Summary of Contents for Hyundai Excel 1993

  • Page 2 FOREWORD EMISSION CONTROL SYSTEM This shop manual is intended for use by service techni- FUEL SYSTEM cians of authorized Hyundai dealers to help them provide efficient and correct service and maintenance on Hyundai CLUTCH (Hydraulic type) vehicle. CLUTCH (Cable type)

  • Page 3: General Information

    GENERAL INFORMATION...

  • Page 4: How To Use This Manual

    00-2 GENERAL INFORMATION TO USE THIS MANUAL This manual is divided into 23 sections. This first page of each section is marked with a black tab at the edge of the page. You can quickly find the first page of each section without looking through a full table of contents.

  • Page 5: Vehicle Identification Number Location

    VEHICLE IDENTIFICATION NUMBER K M H 0 0 0 0 4 7 1. World manufacturer’s identifier code KMH - Hyundai Motor Co., Korea 2. Drive line type V - For LHD (EXCEL) 3. Body Type F - 4 Door sedan D - 3 Door sedan 4.
  • Page 6 00-4 TRANSAXLE NUMBER IDENTIFICATION Description (Automatic transaxle) 1. Model B: KM 176 A: KM 171 2. Product year M : 1991 N : 1992 P : 1993 R : 1994 3. Final gear ratio F : 4.062 E : 3.600 4.

  • Page 7: Engine Identification Plate

    ENGINE IDENTIFICATION PLATE The engine identification plate is stamped at the right front side on the top edge of the cylinder block. ENGINE IDENTIFICATION NUMBER Engine identification number consists of 10 digits. 1. Engine fuel G : Gasoline 2. Engine range 4 : In line 4 cycle 4 cylinder 3.

  • Page 8: Protection Of The Vehicle

    00-6 PROTECTION OF THE VEHICLE Always be sure to cover fenders, seats, and floor areas before starting work. CAUTION: The support rod must be inserted into the hole near the edge of the hood whenever you inspect the engine compartment to prevent the hood from falling and possibly injuring you.

  • Page 9: Preparation Of Tools And Measuring Equipment

    PREPARATION OF TOOLS AND MEASURING EQUIPMENT Be sure that all necessary tools and measuring equipment are available before starting work activity. SPECIAL TOOLS Use special tools when they are required. REMOVAL OF PARTS First find the cause of trouble and then make sure whether removing or disassembling is required before starting the job.
  • Page 10 All parts to be reused should be carefully and thoroughly cleaned by the appropriated method. PARTS When replacing parts, use HYUNDAI genuine parts REASSEMBLY Standard values, such as torques and certain adjustments, must be strictly observed in the reassembly of all parts.

  • Page 11: Electrical System

    00-9 ELECTRICAL SYSTEM 1. Be sure to disconnect the battery cable from the negative (-) terminal of the battery. 2. Never pull on the wiring when disconnecting connectors. 3. Locking connectors will click when the connector is secure. 4. Handle sensors and relays carefully. Be careful not to drop them or hit them against other parts.
  • Page 12 00-10 CATALYTIC CONVERTER INSPECTION Inspect for damage, cracking or deterioration. Replace if faulty. CAUTION The catalytic converters require the use of unleaded gasoline only. Leaded gasoline will destroy the effectiveness of the catalysts as an emission control device. Under normal operating conditions, the catalytic converters will not require maintenance.

  • Page 13: Jack Point

    00-11 JACK POINT When using a free wheel type auto lift When using a single-post lift When using double-post lift...
  • Page 14 JACK POINT When using a floor jack When using the jack provided with the vehicle (for reference) NOTE Do not support car at locations other than the specified support points. This will cause damage etc. to the body.
  • Page 15 00-13 NOTES 1. The torques shown in the table are standard values applicable to tightening performed under the following conditions: 1) Nuts and bolts are made of steel bar, and galvanized. 2) Galvanized plain steel washers are inserted. 3) All nuts, bolts, and plain washers are dry. 2.
