = read, bit 0…7 „GET“ active? (DONE = false) (BUSY = true) Tag present? (TP = true) Ready and ERROR = true successful?

  • Page 24: Get Tag Protection Status Command

    Waiting for next command Fig. 21: Flow chart Get.request TXBUF[1] Get.response RXBUF[1] RXBUF[2] Write, Bit 0…7 RXBUF[3…5] RXBUF[6] Read, Bit 0…7 Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...

  • Page 25: Resetting The Password In The Read/Write Head

    7.2.5 Resetting the password in the read/write head The Reset Password in the Read/Write Head command deletes the password in the read/write head via a Get command. Basic status Ready? ERROR = true (XIN0 = true) Error? DONE = true? Execute command TXBUF[6] „GET“...
  • Page 26 XCVR _INFO RESET Reserved DOMAIN_COUNT Reserved BYTE_ BYTE_ BYTE_ COUNT 2 COUNT 1 COUNT 0 AddrHi AddrLo 8 Bytes WRITE_DATA Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...

  • Page 27: Set Transceiver Pwd Command

    7.3.2 Set Transceiver PWD command The Set Transceiver PWD command sets a password in the read/write head via a Get com- mand. The password is stored temporarily in the memory of the read/write head. After the power supply of the read/write head is reset, the password must be set again in the read/write head.

  • Page 28: Set Tag Password Command

    Fig. 24: Flow chart Get.request TXBUF[1] TXBUF[2] Password byte [0] TXBUF[3] Password byte [1] TXBUF[4] Password byte [2] TXBUF[5] Password byte [3] Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...

  • Page 29: Set Tag Protection Command

    7.3.4 Set Tag Protection command The Set Tag Protection command defines the password protection for the tag via a Get com- mand. For this it has to be specified whether a write protection or a read protection should be set and the area of the tag to which the password applies. Protection for all areas is defined with one command.
  • Page 30 Read, Bit 16 Write, Bit 17 Read, Bit 17 Write, Bit 18 Read, Bit 18 Write, Bit 19 Read, Bit 19 Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...
  • Page 31 Ready for RFID- communication Ready? ERROR = true (XCVR_ON = true) Error? (DONE = true) Preallocate values: Byte Count = 7 WRITE DATA [0] = write, bit 0…7 WRITE DATA [4] = read, bit 0…7 GET command (GET = true) [false ➞...

  • Page 32: Get Tag Protection Status Command

    (BUSY = false) XCVR_ON = true Fig. 26: Flow chart Get.request TXBUF[1] Get.response RXBUF[1] RXBUF[2] Write, Bit 0…7 RXBUF[3…5] RXBUF[6] Read, Bit 0…7 Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...

  • Page 33: Resetting The Password In The Read/Write Head

    7.3.6 Resetting the password in the read/write head The Reset Password in the Read/Write Head command deletes the password in the read/write head via a Get command. Ready for RFID- communication Ready? ERROR = true (XCVR_ON = true) Error? (DONE = true) Preallocate values: Byte Count = 6 GET command...

  • Page 34: Setting Password Protection For Tags

    Error message Error present? ERROR CODE = (ERROR = True) E1FE0200 Fig. 28: Programming tags – multiple tags with one password Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...
  • Page 35 Command: Set_transceiver_password (with default passwort of data carrier = 0x0000) Command: Read … Write … Fig. 29: Access in the application – multiple tags with one password V02.00 | 2021/02...

  • Page 36: Multiple Tags With Different Passwords In An Application (Example)

    Command: Read … Write … new data carrier Fig. 31: Access in the application – multiple tags with different passwords Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...

  • Page 37: Setting Password Protection Via Fdt/Dtm

    7.4.3 Setting password protection via FDT/DTM The BL…-2RFID-S module enables the password protection to be set by a PC via the FDT/DTM. The example uses the following components: FDT: PACTware with the DTM for BL67-2RFID-S BL67-GW-EN gateway BL67-2RFID-S RFID electronic module TN-Q80-H1147 read/write head „...
  • Page 38 Fig. 33: Setting the password of the read/write head to 0 „ Set a new password in the tag. Fig. 34: Setting a new password in the tag (example: 11223344) Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...
  • Page 39 „ Set a new password in the read/write head. Fig. 35: Setting a new password in the read/write head (example: 11223344) „ Set write or read protection. Fig. 36: Setting read/write protection V02.00 | 2021/02...
  • Page 40 Setting Setting password protection for tags Fig. 37: Setting read protection Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...

  • Page 41: Addressing Password Protected Areas Of A Tag

    Addressing password protected areas of a tag The following table shows the possible access options to the tag when password protection is set. Action Response of the tag Remark Access to read protected area Tag responds with 0 The response of the tag with 0 can have two causes: without password or with Either the memory area of the tag is written with 0 incorrect password...

  • Page 42: Troubleshooting

    If there are no faults, there is a device malfunction. In this case, decommission the device and replace it with a new device of the same type. Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...

  • Page 43: Maintenance

    Observe our return acceptance conditions when returning the device to Turck. 10.1 Returning devices Returns to Turck can only be accepted if the device has been equipped with a Decontamination declaration enclosed. The decontamination declaration can be downloaded from https://www.turck.de/en/retoure-service-6079.php and must be completely filled in, and affixed securely and weather-proof to the outside of the packaging.

  • Page 44: Technical Data

    Typical read time 2 ms/byte Typical write time 3 ms/byte Wireless communication ISO 15693 NFC Type 5 protocol standards Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...

  • Page 45: Technical Data - Tw

    12.2 Technical data – TW-…-B320 Technical data IN TAG 300 SLIX2 TW-L36-18-F- TW-L36-18-F- TW-R4-3-M-B320 B320-4KPCS B320-100PCS 100002356 100003272 100025059 100013771 Data transmission Inductive coupling Operating frequency 13.56 MHz Memory type EEPROM Chip type NXP ICODE SLIX2 Memory size 320 bytes Memory Read/write Freely usable memory...

  • Page 46: Turck Subsidiaries - Contact Information

    Turck Banner Malaysia Sdn Bhd Unit A-23A-08, Tower A, Pinnacle Petaling Jaya, Jalan Utara C, 46200 Petaling Jaya Selangor www.turckbanner.my Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...
  • Page 47 Mexico Turck Comercial, S. de RL de CV Blvd. Campestre No. 100, Parque Industrial SERVER, C.P. 25350 Arteaga, Coahuila www.turck.com.mx Turck B. V. Netherlands Ruiterlaan 7, NL-8019 BN Zwolle www.turck.nl Austria Turck GmbH Graumanngasse 7/A5-1, A-1150 Wien www.turck.at Poland TURCK sp.z.o.o.
  • Page 48 Over 30 subsidiaries and over 60 representations worldwide! D500054 | 2021/02 D500054 www.turck.com...
