ASSEMBLY INSTRUCTIONS:

Item No: 10056/604

1. Place the base (A) on a level surface.

2. Insert the harp (C) until it sits firmly into the saddle (B).

3. Adjust the knurl nut (D) on harp (C).

This can be used to raise the shade a little if necessary.

4. Place lower cap (E), shade (F), and upper cap (G) over

the end of the harp (C) and tighten the finial (H) securing

the shade in place.

5. Insert the bulb into the bulb socket.

Recommended (1) maximum 60 WATT Type "B" Bulb

Or (1) maximum 13WATT CFL Bulb

(Bulb not included)

Cleaning of your lamp.

Unplug lamp, wipe with a damp cloth.

Do not use abrasives

*SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.

Made in China

FOR RETURN SHIPPING PURPOSES:

PLEASE RETAIN ORIGINAL PACKAGING

TO MINIMIZE DAMAGE.

Revision -10/16/12
