  • Page 1 Crestron C2N-IVDS24x24 Intercom Video Distribution System Operations Guide...
  • Page 2 This document was prepared and written by the Technical Documentation department at: Crestron Electronics, Inc. 15 Volvo Drive Rockleigh, NJ 07647 1-888-CRESTRON All brand names, product names and trademarks are the property of their respective owners. ©2003 Crestron Electronics, Inc.

  • Page 3: Table Of Contents

    Crestron C2N-IVDS24x24 Contents Intercom Video Distribution System: C2N-IVDS24x24 Introduction ... 1 Features and Functions ... 1 Specifications ... 4 Physical Description... 5 Industry Compliance ... 8 Setup ... 8 Network Wiring... 8 Identity Code ... 9 Rack Mounting ... 12 Stacking...

  • Page 5: Intercom Video Distribution System: C2N-Ivds24X24

    Featuring 24 inputs (16 RCA, 8 CAT5), the IVDS accepts composite video signals over RCA (from video cameras and other composite sources) and CAT5 wiring (from door stations and Crestron devices that transmit composite video over CAT5) and can switch them to any of 24 composite output channels (8 RCA, 16 CAT5).
  • Page 6 NOTE: The device types and quantities shown in the above diagram are for illustrative purposes only. Your actual configuration is only limited by the number of available ports, and can contain multiple IADS and IVDS devices. 2 • Intercom Video Distribution System: C2N-IVDS24x24 Crestron C2N-IVDS24x24 Operations Guide - DOC. 6171...
  • Page 7 Crestron C2N-IVDS24x24 Paging Connect the audio outputs of the IADS to a Crestron CNX-PAD8A (PAD8A) or CNX-BIPAD8 (BIPAD8) audio distribution system to add whole facility paging through the audio distribution system. Connect a Crestron CNXTA telephone card (requires a control system that accepts expansion cards) to the IADS to allow dial-up paging to specific or to all zones throughout the facility.

  • Page 8: Specifications

    Output Channels Balanced line performance Unbalanced line performance Supported Video Signal Formats C2N-IVDS24x24 Firmware (continued on next page) 4 • Intercom Video Distribution System: C2N-IVDS24x24 SPECIFICATION Video Input (RJ-45) Video Output (RJ-45) Video Input (RCA) Video Output (RCA) Crestron C2N-IVDS24x24 DETAILS 12 Watts (0.5 Amp @ 24 VDC)

  • Page 9: Physical Description

    MP2/MP2E CNMSX-AV/PRO CNRACKX/-DP The latest versions can be obtained from the Downloads | Software Updates section of the Crestron website (www.crestron.com). Refer to NOTE below. Crestron 2-Series control systems include the AV2, CP2, CP2E, MP2, MP2E, PAC2, PRO2, and RACK2.
  • Page 10 All connections to the IVDS are made through the ports on the rear panel. Refer to the illustrations and descriptions, which follow. NOTE: An interface connector for the NET port is provided with the IVDS. 6 • Intercom Video Distribution System: C2N-IVDS24x24 3.31 in (8.41 cm) 16.91 in...
  • Page 11 RJ-45 Connector Specifications NOTE: For additional information on audio/video connections over CAT5, refer to the latest version of the Crestron CAT5 Wiring Reference Guide (Doc. 6137) which is available from the Downloads | Product Manuals section of the Crestron website (www.crestron.com).

  • Page 12: Industry Compliance

    NOTE: When installing network wiring, refer to the latest revision of the wiring diagram(s) appropriate to your specific system configuration, available from the Downloads | Product Manuals | Wiring Diagrams section of the Crestron website (www.crestron.com). When calculating the wire gauge for a particular Cresnet run, the length of the run and the power factor of each Cresnet unit to be connected must be taken into consideration.

  • Page 13: Identity Code

    This method does not require that any devices be disconnected Operations Guide - DOC. 6171 Intercom Video Distribution System RESISTANCE (R) WIRE GAUGE Doubled CAT5 Tripled CAT5 Intercom Video Distribution System: C2N-IVDS24x24 • 9...
  • Page 14 Intercom Video Distribution System from the network; Net IDs may be set with the entire Cresnet system intact. This method requires the use of the Crestron Viewport version 3.35 or later. Use the appropriate method to set the Net ID.
  • Page 15 Open the Crestron Viewport. From the Viewport menu, select Functions | Serial Number TSID Conversion Tool. The “Serial Number Tool” window is displayed. Intercom Video Distribution System: C2N-IVDS24x24 • 11 TSID Conversion...

  • Page 16: Rack Mounting

    Complete the following procedure to attach the ears to the unit. The only tool required is a #2 Phillips screwdriver. 12 • Intercom Video Distribution System: C2N-IVDS24x24 Enter the serial number or TSID number as instructed; press the appropriate button to obtain the corresponding number.

  • Page 17: Stacking

    3. Secure the ear to the unit with three screws from step 1, as shown in step 1. 4. Repeat procedure (steps 1 through 3) to attach the remaining ear to the opposite side. Intercom Video Distribution System: C2N-IVDS24x24 • 13 FASTEN WITH THREE TOP COVER SCREWS ATTACH FEET...

  • Page 18: Programming Software

    Earliest Version Software Requirements for the PC software? Direct software related suggestions NOTE: Crestron recommends that you use the latest software to take advantage of and/or complaints to Crestron via the most recently released features. The latest software is available from the email (software@crestron.com).
  • Page 19 It provides a well-designed graphical environment with a number of workspaces (i.e., windows) in which a programmer can select, configure, program, test, and monitor a Crestron control system. SIMPL Windows offers drag and drop functionality in a familiar Windows This section explains how to create a SIMPL Windows program that includes the IVDS.
  • Page 20 In SIMPL Windows, an Analog Initialize logic symbol, as shown in the following diagrams, can be used to provide these analog inputs to the IVDS symbol. 16 • Intercom Video Distribution System: C2N-IVDS24x24 Crestron C2N-IVDS24x24 Operations Guide - DOC. 6171...
  • Page 21 Analog Initialize (For Compensation Settings for Source 17) NOTE: Similar Analog Initialize symbols can be created for the compensation settings of Sources 18 through 24. Operations Guide - DOC. 6171 Intercom Video Distribution System Intercom Video Distribution System: C2N-IVDS24x24 • 17...
  • Page 22 Intercom Video Distribution System C2N-IVDS24x24 The following diagram shows the IVDS symbol in the SIMPL Windows’ Programming Manager. Detail View of the C2N-IVDS24x24 in SIMPL Windows’ Programming Manager 18 • Intercom Video Distribution System: C2N-IVDS24x24 Crestron C2N-IVDS24x24 Operations Guide - DOC. 6171...

  • Page 23: Video Input Compensation

    For longer cable lengths, use higher levels (level 2 or 3). Example Program An example program for the IVDS is available from the Crestron FTP site (ftp://ftp.crestron.com/Examples/). Search for C2NIADS_C2NIVDS.ZIP that contains the example program, associated files and a README.TXT file that describes the program.

  • Page 24: Communication Settings

    Instead, compiled files may be distributed from programmers to installers, from Crestron to dealers, etc. Even firmware upgrades are available from the Crestron website as new features are developed after product releases. In those instances, one has the option to upload via the programming software or to upload and upgrade via the Crestron Viewport.
  • Page 25 (COM 1 is shown after this step) is selected, and that all communication parameters and necessary options from the “Port Settings” window are selected as shown after this step. Click the OK button to save the settings and close the window. Intercom Video Distribution System: C2N-IVDS24x24 • 21...

  • Page 26: Uploading A Simpl Windows Program

    .bin for CNX generation, and .csz for CNX generation with SIMPL+. Upload via Crestron Viewport 22 • Intercom Video Distribution System: C2N-IVDS24x24 Crestron C2N-IVDS24x24 4. To verify communication, select Diagnostics | Establish Communications (Find Rack). This should display a window that gives the COM port and baud rate.
  • Page 27 4. To verify that the program has been transferred successfully, select Diagnostics | Report Program Information. This should display a window that provides details about the current program loaded into the control system. Intercom Video Distribution System: C2N-IVDS24x24 • 23...

  • Page 28: Firmware Upgrade

    Therefore, please check the Crestron website (http://www.crestron.com/downloads/software_updates.asp) for the latest version of firmware. Not every product has a firmware upgrade, but as Crestron improves functions, adds new features, and extends the capabilities of its products, firmware upgrades are posted. To upgrade the firmware, complete the following steps.

  • Page 29: Problem Solving

    “Open” Window Problem Solving Troubleshooting the C2N-IVDS24x24 The following table provides corrective action for possible trouble situations. If further assistance is required, please contact a Crestron customer service representative. C2N-IVDS24x24 Troubleshooting Operations Guide - DOC. 6171 Intercom Video Distribution System 4.

  • Page 30: Further Inquiries

    Dial one of the following numbers. Future Updates As Crestron improves functions, adds new features, and extends the capabilities of the IVDS, additional information may be made available as manual updates. These updates are solely electronic and serve as intermediary supplements prior to the release of a complete technical documentation revision.

  • Page 31: Return And Warranty Policies

    CRESTRON shall not be liable to honor the terms of this warranty if the product has been used in any application other than that for which it was intended, or if it has been subjected to misuse, accidental damage, modification, or improper installation procedures.
  • Page 32 Crestron Electronics, Inc. Operations Guide – DOC. 6171 15 Volvo Drive Rockleigh, NJ 07647 08.03 Tel: 888.CRESTRON Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
