Note: For some small size LED panel,the color coordination of
specifications is not X=0.280/Y=0.290,and we recommend you adopt the
values from panel specifications.
5.5. ADC Calibration and White Balance Adjustment (automatic)
The process of adjusting White Balance automatically is out of the
range of this file, Please refer to the relevant technical file of HuiZhou
factory of TCL.
6.Chip list of software programming before SMT
Following chips must be programmed before SMT by tools
Position
Chip type
U301
MT29F2G08ABAEA
U301
MT29F4G08ABAEA
7.Software update
Method of SW update:
1) Download the bin file to the root directory of your USB device (Do
not change the file name); Then insert the USB device to USB interface
of TV set.
MS08BP/MS08BPA Series with its upgrade file corresponding relation
as thetable below show:
Chassis Name
MS08BP
MS08BPA
2)Appendix
"How to upgrade SW FLASH using Mstar tool"
See Appendix
"How to upgrade MBOOT using USB"
Copy the SW BIN image "
Note: If there's already other "
renamed.
Plug USB stick to the TV USB slot.
Press RCU MENU Option
Or, turn off the TV press and hold the power key of key board before reconnect AC
cord to restart TV for 5-8seconds (Forced Upgrade).
HDMI HDCP Key, System Software
HDMI HDCP Key, System Software
Sales
Upgrade filename
area
RU
MS08BPupgrade.bin DVB-T2
AP
MS08BPupgrade.bin DVB-T2
MstarUpgrade.bin
MstarUpgrade.bin
Software upgrade By USB Confirm.
Software description
Remark
" into USB stick root path.
" into USB root, it needs to be deleted or
第 11 页共 11 页
Chassis
Name
etc.
MS08BP
etc.
MS08BPA
