Coleman 2000013261 Setup Instructions

DO NOT PRINT THIS PAGE
Material: White washable and tear resistant non-woven
fabric, such as Tyvek.
Ink: Black
Resolution: 150 DPI or above
Printing method: Offset Printing
Size: 8.27 x 11.69 in (W x H) A4
This drawing contains proprietary information and trade secrets of The Coleman Company, Inc.
METRIC
[INCH]
CRITICAL DIMENSION
04 24-OCT-16
CHECKING IS COMPULSORY
03 22-APR-16
02 9-FEB-15
VOLUME 01 22-OCT-12
cm3
MASS
grams
REV. DATE
MATERIAL: SEE NOTES
DENSITY g/cm3
GENERAL TOLERANCES
SEE NOTES
EXCEPT AS NOTED FINISH
SPEC.:
0 TO 6mm = ±0.1
>6 TO 30mm = ±0.2
SCALE: DATE:
>30 TO 80mm = ±0.3
1:1
>80 TO 180mm = ±0.4
>180mm = ±0.5
NAME:
Instruction Sheet for Shelter 2000013261
ANGULAR = ± 3°
Printing Notes:
Unauthorized use or copying is prohibited.
Changed "velcro straps" to "fly attachments" and updated ECN number.
Added warning in "Before you begin"; Applied new format to IM.
Updated "Before you begin" and "Things you should know" section and
ECN number.
NEW
MODIFICATIONS
DRAWN BY:
22-OCT-12 Rainy X
Program: InDesign CS6
Black
Rainy X 20057783
Fiona S. 20055933
Rainy X 20046151
Rainy X 20025300
NAME ECN NO.
The Coleman Company, Inc.
Wichita, Kansas USA 67219
COMPOSITE- NO SHEET 1 OF 1
APPROVED BY: REVISION REVISION
04
ID
PART
NO.:
4010022756
